- Page 1 OPERATING MANUAL for AC LOAD BANK type HAC415-200 with iHHC3 hand held controller ISSUE 2 ...
-
Page 2: Table Of Contents
The information contained in this document is considered correct at the time of printing and given in good faith. Hillstone Products bears no responsibility for the accuracy of the data given or any responsibility resulting from the use of the ... -
Page 3: Introduction
INTRODUCTION The load bank HAC415-200 is designed for testing 415 volt, three phase, 50 Hz UPS or generators on a 4 wire, star, connection, plus earth. The user features of this load bank includes ... -
Page 4: Safety Considerations
OMHAC415-200 SAFETY CONSIDERATIONS The unit should only be operated by a competent person who is completely ● familiar with the operation and specification of the load bank. The equipment is designed for AC operation @ 50Hz only and therefore must not ●... -
Page 5: Connection Diagram
OMHAC415-200 CONNECTION DIAGRAM 5 ... -
Page 6: Operating Instructions
OMHAC415-200 OPERATING INSTRUCTIONS Before carrying out the following operating instructions operators should read the SAFETY CONSIDERATIONS and CONNECTION PROCEDURE Ensure all panels are in place on the load bank. Ensure all panel mounted switches are in the OFF position. -
Page 7: Controlling The Load Bank With The Ihhc3 Controller
OMHAC415-200 CONTROLLING THE LOAD BANK WITH THE iHHC3 CONTROLLER Select the appropriate load using the iHHC3 hand held controller as follows; 1. The hand held controller counts down from 7 to 0 when first powered up and displays: Number of multiple Load Banks that can be ... -
Page 8: Specification
OMHAC415-200 SPECIFICATION Type ref HAC415-200 Max operating voltage 415 V three phase 4 wire plus earth Operating voltage tolerance +6%, -10%, based on nominal 415V Nominal current rating ... -
Page 9: Maintenance Procedures
OMHAC415-200 MAINTENANCE PROCEDURES The load bank should not require any special maintenance, however as with any electrical equipment periodic checks should be carried out to ensure the equipment is in a safe and satisfactory condition. ...
