BOL83BF, BOL83BR, BOL83HF, BOL83HR,
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in
manuals, be alert to the potential for personal injury or death.
Improper installation, adjustment, alteration, service,
or maintenance can cause injury or property damage.
Refer to this manual. For assistance or additional
information, consult a qualified installer or service
agency.
Do not store combustible materials, including gasoline
and other flammable vapors and liquids, near the
furnace, vent pipe, or warm air ducts. The homeowner
should be cautioned that the furnace area must not
be used as a broom closet or for any other storage
purposes. Such uses may result in actions that could
cause property damage, personal injury, or death.
Manufactured By
Blue Summit LLC
8201 C National Turnpike
Louisville, KY 40214
The installation of the furnace, wiring, warm air ducts, venting, etc. must conform to the requirements of the National Fire
Protection Association Standard for the Installation of Oil Burning Equipment, NFPA No. 31; the National Electrical Code,
ANSI/NFPA No. 70 (in the USA); the Installation Code for Oil Burning Equipment, CSA Standard CAN/CSA B139 (in
Canada); the Canadian Electrical Code Part 1, CSA 22.1; the Recommendations of the National Environmental Systems
Contractors Association; and any state or provincial laws or local ordinances. Local authorities having jurisdiction should
be consulted before installation is made. Such applicable regulations or requirements take precedence over the general
instructions in this manual.
506793-02B
INSTALLATION INSTRUCTIONS
BOL83UF
Oil-Fired Furnaces
WARNING
WARNING
Save these instructions for future reference
Table of Contents
Installation ...................................................................3
Combustion and Ventilation Air....................................6
Electrical Wiring .........................................................10
Filters .........................................................................11
Start-Up .....................................................................11
Sequence of Operation..............................................12
Maintenance and Service ..........................................13
Never burn garbage or paper in the heating system and
never leave rags, paper, or any flammable items around
the unit.
*P506793-02B*
CAUTION
Issue 1810
CAUTION
(P) 506793-02B
Page 1 of 16
Advertisement
Related Manuals for Blueridge BOL83BF
Summary of Contents for Blueridge BOL83BF
-
Page 1: Table Of Contents
INSTALLATION INSTRUCTIONS BOL83BF, BOL83BR, BOL83HF, BOL83HR, BOL83UF Oil-Fired Furnaces This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in manuals, be alert to the potential for personal injury or death. - Page 2 Oil Furnace Start-Up Checklist (Complete this page and keep for future reference) Customer Name _________________________________________________________________________________________________________ Address ________________________________________________________________________________________________________________ City ______________________________________________________________ State ____________________ Zip Code ____________________ Furnace Model # ____________________________________________________ Serial # ______________________________________________ Input Rate ___________________________________________________________ Nozzle Used ________________________________________ New Construction _____________________________________________________ Replacement ________________________________________ Date of Installation _______________________________________________ Installation Data Start-Up Procedure...
-
Page 3: Installation
Claims of shortages should clearances are greater than fire protection clearances, be filed with the seller within 5 days. the accessibility clearances take precedence. Basement Type Units Hi-Boy (Upflow) BOL83BF, BOL83BR* BOL83UF 57/72 - 84/95 112/125 57/72 - 84/95 112/125 Top of Plenum and Duct Work 2”... - Page 4 Non-Suspended Horizontal Installation To support the furnace from below, set the furnace on non Top View -combustible material suitable to support the weight of the unit. Using a carpenter’s level, check furnace in at least two directions. To make adjustments, use shims of non- Supply Return combustible material.
- Page 5 Cold Air Duct Blower Comparment Burner Combustible Sub-base Floor Base Minimum Clearances Insulation Counterflow Installations Slab Flooring Sides 1” (12" minimum) Return Plenum Top Floor Floor Cold Warm Air Combustible Joist Warm Air Plenum Model Size Hole Hole Supply Plenum Side 1”...
-
Page 6: Combustion And Ventilation Air
Combustion and Ventilation Air WARNING Adequate provisions for combustion air, ventilation of Combustion air openings in the front of the furnace furnace, and dilution of the gases must be made. When a must be kept free of obstructions. Any obstruction will furnace is installed in an unconfined space in a building, it cause improper burner operation and may result in a can be assumed that infiltration will be sufficient to supply... - Page 7 Local building codes may have more stringent installation requirements and should be consulted before installation of the unit. The flue pipe should be as short as possible to do the job. The internal diameter of the flue pipe or vent connector shall equal the outlet diameter of the flue opening of the appliance.
- Page 8 Front Flue Front Flue Rear Flue * Barometric control must be installed in the horizontal venting system and located within 18” of the flue outlet of the furnace. Rear Flue Figure 8. Masonry Chimney * Barometric control may be installed in either the vertical or horizontal section of the flue pipe within 18”...
- Page 9 Removal of Unit from Common Venting System Supply and Return Air Plenum When an existing furnace is removed from a common Secure return air plenum to unit using sheet metal screws. venting system service other appliances, the venting Follow these procedures when installing supply air plenum: system is likely to be too large to properly vent the remaining attached appliances.
-
Page 10: Electrical Wiring
Thermostat Electrical Wiring Locate the thermostat on an inside wall in a room usually occupied during the day, such as a living room or dining All wiring must conform to the National Electrical Code, the room, at a height of 4-1/2” from the floor. Avoid direct Canadian Electrical Code, and any local codes. -
Page 11: Filters
energized whenever the thermostat calls for heat, cooling, or continuous blower. Refer to the furnace wiring diagram CAUTION for specific connection information (see also Figure 10). Do Not start burner unless blower access door is secured in place. Filters Burner Start-Up Upflow and Horizontal/Counterflow Set the operating control to call for heat. -
Page 12: Sequence Of Operation
10. When the proper combustion and smoke readings Furnace Burner Nozzle / Spray Pump have been achieved, tighten the air adjustment screw. Model Head Angle Pattern Pressure 11. Recheck the draft, smoke, combustion, and flue gas 57 * .50 GPH/80° DELAVAN A 100 PSI temperature. -
Page 13: Maintenance And Service
Heat Exchanger Power to the burner is interrupted, thus shutting down the burner. To clean the heat exchanger: Remove the vent pipe from the furnace. Blower Remove the locking screws and the caps from the two A direct drive blower motor contained within the furnace is cleanout tubes;... - Page 14 Figure 12. Wiring Diagram Direct Drive (Horizontal) Page 14 of 16 Issue 1810 506793-02B...
- Page 15 Figure 13. Wiring Diagram Direct Drive (Upflow/Basement) 506793-02B Issue 1810 Page 15 of 16...
- Page 16 Figure 14. Page 16 of 16 Issue 1810 506793-02B...
