Version: T1
Button Commands
TRH0027
Single Channel Remote
Technical specifications
Battery: 3V (CR2450)
Working temperature: -10 ℃ ~50 ℃
-4°F ~ 122°F
Warning
● Do not expose the remote to excessive moisture or water
● Do not strike or use excessive force on the remote
● If the remotes range is decreasing the battery may need to be replaced
● Only use CR2450 batteries in device
● If the voltage is less than 2.6V the remote will show a low voltage indicator
● Under uni-directional operating mode, pressing any button for more than
20s will stop radio signal transmission
● Under bi-directional operating mode, pressing any button for more than
5s will stop radio signal transmission
● Failure to follow these warnings may result in injury or render the remote
inoperable
● Always dispose of batteries properly
TRH0027
Single-channel LCD
Remote Instruction
UP
STOP
DOWN
LED
To remove the back cover use a tool such as a SIM card pin,
mini screwdriver or paper clip. Press down on the center of
the hole on the back and simultaneously slide the cover in a
downward movement.
Battery life: >2 years
Transmitting power: 10 mW
Setting
button
(P2)
Radio frequency: 433.05~434.79MHz
Radio range: 200 meters outdoor, 35 meters indoor
220 yards outdoor, 38 yards indoor
Setting
button
(P2)
TRH0027
Back
Advertisement
Table of Contents
Related Manuals for Trax TRH0027
Summary of Contents for Trax TRH0027
- Page 1 TRH0027 Single-channel LCD Remote Instruction Version: T1 Button Commands STOP DOWN Setting Setting button button (P2) (P2) TRH0027 To remove the back cover use a tool such as a SIM card pin, TRH0027 mini screwdriver or paper clip. Press down on the center of...
- Page 2 Switching Between Uni-Directional and Bi-Directional Modes Note: The factory default mode is Bi-directional Hold P2 button and install the battery LED flashes once Uni-directional mode Remote without battery LED flashes twice Bi-directional mode Locking/Unlocking Programming Functions on Remotes Locking of remotes is used to prevent accidental changes to the pre-set positions of the motor such as open and closed positions as well as preferred stop positions.
