USER MANUAL
Beach volleyball posts
BEACH CHAMP
ID: 111203

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BEACH CHAMP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for funtec BEACH CHAMP

  • Page 1 USER MANUAL Beach volleyball posts BEACH CHAMP ID: 111203...
  • Page 2 + freestanding Ground plates with Square timbers Bolt-down sockets Switch + concrete Foundation - Removable sockets + Bolt-Down Ground plates Spare parts FUNTEC Sports GmbH www.funtec.de | Loehestr. 25 | DE - 53773 Hennef | +49 2242 3231 | info@funtec.de...
  • Page 3: General Information

    Any damaged parts should - The ideal storage location is dry with a temperature be replaced as soon as possible. between 10 and 25° C. FUNTEC Sports GmbH www.funtec.de | Loehestr. 25 | DE - 53773 Hennef | +49 2242 3231 | info@funtec.de...
  • Page 4: Beach Volleyball

    Beach volleyball posts Beach Champ ID: 111203 Overview Beach Champ net posts made from powdercoated special aluminium profile (91 x 91 mm) With single-arm suspension allows easy mounting of tension cable Rope pulley with triple block combination including a stainless steel carabiner with wire gate (for one-...
  • Page 5: Scope Of Delivery

    Scope of delivery ID: 111203 Beach Volleyball posts Net post with Net post with Beach Champ tackle tensioning slider tensioning counter slider...
  • Page 6 Floor mounting options FOR ID: 111203 City Beach socket Freestanding ground socket to be installed with square timbers Switch Socket + Ground plate City Beach Removable socket + Freestanding ground plate with square timbers Bolt-Down socket Ground socket with bolt-down base for installation on a concrete foundation Switch Socket + Bolt-Down Ground plate...
  • Page 7 Assembly OPTION: CITY BEACH General information on building a Beach Volleyball court with City Beach sockets: When building a sand court we suggest to fill up the sand first of all. Afterwards you can just dig in the City Beach ground sockets and set up the net system.
  • Page 8 Assembly OPTION: CITY BEACH Set ground sockets with timbers into excavation; be careful Align the sockets with each other - inserting the net poles not to step onto the borders of the excavation will be helpful Minimum: 35 cm The sockets are designed with a 2° sloping angle to the outwards.
  • Page 9: Accessories (Sold Separately)

    Option: City BEach ACCESSORIES (SOLD SEPARATELY) Pro Beach Courtline Beach Volleyball socket City Beach, Square timber set ID: 111211 ID: 111232 ID: 111304 Pro Beach net PLUS, incl. net antennas PLUS Square-cut Beach Volley post pads (100 x 100 mm), (2-piece, with velcro strap pockets), ID: 111601 1 pair, ID: 111353...
  • Page 10 Option: Switch + City BEach REQUIRED ACCESSORIES (SOLD SEPARATELY) Beach Volleyball socket Switch, Switch ground plate with T-base, incl. sand protection frame removable, ID: 111210 and a 3-piece steel cover lid, ID: 111220...
  • Page 11 Assembly OPTION: SWITCH + CITY BEACH General information on building a Beach Volleyball court with City Beach ground plates: When building a sand court we suggest to fill up the sand first of all. Afterwards you can just dig in the City Beach ground sockets and set up the net system.
  • Page 12 Assembly OPTION: SWITCH + CITY BEACH Set ground sockets with timbers into excavation; be careful Align the sockets with each other - inserting the net poles not to step onto the borders of the excavation will be helpful Minimum: 40 cm The sockets are designed with a 2°...
  • Page 13 Option: Switch + City BEach ACCESSORIES (SOLD SEPARATELY) Square timber set Pro Beach net PLUS, incl. net antennas PLUS ID: 111232 (2-piece, with velcro strap pockets), ID: 111601 Pro Beach Courtline Square-cut Beach Volley post pads (100 x 100 mm), ID: 111304 1 pair, ID: 111353...
  • Page 14 Assembly OPTION: CONCRETE FOUNDATION General information on building a Beach Volleyball court with bolt-down socket: We consider a permanent sand level of 40-50 cm as ideal. It is recommended to fill up the sand a little bit higher at the centres of the playing field halves.
  • Page 15 Option: Concrete Foundation ACCESSORIES (SOLD SEPARATELY) Pro Beach Courtline Socket with bolt-down base Steel ground anchor, with mortar ID: 111212 cartridge, ID: 111213 ID: 111304 Pro Beach net PLUS, incl. net antennas PLUS Square-cut Beach Volley post pads (100 x 100 mm), (2-piece, with velcro strap pockets), ID: 111601 1 pair, ID: 111353...
  • Page 16 Option: Switch + Concrete Foundation REQUIRED ACCESSORIES (SOLD SEPARATELY) Beach Volleyball socket Switch, Switch bolt-down ground plate, incl. sand protection frame removable, ID: 111210 and a 3-piece steel cover lid, ID: 111219...
  • Page 17 Assembly OPTION: CONCRETE FOUNDATION Minimum Sand level: 30 cm Create foundations with a closed surface, Distance (clear span between sockets): 10 m with a 8.5 m net, 11 m with a 9.5 m net Description Foundation, Dimensions: 80 x 80 x 80 cm, class C25/30, built-in welded wire fabric (Q188A) Ground socket, bolted down on the concrete foundation Distance (clear span): 10 m (with a 8.5 m net), 11 m (with a 9.5 m net) Sand (minimum sand level: check red marking)
  • Page 18 Option: Switch + Concrete Foundation REQUIRED ACCESSORIES (SOLD SEPARATELY) Steel ground anchor, with mortar Pro Beach net PLUS, incl. net antennas PLUS cartridge, ID: 111213 (2-piece, with velcro strap pockets), ID: 111601 Pro Beach Courtline Square-cut Beach Volley post pads (100 x 100 mm), ID: 111304 1 pair, ID: 111353...
  • Page 19: Spare Parts

    Beach volleyball posts Beach Champ SPARE PARTS Description Tackle tensioning slider for Beach Champ posts 203-200 Elastic cord, 8 mm diameter, colour: red 206-215 Top-block with stainless steel carabiner 206-217 Tackle tensioning cord, made from Polyester 206-218 Tensioning counter slider for Beach Champ posts...
  • Page 20 www.funtec.de...
