Christie Hedra Series Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation Guide
020-002115-01
Hedra Standard, Pro-KVM
& Pro-Video
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hedra Series and is the answer not in the manual?

Questions and answers

Related Manuals for Christie Hedra Series

Summary of Contents for Christie Hedra Series

  • Page 1 Installation Guide 020-002115-01 Hedra Standard, Pro-KVM & Pro-Video...
  • Page 2 Christie's control such as maintenance of the product in proper working conditions. Performance specifications are based on information available at the time of printing. Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied warranties of fitness for a particular purpose. Christie will not be liable for errors contained herein or for incidental or consequential damages in connection with the performance or use of this material.

  • Page 3: Table Of Contents

    Content Introduction........................... 5 Important safety information ....................5 Technical support ........................6 The Hedra series ........................7 Available variants ........................7 The Hedra standard ....................... 9 Power requirements ......................9 Scope of delivery ........................9 Preparation .......................... 9 Choosing a location ......................9 Planning the video bandwidth ....................
  • Page 4 Connecting the power supply .................... 23 The Hedra Pro-Video ......................25 Power requirements ......................25 Scope of delivery ......................... 25 Preparation ........................25 Choosing a location ......................25 Planning the video bandwidth .................... 25 Planning the maximum pixel area, number of output monitors and virtual outputs ....26 Connecting HDMI or DVI signals ..................

  • Page 5: Introduction

    Important safety information Read this document carefully before installing or operating the Hedra. For installation, setup, and user information, see the product documentation available from the Christie Digital Systems USA Inc. website at www.christiedigital.com. Read all instructions before using or servicing this product.

  • Page 6: Technical Support

    South Korea: +82 2 702 1601 or tech-Korea@christiedigital.com • Christie Professional Services: +1-800-550-3061 or NOC@christiedigital.com • Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 7: The Hedra Series

    The Hedra series You can display the video signals of multiple sources simultaneously on the monitors connected to the Hedra. Place the monitors according to your requirements and arrange the video signals on the monitors simultaneously required. You can scale and frame each video signal individually and/or define the section to be displayed.
  • Page 8 The Hedra series Pro-KVM Pro-Video None Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 9: The Hedra Standard

    • 1 × installation manual • 2 × power cable (NEMA 5-15) • You can download the Hedra User manual (P/N: 020-002116-XX) on the Christie website at www.christiedigital.com. Preparation Prepare considering the following topics when installing Hedra. Choosing a location...

  • Page 10: Planning The Maximum Pixel Area, Number Of Output Monitors And Virtual Outputs

    (16:10, 2.3 MP) • The maximum available pixel area is 8192×8192. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 11: Connecting Hdmi Or Dvi Signals

    Connecting video inputs Connections for the Hedra standard can be seen below. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 12 30 Hz. All other inputs support signals at HD resolution up to 60 Hz. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 13: Connecting Monitors

    If the monitor you want to use does not support the available connection types, use one or • more optionally available converters where applicable. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 14: Connecting Other Interfaces

    Analogue line-in interface (blue) Streaming Virtual Channel Analogue line-out interface (green) Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 15: Establishing Usb Connections With The Computers

    Use the following details as reference when making power connections to Hedra. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 16 The power supply can be turned on and off at any time as long as logging mode is deactivated. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 17: The Hedra Pro-Kvm

    • • 1 × installation manual • 2 × power cable (NEMA 5-15) You can download the Hedra User manual (P/N: 020-002116-XX) on the Christie website at www.christiedigital.com. Preparation Prepare considering the following topics when installing Hedra. Choosing a location...

  • Page 18: Planning The Video Bandwidth

    4 × 3840×2160 (16:9, 8.3 MP) • 6 × 2560×1600 (16:10, 4.1 MP) Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 19: Connecting Hdmi Or Dvi Signals

    Video input connections for the Hedra standard can be seen below. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 20 UHD video signals with 30 Hz. All other inputs support signals up to HD resolution at 60 Hz. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 21: Connecting Monitors

    Use the following details as reference when making control and audio connections to Hedra standard. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 22 Analogue line-in interface (pink) Streaming Virtual Channel Analogue line-out interface (green) Other Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 23: Establishing Usb Connections With The Computers

    Use the following details as reference when making power connections to Hedra. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 24 The power supply can be turned on and off at any time as long as logging mode is deactivated. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 25: The Hedra Pro-Video

    • • 1 × installation manual • 2 × power cable (NEMA 5-15) You can download the Hedra User manual (P/N: 020-002116-XX) on the Christie website at www.christiedigital.com. Preparation Prepare considering the following topics when installing Hedra. Choosing a location...

  • Page 26: Planning The Maximum Pixel Area, Number Of Output Monitors And Virtual Outputs

    3 × 3840×2160 (16:9, 8.3 MP) and 1 × 2560×1600 (16:10, 4.1 MP) and 2 × 1920× 1200 (16:10, 2.3 • Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 27: Connecting Hdmi Or Dvi Signals

    Connecting video inputs Connections for the Hedra Pro-Video can be seen below. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 28 11,12,13 HDMI 300 MP/s 14,15,16,17 165 MP/s HDMI 165 MP/s Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 29: Connecting Monitors

    If the monitor you want to use does not support the available connection types, use one or • more optionally available converters where applicable. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 30: Connecting Other Interfaces

    Analogue line-in interface (pink) Streaming Virtual Channel Analogue line-out interface (green) Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 31: Connecting The Power Supply

    The power supply can be turned on and off at any time as long as logging mode is deactivated. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 32: Getting Started

    Getting started Instructions for getting started out of the box are presented here. Establish the power supply Power on the Hedra by turning on the power button of at least one power supply unit (Power 1/Power 2). Initial configuration of the network settings Configure the network settings to access the web application of the device.

  • Page 33: How To Configure The Network Settings Of The Device

    Enter the IP address of the DNS server (only if USE DHCP inactive). 7. Select Save. 8. Select Reboot now. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 34: Commissioning

    Using the tabs of the web application, you can set up and manage the device. The User Manual is continuously updated and published on the Christie website at www.christiedigital.com. Follow the instructions in the separate User Manual to successively configure these settings: 1.

  • Page 35: Status Displays

    NOTE: Further information on this topic are identified in a separate manual for operating the device. This manual is continuously updated and published on the Christie website at www.christiedigital.com. Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc.

  • Page 36: Technical Data

    Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 37: Features Of The Video Card

    Min. 16 MP/s; maximum 165 MP/s Input 9: Socket: HDMI socket Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 38 Min. 16 MP/s; maximum 165 MP/s Video bandwidth: Per video card: Maximum 1,200 MP/s Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 39: Hedra Pro-Kvm

    Per video card: Maximum 1,200 MP/s Per system: Up to 4,000 MP/s Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 40: Features Of The Video Cards

    Signal: HDMI H display: Min. 320 pixel; maximum 2560 pixel Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 41 Min. 16 MP/s; maximum 165 MP/s Video bandwidth: Per video card: Maximum 1,200 MP/s Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 42: Hedra Pro-Video

    Up to 4,000 MP/s Other interfaces Network: 1 × RJ45 socket (10/100/1000 MBit/s) Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 43: Features Of The Video Cards

    Min. 16 MP/s; maximum 165 MP/s Video bandwidth: Per video card: Maximum 1,200 MP/s Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 44 Min. 16 MP/s; maximum 165 MP/s Video bandwidth: Per video card: Maximum 1,200 MP/s Hedra Standard, Pro-KVM & Pro-Video Installation Guide 020-002115-01 Rev. 1 (09-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
