- Page 1 Three phase hybrid inverter Quick Installation Guide SV 5KHT-G2 / SV 6KHT-G2 SV 8KHT-G2 / SV 10KHT-G2 SV 12KHT-G2 English...
-
Page 3: General Information
GENERAL INFORMATION This quick installation guide does not replace the description in the user manual. The contents of this guide may be updated or revised due to product development. The information in this guide is subject to change without notice. The latest version of this document and the manual for installation, commissioning, configuration and decom- missioning are to be found in PDF format at www.skyworthpv.com. - Page 4 The product must only be operated in connection with an intrinsically safe lithium-ion battery approved by Boneng. The entire battery voltage range must be completely within the permissible input voltage range of the product. The product must only be used in countries for which it is approved by Boneng and the grid operator.
- Page 5 DANGER ！ Danger to life due to electric shock when touching live components in backup mode！ Even if the AC breaker and the PV switch of the inverter are disconnected, the parts of the system may still be live when the battery is switched on due to backup mode. •...
- Page 6 DANGER ！ Danger to life due to electric shock when touching live system compo- nents in case of a ground fault！ If a ground fault occurs, parts of the system may still be live. Touching live parts and cables may result in death or lethal injuries due to electric shock. •...
- Page 7 2.3 Symbols on the label Beware of a danger zone！ This symbol indicates that the product must be additionally grounded if additional grounding or equipotential bonding is required at the installation site. Beware of high voltage and operating current！ The inverter operates at high voltage and current. Work on the inverter must only be carried out by skilled and authorized electricians.
-
Page 8: System Wiring Diagram
SYSTEM WIRING DIAGRAM SV 5-12KHT-G2... - Page 9 SV 5-12KHT-G2...
-
Page 10: Eu Declaration Of Conformity
EU DECLARATION OF CONFORMITY Within the scope of the EU directives Radio Equipment Directive 2014/53/EU (L 153/62-106. May 22. 2014) (RED) Restriction of the use of certain hazardous substances 2011/65/EU (L 174/88, June 8, 2011) and 2015/863/EU (L 137/10, March 31,2015) (RoHS) Shenzhen Boneng Photovoltaic Technology Co., Ltd. -
Page 11: Scope Of Delivery
Object Description Battery Port DC-switch LED指示灯 指示逆变器当前的工作状态 PV Input Ai-Dongle Communication ports AC connector EPS connector Additional grounding screw SCOPE OF DELIVERY AC connector ×1 AC connector ×1 (10-12kH) Wall Bracket ×1 Terminal ×5 Inverter×1 DC connector ×2/3 Battery connector ×1 Ai-Dongle ×1 Fastener Communication... - Page 12 ＞75° √ √ √ × × × × +60℃ -25℃ IP66 4K4H ≤100% max.4000m ≥500mm ≥500mm ≥500mm DIMENSIONS Unit：mm 2-φ9 4-9×17 （ Lumbar foramen） SV 5-12KHT-G2...
- Page 13 MOUNTING Φ10 mm 90° 70mm 10mm 5N·m · SV 5-12KHT-G2...
- Page 14 SECOND PROTECTIVE GROUNDING L=E+(2~3)mm L · AC CONNECTION 4mm²~6mm² 12.5~17.5mm SV 5-12KHT-G2...
- Page 15 × 4.5mm √ 4.09mm √ 3.38mm √ 4.20mm 3.64mm √ 3.92mm √ 3.10mm click 1.2±0.1N·m SV 5-12KHT-G2...
- Page 16 click 2000±50 Connector Object icon Line color number brown black grey blue yellow-green EPS CONNECTION 4mm²~6mm² 12.5~17.5mm SV 5-12KHT-G2...
- Page 17 × 4.5mm √ 4.09mm √ 3.38mm √ 4.20mm 3.64mm √ 3.92mm √ 3.10mm click 1.2±0.1N·m SV 5-12KHT-G2...
- Page 18 click PV CONNECTION TYPE 1 - Phoenix Contact click 2.5-6mm Φ - 5 8mm √ × TYPE 2 2.5-6mm Φ - 5 8mm SV 5-12KHT-G2...
-
Page 19: Battery Connection
BATTERY CONNECTION 10mm² /8AWG Φ6.4-8.5mm SV 5-12KHT-G2... -
Page 20: Communication Setup
COMMUNICATION SETUP 15.1 Communication connection RJ45-1 RJ45-3 RJ45-5 Terminal-1 Terminal-2 Terminal-3 RJ45-2 RJ45-4 RJ45-6 Terminal-4 SV 5-12KHT-G2... - Page 21 PIN definition Object Description Terminal Monitor COM2 RS485A RS485B RS485A RS485B RJ45-3 RJ45-4 COM5 CANAH CANAL X RS485A RS485B PIN Definition Object Description Terminal Multifunction Relay 1 Multifunction Relay 2 Terminal-1 4pin DO1/DO2 PT100 Temperture Sensor Smart Meter UFR Device 6pin Terminal-2 Negative...
- Page 22 15.2 Current Transformer connection (optional) BATTERY RJ45-1 RJ45-3 RJ45-5 GRID Terminal-1 Terminal-2 Terminal-3 COM0 LOAD RJ45-2 RJ45-4 RJ45-6 Terminal-4 1 2 3 4 5 6 Black Arrow pointing to inverter Grid SV 5-12KHT-G2...
- Page 23 15.3 Smart meter connection (optional) BATTERY RJ45-1 RJ45-3 RJ45-5 GRID Terminal-1 Terminal-2 Terminal-3 COM0 LOAD RJ45-2 RJ45-4 RJ45-6 Terminal-4 RS485A RS485B Smart Inverter Meter Grid Grid SV 5-12KHT-G2...
- Page 24 15.4 Ai-Dongle connection √ × SV 5-12KHT-G2...
- Page 25 CONTACT Please contact our Service Department if you have any technical questions about our products. The following information is needed to provide necessary assistance: ——Inverter model ——Inverter serial number ——Photovoltaic module model ——Photovoltaic modules number and strings number connected to each MPPT ——Fault code ——Installation location Shenzhen Boneng Photovoltaic Technology Co., Ltd.
