Probes for Digital Thermohygrometer SK-110TRH-B
Read this manual thoroughly before use, and keep it for future reference.

Names of Sections

Plug-in Probe for SK-110TRH-B: Model S110TRH-10
① Probe part
② Connector to the main unit
Wired Probe for SK-110TRH-B: Model S110TRH-20
① Probe part
② Cable
③ Connector to the main unit
Telescoping Probe for SK-110TRH-B: Model S110TRH-30
① Probe part
② Cable
③ Connector to the main unit
Flexible Probe for SK-110TRH-B: Model S110TRH-40
① Probe part
② Cable
③ Connector to the main unit

How to Use

Connection of Probe:
While the main unit is turned off, insert the connector of the probe straight into
the probe connector on the main unit so that an arrow mark on the probe faces
frontward. Turn the nut on the probe next until the probe is fixed.
Do not turn black elastic parts.
Refer to the manual for the main unit of SK-110TRH-B as well.
Sensor Filter:
An optional sensor filter sold separately can cover S110TRH-10/20 to resist a dusty environment.
Cautions
To use the probes for SK-110TRH-B properly, follow the instructions below.
Do not use the probe in any non-standard atmosphere or submerged in liquids.
Do not touch the humidity sensor with hands.
Do not store in bubble buffers or antistatic bags, which have a distinctive color such as blue, pink, or rose pink in
general. It may damage the humidity sensor.
If the probe gets condensed with moisture, turn the power off immediately and dry it naturally under room temperature
before use.
Be sure not to burn yourself when measuring high temperature.
Do not wet, give a heavy shock to, forcibly pull, disassemble, or customize the probe.
For repair or calibration, contact us or a retailer from which you have purchased.
