- Page 1 Intelligent TFT-LCD Module Model STWA043WT-01 Equipment Manual STWI050WT-01 Equipment Manual Release 05/2021 www.stoneitech.com...
-
Page 2: Table Of Contents
Contents Preface ......................3 1 Introduction ....................5 2 Technical Parameters ................. 9 3 Interface Description ................15 4 Coprocessor (optional) ................15 5 Accessories ....................17 6 Physical Dimensions ................19 7 Electrical Components ................20 8 Naming Rule ....................21 9 International Certification................ -
Page 3: Preface
- Official website: https://www.stone-hmi.com https://www.stoneitech.com https://forum.stoneitech.com - Official forum: https://forum.stoneitech.com - Official forum: - Telephone: 0086-10-84351669 Other support In need of technical queries, please contact STONE representatives in the subsidiaries and branches responsible for your area. STWI050WT-01 Equipment Manual Release 05/2021 www.stoneitech.com... - Page 4 Preface Trademarks STONE registered trademarks are as below: - STONE - STONE TECH - Intelligent HMI - Intelligent TFT-LCD Module - Smart TFT-LCD Module Abbreviations The abbreviation table in this equipment manual is as below: Light Emitting Diode Central Processing Unit...
-
Page 5: Introduction
Introduction This chapter contains general information of: - Brief Introduction - Warranty - Product Characteristics - Application Area - Working principle - Operation Processing - Software Operation STWI050WT-01 Equipment Manual Release 05/2021 www.stoneitech.com... - Page 6 Introduction 1.1 Brief Introduction The STWA043WT-01 has been used as Equipment TFT dispaly & Touch controller. It includes processor, control program, TFT driver, flash memory, UART port, touch screen, power supply etc., and the important is it can supply the Json Code & Hex Code instruction sets, so that it can be controlled by Any MCU.
- Page 7 Introduction 1.5 Working Principle The Intelligent TFT-LCD Module communicates with the Customer’s MCU / CPU / FPGA / PLC via JSON Code and HEX Code Instructions, then the MCU can control its connected equipment to work according to the received instructions. Figure 1.3-1 Configuration and process control phase STWI050WT-01 Equipment Manual...
- Page 8 1.6 Operation Processing Only 3 steps to operate our TFT-LCD Module: 1) Build a new GUI project by STONE GUI Designer Software. 2) Connect with customer’s MCU through RS232,RS422,RS485,TTL directly, Plug & Play. 3) Write a simple program for MCU to control the TFT-LCD Module via Instruction Sets.
- Page 9 Introduction 1.7 Software Operation We will offer a simple & powerful "Stone GUI designer" Software to assist you to design the new GUI project for TFT-LCD Module basic on Windows system, MacOS system or Linux system. STWI050WT-01 Equipment Manual Release 05/2021...
-
Page 10: Technical Parameters
Technical Parameters This chapter contains technical data on: - Physical Parameters: Physical Parameters Display - Hardware Parameters: Processor Memory Interface Power Supply - Storage & Test Electrical Characteristics Ambient Conditions Noise Immunity Radio Interference - Support Device Support Device STWI050WT-01 Equipment Manual Release 05/2021 www.stoneitech.com... - Page 11 Technical Parameters Physical Parameter Size 4.3 inch Resolution 480×RGB×272 Pixel Spacing 0.066(W) × 0.198(H) mm Color 262,144 colors (18 bit) Viewing Area 95.04(W) × 53.86(H) mm Display Dimension 106.5mm × 68.20mm 121.9mm × 74.7 mm × 15.5 mm (T) (Standard type) Overall Dimension 121.9mm ×...
- Page 12 Technical Parameters Interface Serial Interface RS232 / RS422 / RS485 / TTL level Ethernet Interface 10M/100M (optional) Wireless Interface WIFI (optional) Project Download Suggest U Storage Disk or USB2.0 by PC Power Supply Rated Voltage +12V DC or +5V DC Permissible Voltage Range +9V DC...+28V DC or +5V DC Max.
- Page 13 Technical Parameters Ambient Conditions Max. Permissible Ambient Temperature Operation -30℃～ +80℃ Storage -40℃～ +85℃ Relative Humidity 55℃,85% Operation Storage 60℃,90% Shock Loading Operation 15 g/11 msec Storage 25 g/6 msec Vibration Operation 0.035 mm (10 - 58 Hz)/ 1 g (58 - 500 Hz) Storage 3.5 mm (5 - 8,5 Hz)/ 1 g (8.5 - 500 Hz) Barometric Pressure...
- Page 14 Technical Parameters Support Device Support UART Port RS232 / RS422 / RS485 / TTL Support(optional) Network Port Ethernet Port / WIFI Support Flash Memory Standard 256MB Buzzer Support Support Support USB Type A Port Online Download By USB Cable Support U Storage Disk Interface Offline Download or Copy User Data Touch Screen...
-
Page 15: Interface Description
Interface Description This chapter contains the description of the interfaces: - VIN - NC - DO - DI - GND Communication Interface Definition： Option Pin Name Pin NO. Pin Type Interpret Power Ground Data Input RS232/ Data Output None Power Supply Input Power Ground RS485 A RS485... -
Page 16: Coprocessor (Optional)
Coprocessor (optional) This chapter contains the description of the functions: - STM32F103C8T6 MCU Chip - Instruction Transparent Transmission - Instruction Translation - RS485 Bus - CAN Bus STWI050WT-01 Equipment Manual Release 05/2021 www.stoneitech.com... -
Page 17: Accessories
Accessories This chapter contains the accessories: - Double 8-pin Connect Cable - 8-pin Socket - Type A USB Cable - Converter: USB ⇌ RS232 / RS422 / RS485 / TTL - IP65 Plastic Box (optional) - Metal Bezel (optional) Picture Accessory Name Model Note... - Page 18 Picture Accessory Name Model Note IP65-043 IP65-050 For: 4.3”, 5”, 5.6”, 7”, IP65 Plastic Box IP65-056 8”,10.1” (optional) IP65-070 IP65-080 IP65-101 MB-035 MB-043 MB-050 For: 3.5”, 4.3”, 5”, 5.6”, Metal Bezel MB-056 7”, 8”,10.1”,10.4” (optional) MB-070 Colour: Silver & Black MB-080 MB-101 MB-104...
-
Page 19: Physical Dimensions
Physical Dimensions This chapter contains the information of Physical Dimensions. Figure 6-1 STWA043WT-01 dimension STWI050WT-01 Equipment Manual Release 05/2021 www.stoneitech.com... -
Page 20: Electrical Components
Electrical Components This chapter contains the brands of the components: - TFT Panel - Touch Screen - CPU - LCD Controller - Flash memory - Connecter - Capacitance - IC STWI050WT-01 Equipment Manual Release 05/2021 www.stoneitech.com... -
Page 21: Naming Rule
Naming Rule This chapter contains the naming rule: As sample STWI070WT-01E Code Explain Company Code The third version product I=Industrial Type ; A=Advanced Type；C=Civil Type TFT Panel Dimension: 7 inch W=Wide Voltage (+7V to +28V) L=Low Voltage (+5V) T=With Resistive Touch Screen C=With Capacitive Touch Screen N=Without Touch Screen 0=RS232... -
Page 22: International Certification
International Certification This chapter contains the certification we passed: - CE Certificate - ROHS Certificate - FCC Certificate - ISO9001:2008 Quality System CE Certificate FCC Certificate RoHS Certificate ISO9001:2008 STWI050WT-01 Equipment Manual Release 05/2021 www.stoneitech.com... -
Page 23: Appendix
APPENDIX APPENDIX ESD Guidelines What does ESD mean? Virtually all present-day modules incorporate highly integrated MOS devices or components. For technological reasons, these electronic components are very sensitive to overvoltages and consequently therefore to electrostatic discharge: These devices are referred to in German as Elektrostatisch Gefährdeten Bauelemente/ Baugruppen: º... - Page 24 APPENDIX Handling ESD assemblies A general rule is that assemblies should be touched only when this cannot be avoided owing to the work that has to performed on them. Under no circumstances should you handle printed-circuit boards by touching device pins or circuitry. You should touch devices only if ●...
-
Page 25: Glossary
Glossary Baud rate Rate of speed at which data is downloaded. Baud rate is specified in Bit/s. Boot A loading process which downloads the operating system in the working memory of the operating unit. Command Set Hex Code, the MCU can control the TFT Module via the command set. Configuration file It can be created by the softwares. - Page 26 Glossary Flash memory Programmable memory which can be electrically deleted and written to again segment- by-segment. Half Brightness Life The period of time after which the brightness tube only achieves 50% of the original value. Input field Enables the user to enter values which are subsequently sent to the MCU. Micro Control Unit, it is widely used in the industrial control.
- Page 27 Glossary Output field Displays current values from the MCU on the operating unit. Process screen The display of process values and process progress on the operating unit in the form of screens, which may contain graphics, texts and values. RS485 Standard interface for serial data transfer at a very high transmission rate.
