Shenyang Shicheng Printing Machinery Co., Ltd.
OPERATING INSTRUCTIONS
for the heat press
MEM TQB-4050
Congratulations on purchasing a MEM heat press!
Please read these operating instructions carefully so you can start production with your press
without problems. Reproduction of these operating instructions in any form requires the written
approval of MEM. We reserve all rights to change technical data and product features.
MEM does not assume any liability for direct or indirect damage resulting from use of this
product.
Version 1.2 (09.06.2022)
sales@cnmem.cn
| +86 13889380068
MEM (Shenyang Shicheng Printing Machinery Co., Ltd.) |
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MEM TQB-4050
Summary of Contents for MEM TQB-4050
- Page 1 Reproduction of these operating instructions in any form requires the written approval of MEM. We reserve all rights to change technical data and product features. MEM does not assume any liability for direct or indirect damage resulting from use of this product.
-
Page 2: Brief Overview
Do not open the cover or attempt to modify the machine yourself without instruction. In case you are requested by the MEM customer support to open the heating plate cover, please make sure you are wearing respiratory protection and only touch the contained insulation wool with gloves. -
Page 3: Machine Description
Heat plate Bottom platen & platen cover Air reducing valve for left right movement control (do not adjust) k. Oil buffer Stand m. Height adjustable foot n. Foot pedal sales@cnmem.cn | +86 13889380068 MEM (Shenyang Shicheng Printing Machinery Co., Ltd.) |... - Page 4 (reset after power off) function that counts the number of transfers that have already been made during the current session could be enabled, contact MEM for counter function enable instruction. Press and hold SET button to enter parameter setting interface, press and hold SET button to exit parameter setting interface.
-
Page 5: Operation
Operation Pneumatic connection TQB-4050 requires air compressor with minimum 1500w (2 hp) and 60L (15 gallon) hold tank. Connect 5mm inner diameter (usually 8mm outer diameter) air hose to the machine. Charge the compressor to 0.6-0.7 Mpa, up to 0.8 Mpa (120 psi) if possible. -
Page 6: Maintenance And Cleaning
Time Range 0-999sec. Max. Temp. 260°C / 500°F Heat plate size 40x50cm (16"x20") Dimensions(L*W*H) 1080*730*590mm (42"x28"x23") Shipping Dimensions(L*W*H) 1230*770*690mm (49"x31"x28") Shipping Weight 145kg (320lbs) Max. press thickness 40mm sales@cnmem.cn | +86 13889380068 MEM (Shenyang Shicheng Printing Machinery Co., Ltd.) |... -
Page 7: Circuit Diagram
Circuit diagram sales@cnmem.cn | +86 13889380068 MEM (Shenyang Shicheng Printing Machinery Co., Ltd.) |... -
Page 8: Statement Of Conformity
Related Standards: EN ISO 12100:2010, EN 60204-1:2018 RoHS test We herewith declare that the product conforms to RoHS Directive 2011/65/EU Annex II amending Annex (EU)2015/863 and amending Annex (EU)2017/2102. Report No.: B-R2203A0560 sales@cnmem.cn | +86 13889380068 MEM (Shenyang Shicheng Printing Machinery Co., Ltd.) |...
