➢ PRODUCT CODE
CODE
CBU-REPEATER-USB
Address management (DALI Variant) or Channels (DMX Variant) depends on the configuration of the Casambi module.
➢ TECHNICAL SPECIFICATIONS
Supply voltage
Voltage Range
Nominal Power
Storage temperature
Ambient temperature
IP Protection grade
Mechanical dimensions
Casing material
Weight
➢ MECHANICAL DIMENSIONS
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 – 36077 Altavilla Vicentina (VI) – Italy
VAT: IT04023100235 – Tel. +39 0444 1836680 -
CBU REPEATER USB
Device Manual
Input voltage
5Vdc
Headquarters: Via Lago di Garda, 22 – 36077 Altavilla Vicentina (VI) – Italy
➢
FEATURES
1. REPEATER CASAMBI
2. Input: 5Vdc
3. Command: APP CASAMBI
4. Signal repeater
5. Extended temperature range
6. 100% Functional Test – 5 Year Warranty
Input command
Outgoing command
APP CASAMBI
CBU REPEATER USB
5 Vdc
2 – 5.5 Vdc
0,125W max
min: -40 max: +60 °C
min: -25 max: +60 °C
IP20
10x 71.3x 24.3mm
Plastic
15g
www.dalcnet.com
REPEATER
REPEATER
–
info@dalcnet.com
Made in Italy
Rev. 31/05/2023
Pag.1 / 3
Advertisement
Related Manuals for DALCNET CASAMBI CBU-REPEATER-USB
Summary of Contents for DALCNET CASAMBI CBU-REPEATER-USB
- Page 1 Weight ➢ MECHANICAL DIMENSIONS DALCNET S.r.l, Registered office: Via Lago di Garda, 22 – 36077 Altavilla Vicentina (VI) – Italy Headquarters: Via Lago di Garda, 22 – 36077 Altavilla Vicentina (VI) – Italy VAT: IT04023100235 – Tel. +39 0444 1836680 - www.dalcnet.com...
- Page 2 The discharge time of the power supply secondary depends on the construction characteristics of the power supply used. DALCNET S.r.l, Registered office: Via Lago di Garda, 22 – 36077 Altavilla Vicentina (VI) – Italy Headquarters: Via Lago di Garda, 22 – 36077 Altavilla Vicentina (VI) – Italy VAT: IT04023100235 –...
- Page 3 To guarantee the end user the best performance and correct operation, functional testing is carried out on 100% of the devices. If the device has remained associated with the Dalcnet test network, please decouple the device by following the information provided in the Casambi APP and in the paragraph "UNPAIR THE DEVICE FROM THE CASAMBI...
