funtec 111206 User Manual

Pro beach net posts
Hide thumbs

Advertisement

Quick Links

Download this manual
N U A L
U S E R M A
P R O B E A C H
N E T P O S T S

Advertisement

loading
Need help?

Need help?

Do you have a question about the 111206 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for funtec 111206

Summary of Contents for funtec 111206

  • Page 1 N U A L U S E R M A P R O B E A C H N E T P O S T S...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS USER MANUAL FOR BEACH VOLLEYBALL NET POSTS PRO BEACH GENERAL INFORMATION FREESTANDING ITEM-NO.: 111206 - WITH CITY BEACH SOCKETS FIXED ITEM-NO.: 111205 - WITH BOLT-DOWN SOCKETS FLEXIBLE ITEM-NO.: 111204 - WITH REMOVABLE SOCKETS NET INSTALLATION & COURTLINE...

  • Page 3: General Information

    GENERAL INFORMATION Please read carefully before assembly or use and retain for future use! Safety instructions • This product is designed for use at competitions and at top-class sports. • This product may only be used for its intended purpose, namley for volleyball or similar sports. •...

  • Page 4: Freestanding

    BEACH VOLLEYBALL POSTS FREESTANDING PRO BEACH ITEM-NO.: 111206 - WITH FREESTANDING GROUND SOCKETS („CITY BEACH“) Pro Beach net posts made from powdercoated special alu- minium profile (91 x 91 mm), telescopic height adjustment with special socket adapters Single-arm suspension, allows easy mounting of net tension cable.
  • Page 5 SCOPE OF DELIVERY FREESTANDING ITEM-NO.: 111206 Net post with pulley block tensioning Net post with counter slider Pro Beach socket with T-base slider Minimum sand level (35 cm)
  • Page 6 NOTICE! FREESTANDING ITEM-NO.: 111206...
  • Page 7 INSTALLATION STEPS FREESTANDING ITEM-NO.: 111206 General information on building beach volleyball courts: When building a sand court we suggest to fill up the sand first of all. Afterwards you can just dig in the freestanding City Beach ground sockets and set up the net system. We consider a permanent sand level of 40-50 cm as ideal. It is recommended to fill the sand higher towards the centre of the two halves of the court.
  • Page 8 INSTALLATION STEPS FREESTANDING ITEM-NO.: 111206 Excavate sand according to outlines Place the ground sockets with the wood beams in the excavation, keeping a distance from it so that the sand edges do not collapse Minimum: 35 cm Align the sockets with each other - it is helpful to insert the The sockets are already inclined outwards by 2°...
  • Page 9 ACCESSORIES FREESTANDING ITEM-NO.: 111206 Square wood beams, 6-piece, for 1 pair Pro Beach net PLUS, incl. net antennas PLUS, 2-piece, with velcro strap of net posts, Item-No.: 111232 net holders, Item-No.: 111601 Pro Beach courtline Item-No.: 111304 Post pads, square-cut (100 x 100 mm), 1 pair...

  • Page 10: Fixed

    BEACH VOLLEYBALL POSTS FIXED PRO BEACH ITEM-NO.: 111205 - WITH BOLT-DOWN SOCKETS Pro Beach net posts made from powdercoated special alu- minium profile (91 x 91 mm), telescopic height adjustment with special socket adapters Single-arm suspension, allows easy mounting of net tension cable.
  • Page 11 SCOPE OF DELIVERY FIXED ITEM-NO.: 111205 Net post with pulley block tensioning Net post with counter slider Pro Beach socket with bolt-down base slider Minimum sand level (35 cm)
  • Page 12 NOTICE! FIXED ITEM-NO.: 111205...
  • Page 13 INSTALLATION STEPS FIXED ITEM-NO.: 111205 General information on building beach volleyball courts: When building a sand court we suggest to fill up the sand first of all. Afterwards you can just dig in the freestanding City Beach ground sockets and set up the net system. We consider a permanent sand level of 40-50 cm as ideal. It is recommended to fill the sand higher towards the centre of the two halves of the court.
  • Page 14 ACCESSORIES FIXED ITEM-NO.: 111205 Steel ground anchor, with mortar Pro Beach net PLUS, incl. net antennas PLUS, 2-piece, with velcro strap cartridge, Item-No.: 111213 net holders, Item-No.: 111601 Download installation info Pro Beach courtline Item-No.: 111304 Post pads, square-cut (100 x 100 mm), 1 pair Item-No.: 111353...

  • Page 16: Flexible

    BEACH VOLLEYBALL POSTS FLEXIBLE PRO BEACH ITEM-NO.: 111204 - WITH REMOVABLE SOCKETS Pro Beach net posts made from powdercoated special alu- minium profile (91 x 91 mm), telescopic height adjustment with special socket adapters Single-arm suspension, allows easy mounting of net tension cable.
  • Page 17 SCOPE OF DELIVERY FLEXIBLE ITEM-NO.: 111204 Net post with pulley block tensioning Net post with counter slider Pro Beach Bodenhülse, removable slider...
  • Page 18 NOTICE! FLEXIBLE ITEM-NO.: 111204...
  • Page 19 INSTALLATION OPTIONS FLEXIBLE ITEM-NO.: 111204 FREESTANDING FIXED Switch ground plate with T-base, incl. sand protection frame Switch bolt-down ground plate, incl. sand protection frame and a 3-piece plastic cover, Item-No.: 111220 and a 3-piece plastic cover, Item-No.: 111219 Square wood beams, 6-piece, for 1 pair of net posts Steel ground anchor, with mortar cartridge Item-No.: 111232 Item-No.: 111213...
  • Page 20 INSTALLATION STEPS FREESTANDING FLEXIBLE ITEM-NO.: 111204 General information on building beach volleyball courts: When building a sand court we suggest to fill up the sand first of all. Afterwards you can just dig in the freestanding City Beach ground plates with sockets and set up the net system. We consider a permanent sand level of 40-50 cm as ideal. It is recommended to fill the sand higher towards the centre of the two halves of the court.
  • Page 21 INSTALLATION STEPS FREESTANDING FLEXIBLE ITEM-NO.: 111204 Excavate sand according to outlines Place the ground sockets with the wood beams in the excavation, keeping a distance from it so that the sand edges do not collapse Minimum: 40 cm Align the sockets with each other - it is helpful to insert the The sockets are already inclined outwards by 2°...
  • Page 22 INSTALLATION STEPS FIXED FLEXIBLE ITEM-NO.: 111204 General information on building beach volleyball courts: When building a sand court we suggest to fill up the sand first of all. Afterwards you can just dig in the freestanding City Beach ground sockets and set up the net system. We consider a permanent sand level of 40-50 cm as ideal. It is recommended to fill the sand higher towards the centre of the two halves of the court.
  • Page 23 INSTALLATION STEPS FIXED FLEXIBLE ITEM-NO.: 111204 Distance and orientation of ground plates 10 m for a 8.5 m net/ 11 m for a 9.5 m net INNENSEITE/ INSIDE Screw down the sockets onto the foundation Close the safety latch and install plastic cover Download installation info Required for installation:...
  • Page 24 ACCESSORIES FLEXIBLE ITEM-NO.: 111204 Pro Beach net PLUS, incl. net antennas PLUS, 2-piece, with velcro strap Pro Beach courtline net holders, Item-No.: 111601 Item-No.: 111304 Post pads, square-cut (100 x 100 mm), 1 pair Item-No.: 111353...

  • Page 26: Net Installation

    NET INSTALLATION Connect head band net cable to carabiner of the pulley tensioning system...
  • Page 27 NET INSTALLATION Install net cable to opposite side and apply some pre-tension by hand Pull the red pulley rope to achieve the required net tension...
  • Page 28 NET INSTALLATION On both sides: use red ropes to centre the net between the posts On both sides: tighten the bottom net cord and bring the net into a vertical position...
  • Page 29 COURTLINE ASSEMBLY ITEM-NO.: 111304 Pro Beach courtline Overview Item-No.: 111304 16 m/18 m 8 m/9 m Freely adjustable, with markings for 8 x 16 m and 9 x 18 m Assembly guide: 1. Thread strap through at the bottom side 2.

  • Page 30: Spare Parts

    SPARE PARTS Description Item-No. Pulley tensioning slider for Pro Beach posts 206-200 Elastic cord, 8 mm diameter, red 206-215 Top-block with stainless steel carabiner 206-217 Pulley rope, made from polyester 206-218 Tensioning counter slider for Pro Beach posts 206-300...
  • Page 31 • Model: 111206 – Beach Volleyball posts Pro Beach (CB = City Beach), with freestanding sockets (for use with square timber beams) • Model: 111205 – Beach Volleyball posts Pro Beach (BD = Bolt Down), with bolt-down sockets (for an installation on a concrete foundation) •...
