Parts - U-Line U-CO1224FB-00B User Manual & Service Manual

Parts

1
14 17
40 28
15 16
12
27
19
21
2
* Reed switch is located
behind the display on
30
models built after
10/1/2020.
7
6
18 29
8
34*
23
26
38
11
31
25
34*
Item
22
1 Anti tip bracket w/screws
2 Back panel
35 36
3 Compression nut/sleeve
4 Compressor electricals only
5 Compressor w/electricals
6 Condenser assembly
7 Condenser fan w/screws
8 Display module
9 Door assembly w/hinges
10 Drain pan heater
11 Drain pan w/double sided tape
12 Drain pan, evaporator
13 Drier
14 Evaporator fan
15 Evaporator assembly
16 Evaporator cover w/screws
17 Evaporator fan cover w/screws 80-54311-00
18 Freezer door assembly
19 Freezer hinge assembly
20 Gasket, door
21 Glass shelf(1) btm
22 Glass shelf(1) top
23 Grille w/screws
24 Handle w/logo
25 Hinges(2) w/screws
24
26 Hot gas valve and coil
27 Ice bucket
9
20
28 Ice maker assembly
29 LED light strip and cover assy
13
30 Leg Levelers (4)
31 Main board (no case or wires)
32 Packaging
33 Power cord
5
34 Reed switch *
35 Thermistor (1 pc)
4
36 Thermistor cover and pin
37 Water line assembly
38 Water valve assembly
39 Wire harness, board
40 Faceplate 115V
36
U-CO1224FB-00B
Description U-Line P/N
80-54239-00
80-54204-00
80-54355-00
80-54300-00
80-54299-00
80-54301-00
80-54014-00
80-54236-00
80-54298-00
80-54313-00
80-54323-00
80-54361-00
80-54055-00
80-54310-00
80-54306-00
80-54312-00
80-54308-00
80-54307-00
80-54213-00
80-54274-00
80-54304-00
80-54267-00
80-54214-00
80-54208-00
80-54169-00
80-54370-00
80-54360-00
80-54000-00
80-54201-00
80-54008-00
80-54209-00
80-54358-00
80-54284-00
80-54006-00
80-54237-00
80-54357-00
80-54356-00
80-54359-00
80-54523-00
Parts 1
