Toto EGO TX721AE Quick Start Manual

SPECIFICATIONS

18
Ø6
Ø6
69
50
Ø24
67
Ø24
TX 721AEZ
"EGO" Sliding Rail w/ Elbow, Flexible
"EGO " Sliding Rail (L= 625mm)

OPERATING CONDITIONS

1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).

MAINTENANCE

Always wipe chrome plated area with dry soft cloth,
and sometimes wipe it with cloth soaked in mild soap.
ATTENTION
1. Don t use abrasive cleaning material such as; detergents
containing hydrochloric acids, thinner, polishing powder,
and nylon brush.
2. Flow regulator should not be remove because it could
damage the system
3. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
S06210Z

INSTALLATION

1
18
69
50
67
3
Sleeve
TX 721AEV3
Anchor
Hose & Hand Shower
Bracket
Screw
5
Pipe
Hanger
"EGO" SLIDING RAIL (L=625mm) TX721AE
2
Ø6 Holes
Drill
Pen
Bracket
Water Supply
4
Water Supply
Cover
Use Seal Tape
(Not Include)
Elbow
6
Screw
Body

TROUBLESHOOTING

PROBLEM
Unsatisfactory spray
Water leaks around the hose
1. NOZZLES
Flow Regulator Inside
(Don t remove)
Hand
Shower
Packing
Packing
Flexible
Hose
CHECK
SOLUTION
POINT
1 Clean
2 , 3 Tighten
3. NUT
2. NUT
R15
