HEX Alton Assembly Manual

Large metal storage apex shed 8 x 8 ft (2.4 x 2.4 m)
Hide thumbs

Advertisement

Quick Links

Download this manual
A lton
Large Metal Storage Apex Shed Assembly Guide
8 x 8 ft (2.4 x 2.4 m)
IMPORTANT: PLEASE REGISTER YOUR HEX LIVING PRODUCT AFTER ASSEMBLY
Using the unique serial number, simply register your product at www.hexliving.co.uk
or use the QR code above to access the HEX Living lifetime warranty and online support.
Affix Serial Number
HERE

Advertisement

loading
Need help?

Need help?

Do you have a question about the Alton and is the answer not in the manual?

Questions and answers

Related Manuals for HEX Alton

Summary of Contents for HEX Alton

  • Page 1 IMPORTANT: PLEASE REGISTER YOUR HEX LIVING PRODUCT AFTER ASSEMBLY Using the unique serial number, simply register your product at www.hexliving.co.uk or use the QR code above to access the HEX Living lifetime warranty and online support. Affix Serial Number HERE...
  • Page 2 CARING FOR YOUR HEX LIVING PRODUCT Your HEX Living product is designed to stand the test of time, which is why we’re happy to offer a lifetime warranty on our products. With zero maintenance required, simply assemble your HEX Living product and enjoy putting it to great use in your garden.
  • Page 3 Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0213-01 Part Ref: 0205-74 Qty: x1 Qty: x2 Part Ref: 0205-02 Part Ref: 0205-09 Qty: x2 Qty: x3 Part Ref: 0205-13 (1850 x 425mm) Part Ref: 0205-12 (1850 x 625mm)
  • Page 4 Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0205-14 (1885mm Long) Part Ref: 0205-16 (R/H) Qty: x4 Qty: x1 Part Ref: 0256-01 Part Ref: 0213-02 Qty: x1 Qty: x4 Part Ref: 0256-03...
  • Page 5 Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0252-04 Part Ref: 0256-06 Qty: x4 Qty: x1 Part Ref: 0252-14 Part Ref: 0244-11 Qty: x2 Qty: x2 Part Ref: 0244-16 Part Ref: 0256-05...
  • Page 6 Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0205-37 (Left-hand) Part Ref: 0205-36 (Right-hand) Qty: x1 Qty: x1 Part Ref: 0205-39 Part Ref: 0213-21 Qty: x4 Qty: x2 Part Ref: 0205-38-01...
  • Page 7 Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING OF ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0203-03 Part Ref: 0203-41 Qty: x4 Qty: x1 Part Ref: 0205-57 Part Ref: 0203-15 Qty: x4 Qty: x4 Part Ref: 0205-63 Part Ref: 0203-28...
  • Page 8 Assembly Guide ASSEMBLY STAGE 1 LOCATE AND SECURE A CORNER BRACE 0203-03 AT EACH LOCATION INDICATED. 0213-01 0205-02 0203-03 (x4) 0213-01 0205-02 0203-03 SECURE EACH CORNER BRACE 0203-03 AS SHOWN ABOVE. PLEASE NOTE: SECTION VIEW OF TYPICAL FIXING METHOD.
  • Page 9 Assembly Guide ASSEMBLY STAGE 2 LOCATE AND LOOSELY ATTACH WALL PANEL 0213-03 (1850 x 324mm). 0213-03 ENSURE WALL PANEL IS LOCATED WITH CORRUGATION AS SHOWN 0213-03 (1850 x 324mm) LOCATE WALL PANEL 0213-03 INTO POSITION AS SHOWN ABOVE. LOOSELY ATTACH WALL PANEL ONTO FLOOR RAIL AT LOCATION INDICATED. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 10 Assembly Guide ASSEMBLY STAGE 3 LOCATE AND LOOSELY ATTACH CORNER POST 0205-14. x2 HOLES AT TOP 0205-14 LOCATE CORNER POST 0205-14 AS SHOWN ABOVE. LOOSELY ATTACH CORNER POST AT LOCATION INDICATED ONLY. IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
  • Page 11 Assembly Guide ASSEMBLY STAGE 4 LOCATE AND LOOSELY ATTACH SHORT CENTRE BRACE 0213-04 ONTO WALL PANEL. 0213-04 LOCATE AND LOOSELY ATTACH SHORT CENTRE BRACE LOOSELY ATTACH AT LOCATION INDICATED ONLY. 0213-04 AS SHOWN AT LOCATION INDICATED ABOVE. IMPORTANT: DO NOT SECURE AT OUTER FIXING POINT AT THIS STAGE.
  • Page 12 Assembly Guide ASSEMBLY STAGE 5 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE FIRST WALL PANEL 0205-12 (1850 x 625mm) AS SHOWN ABOVE. LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 13 Assembly Guide ASSEMBLY STAGE 6 LOCATE AND LOOSELY ATTACH MID CENTRE BRACE 0205-09. 0205-09 LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY. LOCATE AND LOOSELY ATTACH MID CENTRE BRACE 0205-09 AS IMPORTANT: DO NOT SECURE AT OUTER FIXING POINT INDICATED. SHOWN AT x3 LOCATIONS INDICATED ABOVE.
  • Page 14 Assembly Guide ASSEMBLY STAGE 7 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOOSELY ATTACH AT LOCATIONS INDICATED ONLY. LOCATE AND LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 15 Assembly Guide ASSEMBLY STAGE 8 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-13 (1850 x 425mm). 0205-13 OUTSIDE INSIDE OUTSIDE INSIDE LOOSELY ATTACH AT x2 LOCATIONS INDICATED ONLY. LOCATE AND LOOSELY ATTACH WALL PANEL AT x2 LOCATIONS INDICATED. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 16 Assembly Guide ASSEMBLY STAGE 9 LOCATE AND LOOSELY ATTACH CORNER POST 0205-14. x2 HOLES AT TOP 0205-14 LOCATE CORNER POST 0205-14 AS SHOWN ABOVE. LOOSELY ATTACH CORNER POST AT x2 LOCATIONS INDICATED ONLY. IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
  • Page 17 Assembly Guide ASSEMBLY STAGE 10 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-13 (1850 x 425mm). 0205-13 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE FIRST WALL PANEL 0205-13 (1850 x 425mm) AS SHOWN ABOVE. LOOSELY ATTACH WALL PANEL AT x2 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 18 Assembly Guide ASSEMBLY STAGE 11 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE WALL PANEL 0205-12 INTO POSITION AS SHOWN ABOVE. LOOSELY ATTACH BACK WALL PANEL AT x3 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION. IMPORTANT: DO NOT SECURE ANY FIXING POINTS OTHER THAN THOSE INDICATED.
  • Page 19 Assembly Guide ASSEMBLY STAGE 12 LOCATE AND LOOSELY ATTACH LONG CENTRE BRACE 0205-09 0205-09 LOCATE AND LOOSELY ATTACH LONG CENTRE BRACE 0205-09 LOOSELY ATTACH AT x5 LOCATIONS INDICATED ONLY. AS SHOWN AT x5 LOCATIONS INDICATED ABOVE. IMPORTANT: DO NOT SECURE AT OUTER FIXING POINT INDICATED.
  • Page 20 Assembly Guide ASSEMBLY STAGE 13 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE AND LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED. LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 21 Assembly Guide ASSEMBLY STAGE 14 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE AND LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED. LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 22 Assembly Guide ASSEMBLY STAGE 15 LOCATE AND LOOSELY ATTACH CORNER POST 0205-14 (1885mm). x2 HOLES AT TOP 0205-14 LOCATE CORNER POST 0205-14 AS SHOWN ABOVE. LOOSELY ATTACH CORNER POST AT x2 LOCATIONS INDICATED ONLY. IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
  • Page 23 Assembly Guide ASSEMBLY STAGE 16 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-13 (1850 x 425mm). 0205-13 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE FIRST WALL PANEL 0205-13 (1850 x 425mm) AS SHOWN ABOVE. LOOSELY ATTACH WALL PANEL AT x2 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 24 Assembly Guide ASSEMBLY STAGE 17 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE WALL PANEL 0205-12 INTO POSITION AS SHOWN ABOVE. LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION. IMPORTANT: DO NOT SECURE ANY FIXING POINTS OTHER THAN THOSE INDICATED.
  • Page 25 Assembly Guide ASSEMBLY STAGE 18 LOCATE AND LOOSELY ATTACH MID CENTRE BRACE 0205-09. 0205-09 LOCATE AND LOOSELY ATTACH MID CENTRE BRACE 0205-09 AS LOOSELY ATTACH AT x5 LOCATIONS INDICATED ONLY. SHOWN AT x5 LOCATIONS INDICATED ABOVE. IMPORTANT: DO NOT SECURE AT OUTER FIXING POINT INDICATED.
  • Page 26 Assembly Guide ASSEMBLY STAGE 19 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE AND LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED. LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 27 Assembly Guide ASSEMBLY STAGE 20 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY. LOCATE AND LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 28 Assembly Guide ASSEMBLY STAGE 21 LOCATE AND LOOSELY ATTACH CORNER POST 0205-14. 0205-14 LOCATE CORNER POST 0205-14 AS SHOWN ABOVE. LOOSELY ATTACH CORNER POST AT x2 LOCATIONS INDICATED ONLY. IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
  • Page 29 Assembly Guide ASSEMBLY STAGE 22 LOCATE AND LOOSELY ATTACH WALL PANEL 0213-03 (1850 x 324mm). 0213-03 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE WALL PANEL 0213-03 (1850 x 324mm) AS SHOWN ABOVE. LOOSELY ATTACH WALL PANEL AT x2 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION. IMPORTANT: DO NOT SECURE ANY FIXING POINTS OTHER THAN THOSE INDICATED.
  • Page 30 Assembly Guide ASSEMBLY STAGE 23 LOCATE AND LOOSELY ATTACH RIGHT-HAND DOOR POST 0205-16. LOCATE AND LOOSELY ATTACH SHORT CENTRE BRACE 0213-04 ONTO WALL PANEL. 0205-16 0213-04 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE RIGHT-HAND DOOR POST 0205-16 AS SHOWN ABOVE. SECURE DOOR POST AND CENTRE BRACE AT LOCATIONS INDICATED. IMPORTANT: ENSURE DOOR POST IS IN THE CORRECT ORIENTATION.
  • Page 31 Assembly Guide ASSEMBLY STAGE 24 LOCATE AND LOOSELY ATTACH LEFT-HAND DOOR POST 0205-17. LOCATE AND LOOSELY ATTACH SHORT CENTRE BRACE 0213-04 ONTO WALL PANEL. 0205-17 0213-04 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE LEFT-HAND DOOR POST 0205-17 AS SHOWN ABOVE. SECURE DOOR POST AND CENTRE BRACE AT LOCATIONS INDICATED. IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
  • Page 32 Assembly Guide ASSEMBLY STAGE 25 LOCATE AND LOOSELY ATTACH SHORT ROOF RAIL 0213-02. 0213-02 0213-02 LOCATE SHORT ROOF RAIL 0213-02 AS SHOWN ABOVE. LOOSELY ATTACH AT x12 LOCATIONS INDICATED.
  • Page 33 Assembly Guide ASSEMBLY STAGE 26 LOCATE AND LOOSELY ATTACH LONG ROOF RAIL 0213-02. 0213-02 LOCATE LONG ROOF RAIL 0213-02 AS SHOWN ABOVE. LOOSELY ATTACH AT x12 LOCATIONS INDICATED.
  • Page 34 Assembly Guide ASSEMBLY STAGE 27 LOCATE AND LOOSELY ATTACH LONG ROOF RAIL 0213-02. 0213-02 SLOT INTO DOOR POST LOCATE LONG TOP RAIL 0213-02 AS SHOWN ABOVE. LOOSELY ATTACH AT x4 LOCATIONS INDICATED.
  • Page 35 Assembly Guide ASSEMBLY STAGE 28 LOCATE GROUND ANCHOR BRACKETS 0205-57. 0205-57 (x4) THESE BRACKETS ARE SECURED USING GROUND ANCHOR KIT ONCE THE SHED WALL PANELS ARE FULLY ASSEMBLED (SEE PAGE ‘i’) PLEASE NOTE: THESE BRACKETS ARE OPTIONAL, THEY CLAMP INTO PLACE WHEN FIXED TO A CONCRETE BASE FOR EXTRA STABILITY.
  • Page 36 Assembly Guide ASSEMBLY STAGE 29 LOCATE AND SECURE DOOR STRIP 0205-74. 0205-74 LOCATE DOOR STRIP 0205-74 AS SHOWN. SECURE DOOR STRIP ONTO FLOOR PANELS AT x2 LOCATIONS IMPORTANT: ENSURE DOOR STRIP IS PUSHED AGAINST DOOR POST RETURN. INDICATED, USE EXISTING HOLE AS A LOCATION GUIDE.
  • Page 37 Assembly Guide ASSEMBLY STAGE 30 LOCATE AND SECURE ROOF INFILL SIDE 0256-05. 0256-05 0256-05 LOCATE AND SECURE ROOF SIDE INFILL 0256-05 AT x12 LOCATIONS INDICATED AS SHOWN ABOVE ON EACH SIDE. IMPORTANT: ENSURE ROOF SIDE INFILL 0256-05 IS FITTED ON THE INSIDE AND NOT ON THE OUTSIDE AS ILLUSTRATED ABOVE.
  • Page 38 Assembly Guide ASSEMBLY STAGE 31 LOCATE AND SECURE ROOF FRONT INFILL 0252-14. 0252-14 0252-14 0252-14 LOCATE AND SECURE WINDOW ASSEMBLY 0252-14 AT LOCATIONS INDICATED AS SHOWN ABOVE. IMPORTANT: ENSURE WINDOW ASSEMBLY 0252-14 IS FITTED ON THE INSIDE AND NOT ON THE OUTSIDE AS ILLUSTRATED ABOVE.
  • Page 39 Assembly Guide ASSEMBLY STAGE 32 LOCATE AND EACH CORNER BRACKET 0203-15 TO ROOF INFILL AT FOUR LOCATIONS. 0203-15 (x4) 0203-15 SECURE EACH CORNER BRACKET 0203-15 TO ROOF INFILLS AT SECURE EACH CORNER BRACKET 0203-15 TO ROOF INFILLS AT LOCATIONS INDICATED AS SHOWN ABOVE. LOCATIONS INDICATED AS SHOWN ABOVE.
  • Page 40 Assembly Guide ASSEMBLY STAGE 33 LOCATE AND SECURE ROOF SUPPORTS 0252-07 AND 0252-11. 0252-11 0252-07 0252-07 0252-11 0252-11 0252-11 0252-11 (x4) 0252-07 (x2) LOCATE AND SECURE SHORT ROOF SUPPORT 0252-11 AS SHOWN ABOVE. LOCATE AND SECURE LONG ROOF SUPPORT 0252-07 AS SHOWN ABOVE.
  • Page 41 Assembly Guide ASSEMBLY STAGE 34 LOCATE AND SECURE ROOF CHANNEL ASSEMBLY 0256-03. 0256-03 0256-03 0252-12 0252-12 0252-11 0252-11 SLOT EACH ROOF CHANNEL ASSEMBLY 0252-12 INTO ROOF SUPPORT. SECURE ROOF CHANNEL ASSEMBLY TO SHORT ROOF SUPPORT 0252-11 FIXING POINT (x3 EACH SIDE) USING FASTENERS DETAILED ABOVE. FIXING POINT (x2 EACH SIDE) USING FASTENERS DETAILED ABOVE.
  • Page 42 Assembly Guide ASSEMBLY STAGE 35 LOCATE AND SECURE ROOF CHANNEL ASSEMBLY 0256-01. 0256-01 0252-01 0252-01 0252-07 SLOT ROOF CHANNEL ASSEMBLY 0252-01 INTO ROOF SUPPORT. SECURE ROOF CHANNEL ASSEMBLY TO LONG ROOF SUPPORT 0252-07 FIXING POINT (x3 EACH SIDE) USING FASTENERS DETAILED ABOVE. FIXING POINT (x2 EACH SIDE) USING FASTENERS DETAILED ABOVE.
  • Page 43 Assembly Guide ASSEMBLY STAGE 36 LOCATE AND SECURE ROOF PANEL 0252-03. 0252-03 SECURE ROOF PANELS AT x4 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. IMPORTANT: ENSURE RUBBER WASHER FK4 IS LOCATED AS SHOWN.
  • Page 44 Assembly Guide ASSEMBLY STAGE 37 LOCATE AND SECURE ROOF PANEL SIDE 0252-04. 0252-04 OUTSIDE INSIDE OUTSIDE INSIDE ALIGN AND OVERLAP ROOF PANEL 0252-04 WITH ROOF PANEL SIDE AS SHOWN. SECURE ROOF PANELS AT x 3 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. IMPORTANT: ENSURE PANELS ALWAYS OVERLAP AS SHOWN.
  • Page 45 Assembly Guide ASSEMBLY STAGE 38 LOCATE AND SECURE ROOF PANELS 0252-03 & ROOF PANEL SMALL 0252-06. 0252-06 0252-03 (x2) OUTSIDE INSIDE OUTSIDE INSIDE ALIGN AND OVERLAP ROOF PANEL WITH PREVIOUS ROOF PANEL. SECURE ROOF PANELS AT LOCATIONS INDICATED USING TYPICAL FIXING METHOD. IMPORTANT: ENSURE PANELS ALWAYS OVERLAP AS SHOWN.
  • Page 46 0252-11 Assembly Guide ASSEMBLY STAGE 39 LOCATE AND SECURE ROOF PANEL SIDE 0252-04. 0252-04 0252-06 OUTSIDE INSIDE OUTSIDE INSIDE ALIGN AND OVERLAP ROOF PANEL 0252-04 WITH ROOF PANEL SIDE AS SHOWN. SECURE ROOF PANELS AT x 3 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. IMPORTANT: ENSURE PANELS ALWAYS OVERLAP AS SHOWN.
  • Page 47 Assembly Guide ASSEMBLY STAGE 40 LOCATE AND SECURE ROOF PANEL 0252-03. 0252-03 SECURE ROOF PANELS AT x4 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. IMPORTANT: ENSURE RUBBER WASHER FK4 IS LOCATED AS SHOWN.
  • Page 48 Assembly Guide ASSEMBLY STAGE 41 LOCATE AND SECURE ROOF PANEL SIDE 0252-04. 0252-03 0252-04 OUTSIDE INSIDE OUTSIDE INSIDE ALIGN AND OVERLAP ROOF PANEL 0252-04 WITH ROOF PANEL SIDE AS SHOWN. SECURE ROOF PANELS AT x 3 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. IMPORTANT: ENSURE PANELS ALWAYS OVERLAP AS SHOWN.
  • Page 49 Assembly Guide ASSEMBLY STAGE 42 LOCATE AND SECURE ROOF PANELS 0252-03 & ROOF PANEL SMALL 0252-06. 0252-06 0252-03 (x2) OUTSIDE INSIDE OUTSIDE INSIDE ALIGN AND OVERLAP ROOF PANEL WITH PREVIOUS ROOF PANEL. SECURE ROOF PANELS AT LOCATIONS INDICATED USING TYPICAL FIXING METHOD. IMPORTANT: ENSURE PANELS ALWAYS OVERLAP AS SHOWN.
  • Page 50 Assembly Guide ASSEMBLY STAGE 43 LOCATE AND SECURE ROOF PANEL SIDE 0252-04. 0252-04 0252-06 OUTSIDE INSIDE OUTSIDE INSIDE ALIGN AND OVERLAP ROOF PANEL 0252-04 WITH ROOF PANEL SIDE AS SHOWN. SECURE ROOF PANELS AT x 3 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. IMPORTANT: ENSURE PANELS ALWAYS OVERLAP AS SHOWN.
  • Page 51 Assembly Guide ASSEMBLY STAGE 44 LOCATE AND SECURE ROOF RIDGE BRACKET 0244-16 TO ROOF RIDGE 0256-06. LOCATE AND SECURE ROOF RIDGE 0256-06 TO ROOF CHANNEL ASSEMBLY 0256-01. 0256-06 NOTE: MAKE SURE 0256-06 EDGE IS FLUSH WITH OUTER SHED ROOF EDGE. THIS WILL HELP WITH HOLE ALIGNMENT, WHEN SECURING TO 0256-01 ROOF CHANNEL...
  • Page 52 Assembly Guide ASSEMBLY STAGE 45 LOCATE AND SECURE ROOF RIDGE CAPS 0244-11 TO ROOF RIDGE 0256-06. 0256-06 0244-11 0244-11 SLIDE RIDGE CAP 0244-11 INTO POSITION AT FRONT & REAR OF THE SHED ROOF. SECURE RIDGE CAP AT x4 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. PLEASE NOTE: THE FIXING USED IS A SELF DRILLING COMPONENT.
  • Page 53 Assembly Guide ASSEMBLY STAGE 46 LOCATE AND SECURE ROOF GUTTER ASSEMBLY 0213-21. 0213-21 0213-21 SLIDE AND SECURE ROOF GUTTER 0213-21 INTO POSITION AS SHOWN ABOVE. IMPORTANT: ENSURE PANELS ALWAYS OVERLAP GUTTER AS SHOWN.
  • Page 54 Assembly Guide ASSEMBLY STAGE 47 LOCATE AND SECURE ROOF CAPS 0213-09. 0213-09 0213-09 SLIDE AND SECURE ROOF CAP 0213-09 INTO POSITION AS SHOWN ABOVE. PLEASE NOTE: THE FIXING USED IS A SELF DRILLING COMPONENT.
  • Page 55 Assembly Guide ASSEMBLY STAGE 48 48A 48B DETERMINE WHICH SIDE DRAIN HOLE 0205-53 WILL BE LOCATED. 48A 48B 48A 48B 48A 48B 0205-52 OPPOSITE SIDE TO DRAINPIPE 0205-53 FIT ABOVE WHERE DRAIN HOLE WILL BE LOCATE AN OPEN GROMMET INTO THE ROOF GUTTER ABOVE WHERE LOCATE CLOSED GROMMET INTO THE ROOF GUTTER ON THE OPPOSITE THE DRAIN HOLE WILL BE LOCATED.
  • Page 56 Assembly Guide ASSEMBLY STAGE 49 LOCATE AND SECURE RIGHT-HAND DOOR ASSEMBLY 0205-36 FURNITURE. 0205-36 0203-32 LOCATE EURO MORTICE LOCK 0203-32 RIGHT-HAND DOOR APERTURE SECURE EURO MORTICE LOCK 0203-32 AT x2 LOCATIONS INDICATED ABOVE. AS SHOWN. SEE FOLLOWING DATA SHEET FOR COMPLETION OF MORTICE LOCK INSTALLATION.
  • Page 57 Assembly Guide ASSEMBLY STAGE 49 CONTINUED LOCATE AND SECURE RIGHT-HAND DOOR ASSEMBLY 0205-36 FURNITURE. 0203-34 LOCATE AND SECURE EURO ESCUTCHEON 0203-34 AS SHOWN. LOCATE EURO ESCUTCHEON COVER 0203-34 ONTO EURO ESCUTCHEON AS SHOWN. PLEASE NOTE: THESE ARE PUSHED ON AND WILL CLICK INTO PLACE. LOCATE EURO CYLINDER 0203-36 INTO DOOR APERTURE.
  • Page 58 Assembly Guide ASSEMBLY STAGE 50 LOCATE AND SECURE LEFT-HAND DOOR ASSEMBLY 0205-37 FURNITURE. 0203-35 0203-32 0203-41 0203-35 0203-40 0203-35 LOCATED AS SHOWN 0203-40 ENSURE THE PLUNGER INDICATED IS FACING THE BOTTOM OF THE DOOR, SECURE EACH FLUSH DOOR BOLT ENSURING PLATE PACKER 0203-40 IS LOCATE AS SHOWN ABOVE AND SECURE USING ADJACENT FIXING METHOD.
  • Page 59 Assembly Guide ASSEMBLY STAGE 50 CONTINUED LOCATE AND SECURE LEFT-HAND DOOR ASSEMBLY 0205-37 FURNITURE. 0203-35 FLUSH DOOR BOLT OPEN / CLOSE 0203-35 DOOR BOLT ATTACH DOOR BOLT ONTO FLUSH DOOR BOLT. ENSURE FLUSH DOOR BOLT OPENS AND CLOSES. REPEAT 50A / B / C FOR UPPER FLUSH DOOR BOLT LOCATE AND SECURE UPPER FLUSH DOOR BOLT 0203-35 USING PROCEDURES 50A / B / C, PLUNGER WILL FACE UPWARDS TOWARDS THE TOP OF THE DOOR...
  • Page 60 Assembly Guide ASSEMBLY STAGE 51 LOCATE AND SECURE A DOOR GROMMET 0203-57 AT EACH LOCATION INDICATED. 0203-57 0203-57 0203-57 0203-57 0203-35 0203-35 0203-57 LOCATE DOOR GROMMENT 0203-57 AT x2 LOCATIONS INDICATED. LOCATE DOOR GROMMENT 0203-57 AT x2 LOCATIONS AS SHOWN. PLEASE NOTE: 0203-35 FLUSH BOLTS ARE ALL IN THE UNLOCKED POSITIONS.
  • Page 61 Assembly Guide ASSEMBLY STAGE 52 LOCATE AND SECURE DOOR HINGES ONTO DOOR ASSEMBLIES. 0203-27 0203-28 0203-37 0203-37 0203-27 0203-28 0203-37 0203-37 LOCATE DOOR HINGE PLATE 0203-37 WITHIN DOOR AS SHOWN. SECURE DOOR HINGE PLATE AND HINGE 0203-27 AND 0203-28 AS SHOWN. IMPORTANT: ENSURE CORRECT DOOR HINGE IS SECURED TO CORRECT DOOR.
  • Page 62 Assembly Guide ASSEMBLY STAGE 53 LOCATE AND SECURE DOOR HINGES ONTO LEFT-HAND & RIGHT-HAND DOOR POST. 0203-27 UPPER LOCATION LOCATE DOOR POST PLATE 0203-39 WITHIN DOOR FRAME AS SHOWN. SECURE DOOR POST PLATE AND LEFT-HAND HINGE 0203-27 AS SHOWN. IMPORTANT: ENSURE CORRECT DOOR HINGE IS SECURED TO CORRECT DOOR. PLEASE NOTE: REPEAT EACH PROCEDURE FOR UPPER LOCATION.
  • Page 63 Assembly Guide ASSEMBLY STAGE 54 LOCATE AND SECURE GAS STRUT BRACKETS 0205-66. LEFT-HAND RIGHT-HAND 0205-66 (x2) 0205-68 (x2) SECURE A GAS STRUT BALL JOINT 0205-68 ONTO DETERMINE DOOR OPENING ANGLE: ALIGN EACH GAS STRUT BRACKET WITH RELEVANT FIXING A: 90° OPENING OR B: 120° OPENING EACH GAS STRUT BRACKET 0205-66.
  • Page 64 Assembly Guide ASSEMBLY STAGE 55 LOCATE DOOR ASSEMBLIES ONTO HINGES. 0205-37 0205-36 SLIDE EACH DOOR ASSEMBLY ONTO EACH OF THEIR RESPECTIVE HINGES. ASSEMBLED DOOR HINGE.
  • Page 65 Assembly Guide ASSEMBLY STAGE 56 LOCATE AND SECURE GAS STRUT 0205-63 . SECURE A GAS STRUT BALL JOINT 0205-68 ONTO EACH GAS STRUT BRACKET FIX EACH GAS STRUT 0205-63 ONTO RELEVANT GAS STRUT BALL JOINTS. THAT IS PRE-RIVETED ONTO EACH DOOR ASSEMBLY. PLEASE NOTE: PUSHES DOWN ON DOOR AND UPWARDS ON DOOR FRAME.
  • Page 66 Assembly Guide ASSEMBLY STAGE 57 LOCATE AND SECURE SHELF ASSEMBLY 0205-38. SLIDE SHELF POST UP INTO ROOF FRAME, ONCE THERE IS ENOUGH CLEARANCE AT THE BOTTOM LOCATE SHELF POST OVER FLOOR FRAME AND LOWER. THE SHELF ASSEMBLY CAN BE LOCATED AS DESIRED, PLEASE DETERMINE THE LOCATE EACH SHELF 0205-38-02 ONTO SHELF POST AS DESIRED.
  • Page 67 Assembly Guide NOTES...
  • Page 68 Caring for your HEX Living product Your HEX Living product is designed to stand the test of time, which is why we’re happy to offer a lifetime warranty on our products. With zero maintenance required, simply assemble your HEX Living product, and enjoy putting it to great use in your garden.
