Trainor Sports 18201920120US Owner's Manual

12 foot round trampoline and enclosure
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S
MANUAL
MODEL NO.
18201920120US
Assembly
Adjustments
Parts
Warranty
These instructions are important to minimize chances of injury. Please read each of them
thoroughly before you assemble and use this trampoline. Retain this manual for future reference.
Maximum weight of the user shall NOT exceed 220lbs/100kg for this product.
DO NOT attempt somersaults or flips. Paralysis or death can result if you land on your head or
neck!
No more than one person on the trampoline at a time. Multiple users increase the risk of injury.
Use trampoline only with mature, knowledgeable supervision.
12 FOOT ROUND TRAMPOLINE
AND ENCLOSURE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 18201920120US and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trainor Sports 18201920120US

Summary of Contents for Trainor Sports 18201920120US

  • Page 1  OWNER’S  MANUAL   12 FOOT ROUND TRAMPOLINE AND ENCLOSURE  MODEL NO. 18201920120US       Assembly  Adjustments  Parts  Warranty   These instructions are important to minimize chances of injury. Please read each of them thoroughly before you assemble and use this trampoline.
  • Page 2 NO SOMERSAULTS OR FLIPS – No more than ONE user at a PARALYSIS OR DEATH can result if you time(maximum weight - 220 lbs/100 kg). land on your head or neck! Do not use if in a Do not allow Remove all hard Do not use cast or have...
  • Page 3 INTRODUCTION Thank you for purchasing a Trainor Sports product! This trampoline was designed and manufactured with quality materials and craftsmanship, providing fun and exercise in the enjoyment of your own backyard. It is very important that the owners and users of this trampoline have adequate knowledge of techniques and rules for proper use.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Before you start to assemble… ............................ 1 Before using the product… ............................1 Important Warnings ............................... 2 Important Instructions for Enclosure Netting and Mat ....................6 Trampoline and Enclosure Parts List .......................... 8 Assembly and Installation Instructions ........................10 Trampoline Frame Assembly ..........................11 Trampoline Mat Assembly ............................15 Frame Pad Assembly ...............................19...

  • Page 5: Before You Start To Assemble

    Carefully read and understand all of the instructions and warnings in this manual before assembling and using this product. It is the responsibility of the owner of this trampoline to ensure that all users of this product are fully informed on the proper use and the inherent risks of jumping on a trampoline.

  • Page 6: Important Warnings

    Important Warnings Carefully read these warnings before using this product. Failure to follow these warnings can result in serious injury or death.  Only one user at any one time! Multiple users can cause loss of control, collision or falls on the trampoline. ➢...
  • Page 7 Carefully read these warnings before using this product. Failure to follow these safety instructions can result in serious injury or death.  Proper Play Conditions: ➢ Always use the product in a well-lit area. Do not use without lighting during dawn, dusk or in complete darkness!...
  • Page 8 Carefully read these warnings before using this product. Failure to follow these safety instructions can result in serious injury or death.  Appropriate Use Conditions: ➢ Children must always be supervised while they are playing on the trampoline and must be instructed not to use the trampoline in an inappropriate or hazardous manner.
  • Page 9 Carefully read these warnings before using this product. Failure to follow these safety instructions can result in serious injury or death.  ➢ Do not jump or step onto the frame pad as it was not designed to support the weight of a person. Do not use the trampoline while holding or wearing any type of sharp or pointed objects such as jewelry, ➢...

  • Page 10: Important Instructions For Enclosure Netting And Mat

    Important Instructions for Enclosure Netting and Mat Failure to follow these instructions to ensure proper operational condition of  your trampoline may lead to serious injury or death.  1. Maintenance of Trampoline Enclosure Net, Mat and Pad Enclosure nets and padding are prone to wear and tear like tires on a car. Gradual deterioration of the material will occur;...
  • Page 11 Trying to exit in this way poses a risk of strangulation from being caught between the trampoline frame and the netting walls. Do not attach anything to the netting that is not a Trainor Sports approved accessory or part of the trampoline enclosure.

  • Page 12: Trampoline And Enclosure Parts List

    Trampoline and Enclosure Parts List Trampoline Part Part Picture Description Quantity Number Number Trampoline Mat, stitched HJ9201201 with Triangle-Rings HJ9201202 Frame Pad HJ9201203 Top Rail with Leg Sockets HJ9201204 Top Rail HJ9201205 Leg Base Vertical Leg Extensions(one HJ531206A hole) Vertical Leg Extension with HJ9201206B Indented Hole(two holes) HJ9201207...
  • Page 13 Enclosure Key Number Part Picture Description Quantity Upper Frame Tube with Foam Lower Frame Tube with Foam Tube Cap Gap Spacer Bolt Cap Nut Large Spring Lock Washer Arc Washer Wrench Allen Wrench Cord Enclosure Netting Enclosure Safety Instruction Placard End Cap Customer Service 1-888-707-1880 Dyaco Canada Inc.2019...

  • Page 14: Assembly And Installation Instructions

    Assembly and Installation Instructions Review all steps before assembly and read all precautions before using this product. Failure to do so can result in serious injury or death. During periods of non-use, this trampoline and trampoline enclosure can be easily disassembled and stored by reversing the order of installation.

  • Page 15: Trampoline Frame Assembly

    Trampoline Frame Assembly BEFORE YOU BEGIN: Review all steps before assembly and read all precautions before using the trampoline. At least two adults are required to assemble this trampoline. Protective gloves should be used during assembly to avoid injuries during installation. Goggles should be worn to avoid injuries to the eyes. Step 1–...
  • Page 16 Step 2 – Leg Support and Top Rail with Leg Socket Assembly At this point, two people will be needed to assemble the trampoline. ➢ Attach Vertical Leg Extensions (#6A and #6B) to Leg Base (# 5) as shown in the boxes below. Note there are three combinations with two sets each (the assembled parts will be hereinafter referred to as “Leg Support”).
  • Page 17 Step 3 –Top Rail Assembly Complete the trampoline frame by inser�ng all of the Top Rails (# 4) in between Top Rail with Leg Sockets (# 3) as  shown below. DO NOT PLACE HANDS NEAR THE OPENING WHEN CONNECTING THE TUBES. WEAR PROTECTIVE GLOVES TO PROTECT FROM INJURIES DURING ASSEMBLY.
  • Page 18 Step 4 – Secure Leg Support to Top Rail ➢ Secure Vertical Leg Extension (# 6A) to the frame using Self-Locking Screw (# 11), Small Spring Lock Washer (# 10) and Allen Wrench (# K) as shown below. If the holes do not match up, rotate Vertical Leg Extension back and forth until the holes are aligned.

  • Page 19: Trampoline Mat Assembly

    Trampoline Mat Assembly When attaching the springs, do not place your hands, arms, legs or any other body part close to the connector points (i.e. joints connecting the steel tubes). The connector points can become pinch points as the trampoline springs tighten up. Wear heavy duty working gloves to protect your hands from injuries during installation by the springs and protective goggles to avoid injuries to the eyes.
  • Page 20 Step 6 – Spring Assembly ➢ Continue to attach springs in the same manner. For even distribution of tension and ease of assembly, the springs must be placed on opposite sides of the mat in an alternating manner, i.e. 10 then 46, 28 then 64, etc.
  • Page 21 Step 7 – Spring Assembly ➢ Continue to attach springs in the same manner. For even distribution of tension and ease of assembly, the springs must be placed on opposite sides of the mat in an alternating manner, i.e. 5 then 41, 14 then 50, 23 then 59, 32 then 68, etc.
  • Page 22 Step 8 – Spring Assembly ➢ Continue to attach the remaining springs in the same manner as the previous step, i.e. the springs must be placed on opposite sides of the mat in an alternating manner to ensure even distribution of tension. IMPORTANT: Once all the springs are properly installed, you must go back to Step 4 and now tighten the screws on all Leg Supports.

  • Page 23: Frame Pad Assembly

    Frame Pad Assembly Never use the trampoline without the Frame Pad, the Frame Pad reduces the risk of getting injured by hitting the metal frame or springs. Inspect the Frame Pad before each and every use to ensure all exposed metal parts are fully covered by the Frame Pad! Step 9 ➢...

  • Page 24: Trampoline Enclosure Assembly

    Trampoline Enclosure Assembly BEFORE YOU BEGIN: • This trampoline must only be used when the enclosure netting is properly assembled. The trampoline netting must be checked thoroughly before each use to ensure there are no tears or damages. Please carefully read all the Important Warnings contained in this manual and all warnings on the product before use.
  • Page 25 Step 11- Connect the Enclosure Upper Frame to the Lower Frame ➢ Attach Tube Cap (# C) to Upper Frame Tube with Foam (# A), using Self-Locking Screw (# 11) and Allen Wrench (# K)as shown below. Repeat this step for all of the Frame Tubes. Diagram 11-1 Customer Service 1-888-707-1880 Dyaco Canada Inc.2019...
  • Page 26 ➢ Secure the buckles located at the top of the netting enclosure through Tube Cap (# C) as shown below. Hint: • Please make sure the cap holder is facing outward. • Keep some looseness on the strap of the buckles. Diagram 11-2 Customer Service 1-888-707-1880 Dyaco Canada Inc.2019...
  • Page 27 Step 12 – Connect Enclosure Upper Frame to Lower Frame Tubes ➢ Connect all four Upper Frame Tube with Foam (# A) to Lower Frame Tube with Foam (# B). Secure with Self-Locking Screw (# 11) using Allen Wrench (# K) as shown below. Helpful Tips: It may be easier for one person should stand inside the trampoline to hold the netting in place while another person installs all the frame tubes from the outside.
  • Page 28 Step 13 – Tie the Enclosure to the Mat ➢ Secure the trampoline netting to the trampoline frame using the Cords (# L). Lift up the frame pad and tie one end of the cord to any one of the triangle-rings on the trampoline mat as shown below. ➢...
  • Page 29 - Secure the Frame Pad Step 14 ➢ Wrap and tie the inner elastic straps on the frame pad around the triangle-rings and the outer straps around the trampoline frame as shown below. Diagram 14-1 Customer Service 1-888-707-1880 Dyaco Canada Inc.2019...
  • Page 30 ➢ For the elastic straps near the leg sockets, wrap them BEHIND the leg sockets and then tie a one-sided bow in front as shown below. Diagram 14-2 • Make sure that the knots and bows are tight for all elastic straps. •...
  • Page 31 Step 15–Close the Enclosure and Attach the Safety Instruction Placard ➢ Close the zipper and strap located at the entrance of the Enclosure Netting (# M). ➢ Attach Enclosure Safety Instruction Placard (# N) and Trampoline Safety Instruction Placard (# 8) to the trampoline frame as shown.

  • Page 32: Disassembly Of The Trampoline And Enclosure

    IMPORTANT Once you have finished the assembly of the trampoline, go back over all of the nuts and bolts and properly tighten all of them before using. Read this entire manual and make sure all jumpers completely understand all of the safety rules printed in the manual and on the various warning signs.

  • Page 33: Care And Maintenance

    Care and Maintenance Failure to follow these instructions to ensure proper operational condition of your trampoline may lead to serious injury or death.   ➢ The zipper and buckles should be closed during use to avoid users falling out of the trampoline, as well as during periods of non-use to restrict access by unauthorized users.

  • Page 34: Proper Use Instructions

    Proper Use Instructions Read and understand the use instructions in this manual prior to using this product. Failure to do so can result in serious injury or death.  Responsibilities of the user The key here is to stay in control of your jumps. DO NOT move onto more complicated, more difficult maneuvers until you have mastered the basic, fundamental bounce.
  • Page 35  The enclosure net is provided as a safety feature only and is not to be used for play. The enclosure net is meant to help prevent a single user who uses the trampoline in a manner consistent with the instructions in the owner’s manual from falling off the trampoline if he or she loses their balance.
  • Page 36 Read and understand the use instructions in this manual prior to using this product. Failure to do so can result in serious injury or death.  Read all instructions before using the trampoline. Warnings and instructions for the care, maintenance and use of this trampoline are included to promote proper and enjoyable use of this equipment.

  • Page 37: Learning The Fundamental Trampoline Skills

    Learning the fundamental trampoline skills The following lessons are suggested for you to learn basic steps and bounces. Before using the trampoline, you should read and understand all warnings. A complete discussion and demonstration of body mechanics and trampoline guidelines should occur between the supervisor and student as well.
  • Page 38 BASIC TRAMPOLINE BOUNCES THE BASIC BOUNCE 1. Start from the standing position, with your feet having shoulder width apart and with head up and eyes on mat 2. Swing arms forward and up in a circular motion 3. Bring feet together while in mid-air and point toes downwards.

  • Page 39: Product Warranty

    Product Warranty Dyaco Canada Inc. warrants this unit, to the original purchaser, to be free from defects in material and workmanship for the period of time listed below. Warranty time begins at the time of purchase. Normal wear and user’s abuse are not covered in the warranty. Weather damage and other such acts of nature are not covered by the Manufacturer’s warranty.
  • Page 40 Please visit us online for information about our other brands and products manufactured and distributed by Dyaco Canada Inc. spiri�itness.ca solefitness.ca xterrafitness.ca dyaco.ca/products/everlast.html dyaco.ca/UFC/UFC-home.html spiri�itness.ca/johnnyg.html trainorsports.ca For more informa�on, please contact Dyaco Canada Inc. T: 1-888-707-1880 ⏐ 5955 Don Murie St., Niagara Falls, Ontario L2G 0A9 ⏐ sales@dyaco.ca...
