- Page 1 OPERATION AND MAINTENANCE MANUAL MYPC40-500 (VER:4.0) MYPC40-1500 (VER:4.0) MYPC32-100 (VER:4.0) Please scan the following QR code or download the operation manual from MYTORQ website https://www.mytorqtools/tc/download-list.php SAING EI CORP. https://www.mytorqtools.com Y2F125Q-17E-002...
-
Page 3: Table Of Contents
NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. MYTORQ is not responsible for customer modification of tools for applications on which MYTORQ was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions. It is the responsibility of the employer to place the information in this manual into the hands of the operator. -
Page 4: Important Safety Instructions
Important Safety Instructions WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term "power tool" in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 5 d) Store idle power tools out of reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tools operation.
-
Page 6: Operations Cautions
MY8 MYT MYR series with the Multi-Function Controller. ＊ Please arrange to use together with MYTORQ MY2 MY5 MY7 MY8 MYT MYR series Electric Screwdriver. If operator uses different brand of Electric Screwdriver and repair tools with parts or accessories not from MYTORQ manufacturer, it may cause the Controller malfunction or poor quality. -
Page 7: Main Technical Parameters
Main Technical parameters MYPC32-100 (Ver：4.0) MYPC40-500 (Ver：4.0) MYPC40-1500 (Ver：4.0) Model No Input Voltage AC 100-240V 50 / 60Hz AC 100-240V 50 / 60Hz AC 115/230V 50 / 60H Output Voltage DC 32V/ 24V DC 40V/ 32V/ 24V DC 40V/ 32V/ 24V... -
Page 8: Control Panel Specifications
Control panel specifications PARTS NAME PARTS NAME LED Indicator Down-Selecting Key HI / LO Speed Switch System Build-in Reset Key Key setting lock POWER/CLEAR Key 6Pin Connector Functional Selection / Confirm Key WORK Light Power point OK Light POWER SWITCH N.G Light Output voltage choice I/O Inserting Hole ＊... -
Page 9: Functions Of Keys On Panel
Functions of Keys on Panel： Description of function. Remarks When there is NG signal, POWER： Power Switch press CLEAR bottom to (1) Press and hold for 6 seconds that will turn off counter and other functions including 7 segment. clear the NG signal LED display. - Page 10 Note： Enter the setup： dt----- tt-----Sr----SA----Gr-----Rn (1) When the user presses the dt/tt POWER + UP, panel displays dt：the time range between each screwing process. This function will be triggered after finish one dt, release POWER + UP to screwing process. If user doesn’t start next screwing process in this setting time range. The system show up values.
-
Page 11: I/O Inserting Hole
I/O Inserting Hole： Name In/Out Content wave pattern of signals Remark Output：DC +12V or +24V (Max：200mA) Default value：+24VDC Output 12 or 24 v dc (+12VDC need to custom modify) CN2 and CN3 will be short Automatically open CN2~CN3 Output when finished fastening one MOS RELAY (default) +/- 40V, +/- 250mA screw (Open Collector need to custom modify) - Page 12 Terminal Connecting Diagram：(To take factory default：MOS RELAY I/O for example) Output： Input：...
-
Page 13: Functional Dip Switch
Select OFF makes system automatically to recover from the setting count number. SW4：Switching Mode：Select ON means the external SENSOR need to have two signals been sent to MYPC40-500 which stands for the fastener on operational process need to go through the sensor on machine table to identify the fastener has been removed from working table, and new fastener goes through another SENSOR for confirming the new fastener that has reached the working table. - Page 14 CONFIRM ： Code Instruction Notations External sensor First external sensor to be confirmed. * When the SA is set to HI, the display SW2 (ON) + SW3 (OFF) + SW4 (OFF) "C1" ； if set is LO and will displayed "C.1 " The second external sensor to be confirmed.
-
Page 15: System Setting
※ If using three units of data only and let three units in cycles. It can set up "00" in counting number on U4, when SW6 switch ON, the system will automatically move in circle from U1~U3. System setting System procedure： SL<SELECT>SC<SELECT>At<SELECT>Ot<SELECT>Rc<SELECT>SP<SELECT>Ht<SELECT>... - Page 16 Presses SELECT to select then press UP/DOWN to change digits. The maximum digit is 9.9. Ut: Pre tightening time; any escaped time less than Ut will be counted as NG failure. To press SELECT, the screen will show , push POWER key, adjust decimals , push UP/DOWN to increase or decrease number, the maximum can set up 9.99.
- Page 17 Data Chart： Ht/Lt mainly set up the period of time. If stop is within the set period, it means OK. In contrast, it will be (NG), as stop before Lt or after Ht. and should reconfirm whether wrong screws is taken. More precise requested means more correct Ht/Lt set-up should be.
-
Page 18: Simulated Learning
Simulated Learning 1、 The switch mode SW5 change into ON. ※When SW5 change to ON, it will force to enter simulated learning procedure, any function will not work. 2、 When it changes to ON, LED will flash. The user can set whether or not counting screws, starting slow start. The simulated learning function will be turned on after this necessary condition confirming. - Page 19 CAUTION The use of other than genuine MYTORQ replacement parts may Result in decreased tool performance and increased maintenance, and may invalidate all warranties. All repairs and maintenance of this tool and its word must be performed by an authorized service center.
