HEX Bromley Assembly Manual

Horizontal metal storage shed
Hide thumbs

Advertisement

Quick Links

Download this manual
Bromley
Horizontal Metal Storage Shed Assembly Guide
IMPORTANT: PLEASE REGISTER YOUR HEX LIVING PRODUCT BEFORE ASSEMBLY
Using the unique serial number, simply register your product at www.hexliving.co.uk
to access and download the HEX Living lifetime warranty and video assembly instructions.
Affix Serial Number
HERE
Doc Ref: 699-0805/C

Advertisement

loading
Need help?

Need help?

Do you have a question about the Bromley and is the answer not in the manual?

Questions and answers

Related Manuals for HEX Bromley

Summary of Contents for HEX Bromley

  • Page 1 Horizontal Metal Storage Shed Assembly Guide IMPORTANT: PLEASE REGISTER YOUR HEX LIVING PRODUCT BEFORE ASSEMBLY Using the unique serial number, simply register your product at www.hexliving.co.uk to access and download the HEX Living lifetime warranty and video assembly instructions. Affix Serial Number HERE...
  • Page 2 CARING FOR YOUR HEX LIVING PRODUCT Your HEX Living product is designed to stand the test of �me, which is why we’re happy to offer a life�me warranty on our products. With zero maintenance required, simply assemble your HEX Living product and enjoy pu�ng it to great use in your garden.
  • Page 3 Bromley: Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0204-01 Part Ref: 0204-05 Qty: x2 Qty: x1 Part Ref: 0204-02 Part Ref: 0204-07 Qty: x2...
  • Page 4 Bromley: Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0204-18 Part Ref: 0204-08 (824mm Wide) Qty: x1 Qty: x2 Part Ref: 0204-12 (Right-hand) Qty: x1...
  • Page 5 Bromley: Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0204-17 Part Ref: 0204-33 Qty: x1 Qty: x2 Part Ref: 0204-34 Qty: x2 Part Ref: 0204-21 (Right-hand)
  • Page 6 Bromley: Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0204-46 Part Ref: 0204-65 Qty: x1 Qty: x6 Part Ref: 0204-56 Part Ref: 0205-68 Qty: x1...
  • Page 7 Bromley: Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0206-28 (Assembly) Part Ref: 0203-40 Qty: x1 Qty: x4 Part Ref: 511-0023 Qty: x4 Part Ref: 0203-33 (Assembly)
  • Page 8 Bromley: Assembly Guide ASSEMBLY STAGE 1 LOCATE AND SECURE A CORNER BRACE 0203-03 AT EACH LOCATION INDICATED. 0204-02 0204-01 0203-03 (x4) 0204-01 0204-02 0203-03 PLEASE NOTE: SECTION VIEW OF TYPICAL FIXING METHOD. SECURE EACH CORNER BRACE 0203-03 AS SHOWN ABOVE.
  • Page 9 Bromley: Assembly Guide ASSEMBLY STAGE 2 LOCATE AND SECURE A FLOOR BRACE 0204-03 AT EACH LOCATION INDICATED. 0204-03 (x3) 0204-03 PLEASE NOTE: ENSURE TOP OF FLOOR BRACE IS LEVEL WITH TOP OF FLOOR RAIL. SLOT EACH FLOOR BRACE 0204-03 INTO POSITION AS SHOWN ABOVE.
  • Page 10 Bromley: Assembly Guide ASSEMBLY STAGE 3 LOCATE SIDE WALL PANEL 0204-08 (824mm WIDE), PLEASE NOTE EACH PANEL DOES NOT HAVE A SPECIFIC TOP OR BOTTOM SO CAN BE LOCATED EITHER WAY. 0204-08 (824mm) 0204-08 (824mm) LOCATE SIDE WALL PANEL 0204-08 INTO POSITION AS SHOWN ABOVE.
  • Page 11 Bromley: Assembly Guide ASSEMBLY STAGE 4 LOCATE AND LOOSELY ATTACH SHORT CENTRE BRACE 0204-06 ONTO SIDE WALL. 0204-06 LOCATE AND LOOSELY ATTACH SHORT CENTRE BRACE 0204-06 AS SHOWN AT LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY. x3 LOCATIONS INDICATED ABOVE.
  • Page 12 Bromley: Assembly Guide ASSEMBLY STAGE 5 LOCATE AND LOOSELY ATTACH CORNER POSTS 0204-10 (1237mm) & 0204-11 (1302mm LONG) ONTO SIDE WALL. 0204-11 (1302mm LONG) 0204-10 (1237mm LONG) x3 HOLES AT TOP x2 HOLES & LARGE OBROUND AT TOP LOCATE CORNER POSTS 0204-10 & 0204-11 AS SHOWN AT x2 LOCATIONS ABOVE.
  • Page 13 Bromley: Assembly Guide ASSEMBLY STAGE 6 LOCATE BACK WALL PANEL 0204-09 (625mm WIDE), PLEASE NOTE THE PANEL DOES NOT HAVE A SPECIFIC TOP OR BOTTOM BUT ENSURE IT IS LOCATED AS INSTRUCTED. 0204-11 (1302mm LONG) 0204-09 (625mm WIDE) LOCATE FIRST BACK WALL PANEL 0204-09 (625mm WIDE) AS SHOWN ABOVE.
  • Page 14 Bromley: Assembly Guide ASSEMBLY STAGE 7 LOCATE AND LOOSELY ATTACH LONG CENTRE BRACE 0204-05 ONTO BACK WALL PANEL. 0204-05 LOCATE AND LOOSELY ATTACH LONG CENTRE BRACE 0204-05 AS SHOWN AT LOOSELY ATTACH AT x2 LOCATIONS INDICATED ONLY. x2 LOCATIONS INDICATED ABOVE ONLY.
  • Page 15 Bromley: Assembly Guide ASSEMBLY STAGE 8 LOCATE BACK WALL MIDDLE PANEL 0204-54 (616mm WIDE), PLEASE NOTE THE PANEL DOES NOT HAVE A SPECIFIC TOP OR BOTTOM BUT ENSURE IT IS LOCATED AS INSTRUCTED. 0204-54 LOCATE AND LOOSELY ATTACH BACK WALL MIDDLE PANEL AT x3 LOCATIONS.
  • Page 16 Bromley: Assembly Guide ASSEMBLY STAGE 9 LOCATE BACK WALL PANEL 0204-09 (625mm WIDE), PLEASE NOTE THE PANEL DOES NOT HAVE A SPECIFIC TOP OR BOTTOM BUT ENSURE IT IS LOCATED AS INSTRUCTED. 0204-09 LOCATE AND LOOSELY ATTACH BACK WALL MIDDLE PANEL AT x3 LOCATIONS.
  • Page 17 Bromley: Assembly Guide ASSEMBLY STAGE 10 LOCATE AND LOOSELY ATTACH CORNER POST 0204-11 (1302mm LONG) ONTO SIDE WALL. 0204-11 (1302mm LONG) x3 HOLES AT TOP LOCATE CORNER POST 0204-11 (1302mm) AS SHOWN ABOVE. LOOSELY ATTACH CORNER POST AT LOCATION INDICATED ONLY.
  • Page 18 Bromley: Assembly Guide ASSEMBLY STAGE 11 LOCATE SIDE WALL PANEL 0204-08 (824mm WIDE), PLEASE NOTE THE PANEL DOES NOT HAVE A SPECIFIC TOP OR BOTTOM SO CAN BE LOCATED EITHER WAY. 0204-08 (824mm) LOCATE SIDE WALL PANEL 0203-09 INTO POSITION AS SHOWN ABOVE.
  • Page 19 Bromley: Assembly Guide ASSEMBLY STAGE 12 LOCATE AND LOOSELY ATTACH SHORT CENTRE BRACE 0204-06 ONTO SIDE WALL. 0204-06 LOCATE AND LOOSELY ATTACH SHORT CENTRE BRACE 0204-06 AS SHOWN AT LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY. x3 LOCATIONS INDICATED ABOVE.
  • Page 20 Bromley: Assembly Guide ASSEMBLY STAGE 13 LOCATE AND LOOSELY ATTACH CORNER POST 0204-10 (1237mm) ONTO SIDE WALL. 0204-10 (1237mm LONG) x2 HOLES & LARGE OBROUND AT TOP LOCATE CORNER POST 0204-10 (1237mm) AS SHOWN ABOVE. LOOSELY ATTACH CORNER POST AT LOCATION INDICATED ONLY.
  • Page 21 Bromley: Assembly Guide ASSEMBLY STAGE 14 LOCATE AND LOOSELY ATTACH A CENTRE BRACE REAR BRACKET 0204-33. 0204-33 LOCATE AND LOOSELY ATTACH CENTRE BRACE CORNER BRACKET 0204-33 AS LOOSELY ATTACH CENTRE BRACE CORNER BRACKET 0204-33 AT REMAINING FIXING SHOWN ABOVE. POINTS AS SHOWN.
  • Page 22 Bromley: Assembly Guide ASSEMBLY STAGE 15 LOCATE AND LOOSELY ATTACH A CENTRE BRACE REAR BRACKET 0204-33. 0204-33 LOCATE AND LOOSELY ATTACH CENTRE BRACE CORNER BRACKET 0204-33 AS LOOSELY ATTACH CENTRE BRACE CORNER BRACKET 0204-33 AT REMAINING FIXING SHOWN ABOVE. POINTS AS SHOWN.
  • Page 23 Bromley: Assembly Guide ASSEMBLY STAGE 16 LOCATE AND LOOSELY ATTACH RIGHT-HAND TOP RAIL 0204-15. 0204-15 ONLY ATTACH AT FIXING POINTS CIRCLED SLOT RIGHT-HAND TOP RAIL 0204-15 INTO POSITION AS SHOWN ABOVE. LOOSELY ATTACH AT x3 LOCATIONS INDICATED. IMPORTANT: ONLY ATTACH AT FIXING POINTS INDICATED AT THIS STAGE.
  • Page 24 Bromley: Assembly Guide ASSEMBLY STAGE 17 LOCATE AND LOOSELY ATTACH LEFT-HAND TOP RAIL 0204-19. 0204-19 ONLY ATTACH AT FIXING POINTS CIRCLED SLOT LEFT-HAND TOP RAIL 0204-19 INTO POSITION AS SHOWN ABOVE. LOOSELY ATTACH AT x3 LOCATIONS INDICATED. IMPORTANT: ONLY ATTACH AT FIXING POINTS INDICATED AT THIS STAGE.
  • Page 25 Bromley: Assembly Guide ASSEMBLY STAGE 18 LOCATE AND LOOSELY ATTACH REAR TOP RAIL 0204-18. 0204-18 ONLY ATTACH AT FIXING POINTS CIRCLED SLOT REAR TOP RAIL 0204-18 INTO POSITION AS SHOWN ABOVE. LOOSELY ATTACH AT x4 LOCATIONS INDICATED. IMPORTANT: ONLY ATTACH AT FIXING POINTS INDICATED AT THIS STAGE.
  • Page 26 Bromley: Assembly Guide ASSEMBLY STAGE 19 LOCATE AND LOOSELY ATTACH LEFT-HAND DOOR POST 0204-13. 0204-13 LOCATE LEFT-HAND DOOR POST 0204-13 AS SHOWN ABOVE. SECURE DOOR POST AT x1 LOCATION INDICATED. IMPORTANT: ONLY ATTACH AT FIXING POINT INDICATED AT THIS STAGE.
  • Page 27 Bromley: Assembly Guide ASSEMBLY STAGE 20 LOCATE AND LOOSELY ATTACH RIGHT-HAND DOOR POST 0204-15. 0204-15 LOCATE RIGHT-HAND DOOR POST 0204-15 AS SHOWN ABOVE. SECURE DOOR POST AT x1 LOCATION INDICATED. IMPORTANT: ONLY ATTACH AT FIXING POINT INDICATED AT THIS STAGE.
  • Page 28 Bromley: Assembly Guide ASSEMBLY STAGE 21 LOCATE AND LOOSELY ATTACH FRONT TOP RAIL 0204-14. 0204-14 SLOT FRONT TOP RAIL 0204-14 INTO POSITION AS SHOWN ABOVE. SECURE FRONT TOP RAIL AT x2 LOCATIONS INDICATED.
  • Page 29 Bromley: Assembly Guide ASSEMBLY STAGE 22 LOCATE AND LOOSELY ATTACH x1 CENTRE BRACE FRONT BRACKET 0204-34 AT THE LOCATION INDICATED. 0204-34 LOOSELY ATTACH CENTRE BRACE FRONT BRACKET 0204-34 AS SHOWN ABOVE. LOOSELY ATTACH AT REMAINING FIXING POINT AS SHOWN.
  • Page 30 Bromley: Assembly Guide ASSEMBLY STAGE 23 LOCATE AND LOOSELY ATTACH x1 CENTRE BRACE FRONT BRACKET 0204-34 AT THE LOCATION INDICATED. 0204-34 LOOSELY ATTACH CENTRE BRACE FRONT BRACKET 0204-34 AS SHOWN ABOVE. LOOSELY ATTACH AT REMAINING FIXING POINT AS SHOWN.
  • Page 31 Bromley: Assembly Guide ASSEMBLY STAGE 24 LOCATE AND LOOSELY ATTACH A TOP FRONT SUPPORT BRACKET 0204-59 AT EACH LOCATION INDICATED. 0204-59 0204-59 LOCATE AND LOOSELY ATTACH EACH TOP FRONT SUPPORT BRACKET AS SHOWN LOOSELY ATTACH AT EACH FIXING POINT USING TYPICAL FIXING METHOD ABOVE.
  • Page 32 Bromley: Assembly Guide ASSEMBLY STAGE 25 ASSEMBLE HINGE BRACKET ASSEMBLIES. 511-0023 511-0023 0204-47 0204-47 0204-23 0204-24 0205-68 0205-68 0205-68 0205-68 511-0023 SECURE HINGE BRACKET PIVOTS 0204-47 & 0204-50 ONTO EACH HINGE BRACKET SECURE BALL STUDS 0205-68 ONTO EACH HINGE BRACKET PIVOT AND HINGE BASE 0204-23 &...
  • Page 33 Bromley: Assembly Guide ASSEMBLY STAGE 26 LOCATE AND LOOSELY ATTACH HINGE BRACKET ASSEMBLIES AT EACH LOCATION INDICATED. 0204-23 0204-24 0204-23 0204-24 LOCATE AND LOOSELY ATTACH HINGE BRACKET ASSEMBLY ON RIGHT-HAND SIDE LOCATE AND LOOSELY ATTACH HINGE BRACKET ASSEMBLY ON LEFT-HAND SIDE OF STORAGE UNIT AS SHOWN.
  • Page 34 Bromley: Assembly Guide ASSEMBLY STAGE 27 LOOSELY ATTACH AT ALL UPPER FIXING POINTS INDICATED. IMPORTANT ADJUST ALL COMPONENTS FOR BEST POSSIBLE FIT AND TIGHTEN ALL FASTENERS. ONCE ALL FASTENERS HAVE BEEN CHECKED AND ARE SECURE PROCEED ONTO STAGE 26. ONCE UPPER FIXING POINTS ARE ATTACH TIGHTEN ALL FASTENERS.
  • Page 35 Bromley: Assembly Guide ASSEMBLY STAGE 28 INSERT AN END CAP 0204-30 AT EACH LOCATION INDICATED. 0204-30 (x4) INSERT AN END CAP 0204-30 INTO EACH LOCATION INDICATED AS SHOWN.
  • Page 36 Bromley: Assembly Guide ASSEMBLY STAGE 29 ASSEMBLE AND SECURE HINGE BRACKET BASE 0204-46 AND HINGE BRACKET PIVOT 0204-56. 0204-46 / 0204-56 0204-46 0204-56 511-0023 ASSEMBLE HINGE BRACKET BASE 0204-46 AND HINGE BRACKET PIVOT 0204-56 SECURE HINGE BRACKET BASE 0204-46 ONTO STORAGE UNIT AS SHOWN.
  • Page 37 Bromley: Assembly Guide ASSEMBLY STAGE 30 LOCATE EACH FLOOR PANEL 0204-32 AS SHOWN. 0204-32 (x2) IMPORTANT: ENSURE THE HEXAGON PATTERN IS FACE UP. LOCATE EACH FLOOR PANEL 0204-32 INTO BASE OF STORAGE UNIT AS SHOWN.
  • Page 38 Bromley: Assembly Guide ASSEMBLY STAGE 31 LOCATE AND SECURE DOOR STRIP 0204-07. 0204-07 LOCATE DOOR STRIP 0204-07 AS SHOWN. SECURE DOOR STRIP ONTO FLOOR PANELS AT x6 LOCATIONS INDICATED. IMPORTANT: ENSURE DOOR STRIP IS PUSHED AGAINST DOOR POST RETURN. PLEASE NOTE: THE FIXING USED IS A SELF DRILLING COMPONENT.
  • Page 39 Bromley: Assembly Guide ASSEMBLY STAGE 32 LOCATE AND SECURE T-HANDLE 0204-58. 0204-58 0206-28 LOCATE T-HANDLE AND T-HANDLE GASKET 0204-58 SECURE T-HANDLE USING T-HANDLE ASSEMBLY NUT SECURE 2 POINT CAM 0206-28 ONTO T-HANDLE USING INTO LID 0204-17 APERTURE AS SHOWN. AS SHOWN.
  • Page 40 Bromley: Assembly Guide ASSEMBLY STAGE 33 LOCATE A BUMPER STOP 0204-61 AND GUIDE BUSH 0204-51 AT EACH LOCATION INDICATED. 0204-51 0204-61 APPLY BUMPER STOP 0204-61 ONTO LID AT LOCATION LOCATE GUIDE BUSH 0204-51 INTO LID TAB AS SHOWN. LOCATE GUIDE BUSH 0204-51 INTO LID TAB AS SHOWN.
  • Page 41 Bromley: Assembly Guide ASSEMBLY STAGE 34 LOCATE AND SECURE RODS 0204-57 AT EACH LOCATION INDICATED. 0204-57 0204-57 SLOT EACH ROD 0204-57 INTO POSITION AS SHOWN ABOVE. SECURE ROD ONTO 2 POINT CAM USING E-CLIPS (PART OF 0206-28 ASSEMBLY).
  • Page 42 Bromley: Assembly Guide ASSEMBLY STAGE 35 ASSEMBLE BIN LID CLIP ASSEMBLIES AND ATTACH ONTO LID AT EACH LOCATION INDICATED. 0204-65 0204-63 0204-65 0204-62 ASSEMBLE x3 BIN LID CLIP ASSEMBLES AS SHOWN ABOVE. ATTACH BIN LID CLIP ASSEMLIES ONTO LID AT EACH LOCATION INDICATED.
  • Page 43 Bromley: Assembly Guide ASSEMBLY STAGE 36 LOCATE LID ONTO STORAGE UNIT AND SECURE HINGE BRACKET AT EACH LOCATION INDICATED. LOCATE LID ASSEMBLY ONTO STORAGE UNIT AS SHOWN. SECURE HINGE BRACKET ONTO LID ASSEMBLY, DO THIS WITH THE LID DOWN. IMPORTANT: ONLY ATTACH AT FIXING POINTS INDICATED AT THIS STAGE.
  • Page 44 Bromley: Assembly Guide ASSEMBLY STAGE 37 SECURE LID AT REMAINING HINGE FIXING POINTS IMPORTANT: ENSURE LID IS SUPPORTED BY ANOTHER PERSON WHILST CARRYING OUT THIS PROCEDURE SECURE EACH HINGE BRACKET AT REMAINING FIXING AS SHOWN ABOVE. SECURE CENTRE HINGE BRACKET AS SHOWN ABOVE.
  • Page 45 Bromley: Assembly Guide ASSEMBLY STAGE 38 LOCATE AND GAS STRUTS 0204-25 AT EACH LOCATION INDICATED. IMPORTANT: ENSURE LID IS SUPPORTED BY ANOTHER PERSON WHILST CARRYING OUT THIS PROCEDURE 0204-25 FIX GAS STRUT 0204-25 ONTO BALL STUDS LOCATED ON LEFT-HAND SIDE OF UNIT.
  • Page 46 Bromley: Assembly Guide ASSEMBLY STAGE 39 LOCATE AND SECURE A CORNER BRACE 0204-03 AT EACH LOCATION INDICATED. 0205-36 LOCATE EURO MORTICE LOCK 0203-32 RIGHT-HAND DOOR APERTURE AS SHOWN. SECURE EURO MORTICE LOCK 0203-32 AT x2 LOCATIONS INDICATED ABOVE. SEE FOLLOWING DATA SHEET FOR COMPLETION OF MORTICE LOCK INSTALLATION...
  • Page 47 Bromley: Assembly Guide ASSEMBLY STAGE 39 CONTINUED LOCATE AND SECURE A CORNER BRACE 0204-03 AT EACH LOCATION INDICATED. 0203-34 LOCATE AND SECURE EURO ESCUTCHEON 0203-34 AS SHOWN. LOCATE EURO ESCUTCHEON COVER 0203-34 ONTO EURO ESCUTCHEON AS SHOWN. PLEASE NOTE: THESE ARE PUSHED ON AND WILL CLICK INTO PLACE.
  • Page 48 Bromley: Assembly Guide ASSEMBLY STAGE 40 LOCATE AND SECURE A CORNER BRACE 0204-03 AT EACH LOCATION INDICATED. 0203-40 0203-35 LOCATED AS SHOWN 0203-40 ENSURE THE PLUNGER INDICATED IS FACING THE BOTTOM OF THE DOOR, LOCATE SECURE EACH FLUSH DOOR BOLT ENSURING PLATE PACKER 0203-40 IS LOCATED AS SHOWN ABOVE AND SECURE USING ADJACENT FIXING METHOD.
  • Page 49 Bromley: Assembly Guide ASSEMBLY STAGE 40 CONTINUED LOCATE AND SECURE A CORNER BRACE 0204-03 AT EACH LOCATION INDICATED. 0203-35 FLUSH DOOR BOLT OPEN / CLOSE 0203-35 DOOR BOLT ATTACH DOOR BOLT ONTO FLUSH DOOR BOLT. ENSURE FLUSH DOOR BOLT OPENS AND CLOSES.
  • Page 50 Bromley: Assembly Guide ASSEMBLY STAGE 41 LOCATE AND SECURE A CORNER BRACE 0204-03 AT EACH LOCATION INDICATED. 0203-27 0203-28 0203-37 0203-37 0203-27 0203-28 0203-37 0203-37 LOCATE DOOR HINGE PLATE 0203-37 WITHIN DOOR AS SHOWN. SECURE DOOR HINGE PLATE AND HINGE 0203-27 AND 0203-28 AS SHOWN.
  • Page 51 Bromley: Assembly Guide ASSEMBLY STAGE 42 LOCATE AND SECURE DOOR HINGE PLATE 0203-37 AND LEFT-HAND HINGE 0203-27 AT EACH LOCATION INDICATE. 0203-27 0203-37 0203-27 0203-37 LOCATE DOOR HINGE PLATE 0203-37 WITHIN DOOR AS SHOWN. SECURE DOOR HINGE PLATE 0203-37 AND LEFT-HAND HINGE 0203-27 AS SHOWN.
  • Page 52 Bromley: Assembly Guide ASSEMBLY STAGE 43 LOCATE AND SECURE DOOR HINGE PLATE 0203-37 AND RIGHT-HAND HINGE 0203-28 AT EACH LOCATION INDICATE. 0203-28 0203-37 0203-28 0203-37 LOCATE DOOR HINGE PLATE 0203-37 WITHIN DOOR AS SHOWN. SECURE DOOR HINGE PLATE 0203-37 AND RIGHT-HAND HINGE 0203-28 AS SHOWN.
  • Page 53 Bromley: Assembly Guide ASSEMBLY STAGE 44 LOCATE DOOR ASSEMBLIES ONTO HINGES. 0204-22 0204-21 SLIDE EACH DOOR ASSEMBLY ONTO EACH OF THEIR RESPECTIVE HINGES. ASSEMBLED DOOR HINGE.

  • Page 54: Left-Hand Side

    Bromley: Assembly Guide ASSEMBLY STAGE 45 SECURE GAS STRUT BRACKETS 0205-66. LEFT-HAND SIDE 0205-66 (x2) 0205-68 (x2) RIGHT-HAND SIDE SECURE A BALL STUD 0205-68 ONTO EACH GAS STRUT ALIGN EACH GAS STRUT BRACKET WITH RELEVANT FIXING BRACKET 0205-66. HOLES, SECURE USING TYPICAL FIXING METHOD ABOVE.
  • Page 55 Bromley: Assembly Guide ASSEMBLY STAGE 46 LOCATE AND SECURE GAS STRUT 0205-63. SECURE A BALL STUD 0205-68 ONTO GAS STRUT BRACKETS THAT ARE PRE-RIVETED FIX EACH GAS STRUT 0205-63 ONTO BALL STUDS INDICATED ABOVE. PLEASE NOTE: PUSHES DOWN ON DOOR AND UPWARDS ON DOOR FRAME.
  • Page 56 Bromley: Assembly Guide ASSEMBLY STAGE 47 TEST ALL LOCKS / HANDLES AND TIGHTEN ALL FASTENERS TO COMPLETE ASSEMBLY IMPORTANT ADJUST ALL COMPONENTS FOR BEST POSSIBLE FIT AND TIGHTEN ALL FASTENERS. ONCE ALL FASTENERS HAVE BEEN CHECKED AND ARE SECURE THE ASSEMBLY IS COMPLETE.
  • Page 57 Bromley: Assembly Guide NOTES...
  • Page 58 Bromley: Assembly Guide NOTES...
  • Page 59 Bromley: Assembly Guide NOTES...
  • Page 60 Caring for your HEX Living product Your HEX Living product is designed to stand the test of time, which is why we’re happy to offer a lifetime warranty on our products. With zero maintenance required, simply assemble your HEX Living product,and enjoy putting it to great use in your garden.
