Renaissance Cooking
Systems
INSTALLATION AND OPERATING
INSTRUCTIONS
Leave these instructions with consumer.
INSTALLER:
READ &
CONSUMER:
READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGINNING INSTALLATION
Important:
DANGER
IF YOU SMELL GAS
1. Shut off the gas to the appliance.
2. Extinguish any open flame.
3. Open lid to vent.
4. If odor continues, keep away from the
appliance, and immediately call your
gas supplier or fire department.
CODE AND SUPPLY REQUIREMENTS:
burner must be installed in accordance with local codes
and ordinances, or, in the absence of local codes, with
either the latest National Fuel Gas Code (ANSI Z223.1/
NFPA 54), and Natural Gas and Propane Storage and
Handling Installation Code (CSA-B149.1).
This appliance and its individual shutoff valves must
be disconnected from the gas supply piping system
when testing the system at pressures in excess of
½ psig (3.5 kPa).
This appliance must be isolated from the gas supply
piping system by closing its individual manual
shut-off valves during any pressure testing of the
gas supply system at pressures up to and including
½ psig (3.5 kPa).
Side Burner
retain for future reference.
SAFETY WARNINGS & CODES
:
This side
Side Burner
Model #
RSB1
RSB3A
RJCSSB / RJCSSBL
RDB1 / RDB1EL
ASBSSB
ASB3
WARNING
1. Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
2. A propane cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance with flame.
WARNING
mproper installation, adjustment, alteration,
I
service, or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information consult
a qualified professional installer, service
agency, or the gas supplier.
All electrical outlets in the vicinity of the side
burner must be properly grounded in
Accordance with local codes or, in the
absence of local codes, with the National
Electrical Code, ANSI/NFPA 70, or the
Canadian Electrical Code, CSA C22.1,
whichever is applicable.
Keep all electrical supply cords and fuel
supply hoses away from any heated surface
at all times.
Liner Jacket
Model #
-
LJRSB3A
LJRJCSSC
LJRDB1
LJASBSSB
LJASB3
Page 1
REV 11/21/2023
Advertisement
Table of Contents
Related Manuals for Renaissance Cooking Systems RSB3A
Summary of Contents for Renaissance Cooking Systems RSB3A
- Page 1 Renaissance Cooking Side Burner Liner Jacket Model # Model # Side Burner Systems RSB1 RSB3A LJRSB3A RJCSSB / RJCSSBL LJRJCSSC INSTALLATION AND OPERATING RDB1 / RDB1EL LJRDB1 INSTRUCTIONS ASBSSB LJASBSSB Leave these instructions with consumer. INSTALLER: ASB3 LJASB3 READ &...
- Page 2 Safety and Installation Instructions When using your side burner, please read and follow these basic precautions: SIDE BURNER INSTALLATION This Outdoor-cooking appliance (side burner) must be installed in accordance with all local and state codes INSPECTED by your local CITY & Fire department. If installation is planned in an area with no local codes, the gas burner must be installed in accord with the National Fuel Gas Code ANSI Z223.1 and storage and handling of liquefied petroleum gases, ANSI/NFPA 58 or CSA B149.1 natural gas and propane installation code.
-
Page 3: General Safety Requirements
GENERAL SAFETY REQUIREMENTS: 1. The installation of this appliance must conform with local codes or, in the absence of local codes, Either the National Fuel Gas Code, ANZI Z223.1/NFPA 54, or CAN/CGA-B149.1, Natural Gas Installation Code or CAN/CGA-B149.2, Propane Installation Code. 2. -
Page 4: Ensuring Proper Combustion Air And Cooling Air Flow
WHERE TO INSTALL THE SIDE BURNER THIS SIDE BURNER IS FOR OUTDOOR USE ONLY. IMPORTANT: WARNING The side burner must be installed in a masonry or other type of fireproof surround. The unit is not insulated and therefore must be installed or placed with 16" of side and back clearance from –... -
Page 5: Gas Safety Requirement
GAS SAFETY REQUIREMENTS Each appliance is set and tested at the factory for the type of gas supply to be used. Identify the Type of gas, either natural gas or LP ( Liquid Propane) gas and make sure that the marking on the rating plate located on the side of the unit. -
Page 6: Lp Gas Hook-Up
LP GAS HOOK-UP Do not use any replacement regulator other than that specified by the manufacturer. Use only pipe sealants that are approved for use with natural and LP gases. An installer-supplied gas shutoff valve must be installed in an accessible location. (Reference: leak test procedure). An enclosure or Island for LP gas cylinder or natural gas must be VENTING YOUR ENCLOSURE: vented on the level of the cylinder valve and at floor level. -
Page 7: Natural Gas Installation
NATURAL GAS INSTALLATION The installation must conform with local codes or, in the absence of local codes, with either The national Fuel Gas Code, ANSI Z223.1/NFPA 54, or CAN/CGA-B149.1, Natural Gas Installation Code or CAN/CGA-B149.2, Propane Installation Code. 1. This gas appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at the test pressures in excess of 1/2 psi (3.5 kPa). - Page 8 To prevent fire or explosion hazard, DO NOT use or permit sources of ignition in the area while performing a leak test. Perform leak test outdoors only. Check to ensure that flexible hoses do not have any cuts and wear that may affect the safety before each use.
-
Page 9: Clearance To Combustible Construction
TYPICAL BUILDING DIMENSIONS CLEARANCE TO COMBUSTIBLE CONSTRUCTION Cut Out Dimensions A - Width B - Depth C - Height Model # RSB1 7 3/4" 15 1/2" RSB3A 14" 18 5/8" 9 1/4" RJCSSB/L 10 3/4" 21" 8" RDB1 / EL 12"... -
Page 10: Stainless Steel Maintenance
CLEANING & MAINTENANCE SPIDER AND INSECT WARNING Spiders and other insects can nest in the burner of this and any other side burner, which causes the gas to flow from the front of the burner. This dangerous “condition” can cause a fire behind the valve panel, damaging the side burner and making the side burner unsafe to operate. - Page 11 BURNERS CLEANING & MAINTENANCE Burners are made of brass and stainless steel and can be cleaned using a brush, warm water and soap. Check every port hole for clogs. Use a wire pin to clean out clogged ports. DRIP PAN The drip pan collects grease, liquid and fallen food particles.
- Page 12 TO LIGHT THE SIDE BURNER’S BURNER Lighting the side burner 1. Open the gas supply shut-off valve. 2. Push in the knob and rotate the knob counter-clockwise, wait a few seconds and then click the sure-strike ignition system to ignite. If the igniter does not light turn to the right and OFF position, verify that the gas is on and then try again.
- Page 13 Renaissance Cooking Systems Product Warranty RCS is proud to provide the industries most comprehensive warranty program. All RCS American Renaissance Grills, Cutlass Pro Series Grills and Cutlass Pro Series side burners, sinks, as well as ALL doors and drawers are warrantied to be free from manufacturer defects for the lifetime of the original owner.
- Page 14 RSB-1 3 7/8" 6" 19 1/2" 14"...
- Page 15 RSB3A 10 1/2" 22" 15 3/4" 9" 18 1/2" 13 1/2"...
- Page 16 RJCSSB " " " " " " " " RJCSSBL " " " " " " " "...
- Page 17 RDB-1EL 13 7/8" 10 7/8" 8 3/4" 18 5/8" 11 1/2" 23 3/4" 12 3/4" RDB-1 13 7/8" 10 7/8" 8 3/4" 18 5/8" 11 1/2" 23 1/2" 12 3/4"...
