DESCRIPTION
The GXT 4000 microphone console is a touch screen console. It has from 16 up to 64 programmable soft
keys for making PA broadcasts into selected areas or zones. It is designed to operate over a bus architecture,
meaning that several consoles can be used over the same network, while collectively occupying just one single
audio channel. In fact, the consoles are self-regulating, with audio channel priority always being given to the first
console that picks up the channel. The main part of the console may be flush fitted or mounted on its own swivel
base for tabletop use.
The GXT 4000 console comes complete with:
an electret microphone,
a touch screen for setting and selecting zones,
a memory card reader for broadcasting pre-recorded messages,
a loudspeaker for monitoring announcements, etc.,
a fail soft switch with protective hood.
It may be used to:
view the degree of occupancy of the network's zones,
broadcast an announcement into one or more zones.
2
TECHNICAL SPECIFICATIONS
Audio signal bus:
Output: via transformer
Nominal level: 0 dBu
Microphone preamplifier: compressor fitted
Transmission and commands
Serial link: RS485 bus
User interface
Touch screen with up to 64 programmable soft keys and 5 function keys
Zone occupancy indicator
Audio bus occupancy indicator
Indicator showing whether the serial link is connected to the host system
a protected fail soft pushbutton switch (connector output with connection box)
monitoring loudspeaker
message memory card reader
Message memory card reader
Memory medium: SD card using FAT32, files stored in root directory only (sub-directories are
not supported)
Message format: wav, 44100 Hz, 16 bit, mono
The console has 2 memory card slots, one inside the console, the second accessible from the
outside. The external reader has priority
GXT 4000 – 16
GXT 4000 – 32
GXT 4000 – 48
GXT 4000 – 64
TOUCH SCREEN
MICROPHONE
CONSOLES
GENERAL INFORMATION
Code 596652eng-01/2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the GXT 4000-16 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bouyer GXT 4000-16

  • Page 1 GXT 4000 – 16 GXT 4000 – 32 GXT 4000 – 48 GXT 4000 – 64 TOUCH SCREEN MICROPHONE CONSOLES GENERAL INFORMATION Code 596652eng-01/2024 DESCRIPTION The GXT 4000 microphone console is a touch screen console. It has from 16 up to 64 programmable soft keys for making PA broadcasts into selected areas or zones.
  • Page 2: Installation

    Power • Voltage: 24 V d.c. (min. 12 volts, max. 28 volts) • Current: 110 mA (190 mA at 12 V, 100 mA at 28 V) Housing • Material: metal • Colour: grey console on black base • Dimensions: 287 x 237 x 73 mm •...
  • Page 3 Recess mounting Recess dimensions: 240 x 150 mm Separate the central unit from its base by extracting the 2 screws and brackets located underneath the unit. Use the brackets to fix the unit to a supporting surface that has a depth of between 1 and 35 mm. For greater depths, use spacers, wedges or longer bracket retaining screws.
  • Page 4 Fail soft mode: To wire up the fail soft, connect the connection box (PGM) to the 26 pin connector strip located inside the console. The connector strip may be accessed by removing the cover on the console’s base. There is one configuration switch per protected pushbutton located on the main board inside the console; use these switches to set the contacts to NO (normally open) or NC (normally closed) as required.
  • Page 5 2 (Console 2 RJ45 socket) to which can be connected one or more GXT 4000 or GX 3016 units (address 2). Refer to the CC 3816 Manual for additional information. Use with the DN 3816 (multi-DN application) Contact Bouyer for further information. GXT 4000...
  • Page 6: Operation

    OPERATION Description of the touch screens 6.1.1 Start screen When first switching on the console, a Welcome screen is displayed while the console boots up. 6.1.2 The zone selection screens The zone selection screens are then displayed. The GXT 4000 can be set to display its screens in either of two ways. Display mode 1: (Standby) This mode displays: - the date and time,...
  • Page 7 Display mode 2 : (ON) This mode displays: - the host system connection (in this case the RS485 connection has been established as shown by the icon - the date and time, - which zones are occupied (in this case the “North Entrance” zone which has been set to soft key n°21), - the programmable soft keys from n°17 to 26, and here showing that zone 21 is occupied,...
  • Page 8 The CHIME Tab The second tab is used to set the chime volume. Use the cursor to adjust the volume from 0 (silent) and 10 (maximum). This slider also sets the volume at which audio messages stored on the memory card are broadcast. Pressing the Default Setting key sets the volume automatically to 5.
  • Page 9 • Where a key’s function is set to None, pressing the soft key will result in the message being broadcast in all the previously switched zones (the message will only play if 1 or more zones has been switched), • Where the key’s function is set to Number or General Announcement, pressing the soft key will first request the zone or group linked to the key number to be switched before it can broadcast the message.
  • Page 10 Using the selection dial: Values may be changed by “flicking” the relevant box to scroll through the various possible options. The dial will automatically disappear, saving the selection, if the touch screen is then left alone. Press the key to save any changes you have made in the KEY menu and exit. Press the key to exit the menu without saving any changes you may have made.
  • Page 11: The Password Tab

    4 characters. The password is used to protect access to the Console , Key , Message System menus. The password is left empty by default (input either 4 spaces or leave blank). A password recovery procedure is available should the password be forgotten. Contact Bouyer for further information. GXT 4000...
  • Page 12 The DISPLAY Tab The fourth tab is used to change the style in which the zone selection screens are displayed. Use this to switch between display modes 1 and 2, as well as select and arrange the function keys in each mode. Display mode : Press on the display mode button to switch to mode 1 or on display...
  • Page 13 To switch to a more recent version requires a code that can be supplied to order. Contact Bouyer for further information. The unlock code consists of 4 characters. These may be input using the hexadecimal keypad to the right.
  • Page 14 Use the hexadecimal keypad to the right to enter the unlock code. Contact Bouyer for further information. The PA MODE Tab The ninth tab is used to configure the way the Microphone and Chime keys work.
  • Page 15 Pressing on the PA Mode box displays a selection dial showing the different options. Using the selection dial: Values may be changed by flicking the relevant box to scroll through the various possible options. The dial will automatically disappear, saving the selection, if the touch screen is then left alone. Press the key to save any changes you have made in the CONSOLE menu and exit.
  • Page 16 Pressing the Play key opens the Broadcast message window so that the message can be listened to locally on the monitoring loudspeaker. Use this screen to view playback progress of the message selected; press Stop stop playback. The progress bar shows how far through the announcement the playback is. Using the selection dial: Values may be changed by flicking the relevant box to scroll through the various possible options.
  • Page 17: The System Tab

    Standby Screen After one minute of inactivity the console will switch to standby, and display the Bouyer logo and the current time. Tapping the touch screen or activity on the bus (such as another source grabbing a zone, for example) will cause the console to return to its zone selection screen.
  • Page 18 At the end of your product’s life and where it is located within France’s territorial limits, please contact BOUYER to arrange for its destruction in accordance with the DEEE directive pertaining to the disposal of waste electrical and electronic equipment.
