DALCNET CBU MASTER Device Manual

➢ PRODUCT CODE
CODE
CBU-MASTER-DALI-IP
CBU-MASTER-DMX-IP
CBU-REPEATER-IP
The management of Addresses (DALI Variant) or Channels (DMX Variant) depends on the Casambi module configuration.
➢ PROTECTION
OVP Over voltage protection
IFP Input fuse protection
➢ TECHNICAL SPECIFICATION
Nominal Voltage
Voltage Range
Mains Frequency
1
Nominal Power @230V
Power loss in standby mode
Operating Frequencies 2
Maximum output power 2
Storage Temperature
Ambient Temperature 1
Type of connector
Wiring of connector
Wire strip lenght
Clamping range of cable gland
Protection grade
Mechanical dimensions
Casing material
Weight
I out (only for DALI)
V out (only for DALI)
1
Maximum value, dependent on the ventilation conditions.
2
The parameters are derived from the configuration of the Casambi module.
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 – 36077 Altavilla Vicentina (VI) – Italy
VAT: IT04023100235 – Tel. +39 0444 1836680 -
CBU MASTER BUS & CBU REPEATER
Device Manual
Input Voltage
230Vac
230Vac
230Vac
Guaranteed current to the bus = 150mA / Max bus current = 250mA
Headquarters: Via Lago di Garda, 22 – 36077 Altavilla Vicentina (VI) – Italy
FEATURES
• CONVERTER+CASAMBI+BUS
• REPEATER CASAMBI
• Input: 230Vac
• Command: APP CASAMBI
• CASAMBI FUNCTION: SMART SWITCHING
• Signal converter from Casambi to DALI o DMX, in MASTER Variant
• Signal repeater, in REPEATER Variant
• Possibility to control DALI or DMX device, by Casambi APP
• Extended temperature range
• 100% Functional test – 5 Years warranty
Input Command Output Command
APP CASAMBI
APP CASAMBI
APP CASAMBI
CBU-MASTER-DALI/DMX
✓
✓
CBU MASTER & CBU REPEATER
230 Vac
100...240 Vac
50/60 Hz
3W max
<500mW
2402 – 2480 MHz
7dBm
min: -40 – max: +60 °C
min: -25 – max: +60 °C
Plug-In Screw Terminals
Power: 2,5mm 2 solid & stranded – 30/12 AWG
2
Bus: 1,5mm solid & stranded – 30/14 AWG
Power: 7,5mm / Bus: 6mm
min: 5mm – max: 10mm
IP66
90 x 90 x 65 mm
Plastic
88g
Only for BUS DALI
15V
www.dalcnet.com
DALI (DT6 – DT8)
DMX
REPEATER
REPEATER
– info@dalcnet.com
Made in Italy
Rev.10/01/2024
Pag.1 / 15
CONVERTER
CONVERTER
REPEATER
✓
✓
