- Page 1 42PF7320G 50PF7320G...
-
Page 2: Table Of Contents
Introduction Thank you for purchasing this television set. This handbook has been designed to help you install and operate your TV set. We strongly recommend that you read it thoroughly. Table of Contents Safety Information ............. . 2 Preparation / Getting started . -
Page 3: Safety Information
Safety Information 10 cm 10 cm Leave at least 10 cm around each side of the TV set to allow for proper ventilation. Place the set on a stable, level surface. Never cover the ventilation slots of the TV with a cloth or other material. -
Page 4: Preparation / Getting Started
Preparation / Getting started Positioning the TV set 10 cm 10 cm Place your TV set on a solid stable surface, leaving a space of at 10 cm around the set. Connections • Insert the aerial plug into the 75Ω : socket at the bottom of the set. -
Page 5: Television Keys And Connectors
Televison keys and connectors CAUTION : This a Class 1 apparatus. It must be connected to a MAINS socket out with a protective earthing connection. MAINS ~ POWER . key: to switch the TV on and off. A little power remains on even when the Power switch is turned off. -
Page 6: Remote Control Keys
Remote Control keys Standby To set the TV to standby mode. To switch the TV set on again, press P – / + or key. Pixel Plus Offers a unique combination of ultimate sharpness, increased depth impression, true natural detail, brilliant and vivid colours. Press key for a Pixel Plus demonstration. - Page 7 Remote Control keys * The signal strength indicator shows the signal strength of the reception of the programme you are watching. Numerical keys For direct selection of channels. For a 2 digit channel number, the 2 be entered before the dash disappears. Screen information To display/remove the channel number, the sound mode, the remaining time of the...
-
Page 8: Remote Control Keys (Dvd Or Aux)
Remote Control keys (DVD or AUX) The remote control also allows you to control the main functions of some Philips DVD players. Press the key to select the required mode: DVD or AUX. The remote control indicator lights up to display the selected mode. It switches off automatically after 20 seconds if left idle. -
Page 9: Auto Store
Auto Store Press key. Press Î ï keys repeatedly until Install is selected and press Æ / access Install menu. TV Menu Install Picture Sound Language Features Install Auto Store Manual Store Sort Name Channel Edit Manual Store You can choose to tune your channels manually. Manual tuning allows you to store each programme manually. -
Page 10: Sort
Sort Sort feature allows you to change the channel number for a particular TV station Press key. Press Î ï keys repeatedly until Install is selected and press Æ / access Install menu. TV Menu Install Picture Sound Language • Æ... -
Page 11: Channel Edit
Channel Edit Channel Edit feature allows you to edit or skip programmes which have bad or weak signal or programme you do not watch often. Press key. Press Î ï keys repeatedly until Install is selected and press Æ / access Install menu. -
Page 12: Timer
Timer The Timer feature allows you to set the timer to switch to another channel at a specified time while you are watching another channel. You can also use it as an alarm to switch on the TV at a specified time from standby mode. For the timer to function, the set must not be switched off. -
Page 13: Child Lock
Child Lock The Child Lock feature allows you to lock channels to prevent your children from watching certain programmes. Press key. Press Î ï keys repeatedly until Features is selected and press Æ / access Features menu. Press Î ï keys repeatedly until Child Lock is selected and press Æ... -
Page 14: Screen Formats
Screen Formats The pictures you receive may be transmitted in 16:9 format (wide screen) or 4:3 format (conventional screen). 4:3 pictures sometimes have a black band at the left and right of the screen when viewed on a widescreen TV. This function allows you to optimise the picture display on screen. Press key (or Í... -
Page 15: Smart Picture And Sound
Smart Picture and Sound Smart Picture feature offers you a choice of 5 picture settings namely : Rich, Natural, Soft, Multimedia and Personal. Smart Sound feature offers you a choice of 4 sound settings namely : Theatre, Music, Voice, and Personal. Note : The Personal setting is the setting that you set up using the Picture/Sound menu in the main menu. -
Page 16: Tv As A Pc Monitor
TV as a PC Monitor Your TV can be used as a computer monitor. Important For the TV to function as PC monitor, the following steps must be taken : STEP 1 Connect the PC Via CVI 2/VGA – Connect VGA output of the PC to the CVI 2/VGA input of the TV. - Page 17 TV as a PC Monitor STEP 1 Connect the PC Via HDMI – Connect DVI output of the PC to the HDMI 1 or HDMI 2 input of the TV. Use a DVI to HDMI adaptor. HDMI 1 HDMI 2 inputs at bottom of TV HDMI 2 HDMI 1...
-
Page 18: Tv In Hd (High Definition) Mode
TV in HD (High Definition) Mode The HD (High Definition) mode allows you to enjoy clearer and sharper pictures if you are using a HD equipment that can produce high definition programming. Important For the TV to function in HD mode, the following steps must be taken : STEP 1 Connect the HD equipment... - Page 19 576p NOTE : For more details on connection to the HD equipment, see guide “ CONNECT”. Your Philips TV is HDMI compliant. If you do not get a good picture, please change the video format on your device (DVD player, cable set-top box, etc.) to a standard format.
-
Page 20: Pip (Picture-In-Picture)
PIP (Picture-in-Picture) The PIP (Picture-in-Picture) feature allows you to call up a PIP screen of the PC (Personal Computer) or HD (High Defintion) equipment while watching a TV programme. Likewise, you can also call up a PIP screen of the TV while you are in PC or HD mode. - Page 21 PIP (Picture-in-Picture) Accessing the PIP via the PIP menu Note : This is only possible when PIP signal is detected. & Press key to display main menu. Press Î ï key, select Features and é the Æ / key to enter the Features menu.
-
Page 22: Troubleshooting Tips
Troubleshooting Tips Below is a list of symptoms you may encounter with your TV. Before you call for service, make these simple checks. Symptom Possible Causes No display on screen • Faulty power supply • TV’s Power not turned Poor reception •... -
Page 23: Glossary
Troubleshooting Tips Symptom Possible Causes PC modes do not • Wrong connections work • Wrong source selected. • Wrong display resolution • Wrong setting of PC Black bar on top • PC refresh rate too high and bottom of screen in PC mode Warning concerning stationary images on the TV screen A characteristic of Plasma Display Panels is that displaying the same image for a long time can cause a permanent after-image to remain on the screen. -
Page 24: Specifications
Specifications Panel screen size Audio output TV System Video playback Sound System Connectivity Rear Side Power consumption Standby power consumption Set dimensions (with stand) Width Depth Height Nett Weight (with stand) 42PF7320G 1070 mm (42”) 2 x 15 W @ 10% THD 2 x 13 W @ 7% THD PAL, SECAM... - Page 25 Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners. 2005 © Koninklijke Philips Electronics N.V. All rights reserved . www.philips.com...
