- Page 1 USERMANUAL BRAILLEX EL 80c, BRAILLEX EL 60c, BRAILLEX EL 40c Article code: 0090.459.00 | Version: 1.5.0 | Status: 06.2023...
-
Page 2: Table Of Contents
General Information ......................5 Copyright..........................5 Further authors / sources ....................5 Explanation of symbols ...................... 5 Shortcuts ..........................6 Intended use ........................6 Safety instructions ......................6 General precautions ......................7 Cleaning ..........................8 Packaging and Transport ....................8 Introduction ......................... - Page 3 Buttons on BRAILLEX EL c ....................... 19 The command lists ......................20 Navigation with the Braille display ..................20 Comfort while moving - the working modes ...............21 The BRAILLEX EL c in navigation mode ................21 Other functions for navigating with the Braille display ............22 The BRAILLEX EL c in PC mode ..................22 The BRAILLEX EL c in combined mode.
- Page 4 Errors and faults ........................30 Repair and maintenance ....................30 Warranty ...........................31 Warranty (only valid within Germany) ................31 Disposal ..........................31...
- Page 5 This user manual applies to the products BRAILLEX EL 40c, BRAILLEX EL 60c and BRAILLEX EL 80c. Manufacturer: F.H. Papenmeier GmbH & Co. KG Talweg 2 D-58239 Schwerte / Germany www.papenmeier-rehatechnik.de All technical data, information and properties of the product described in this work have been compiled to the best of our knowledge and correspond to the status at the time of publication.
-
Page 6: General Information
All contents of these instructions for use, especially texts, photographs and graphics, are protected by copyright. Unless expressly stated otherwise, the copyright lies with F.H. Papenmeier GmbH & Co. KG. Please ask us if you would like to use the contents of this manual. -
Page 7: Shortcuts
The expected service life of the medical device is 7 years. In order to achieve the expected service life of the product, a complete professional cleaning by the technical service of Papenmeier is recommended at intervals of a maximum of 2 years. This service is chargeable. -
Page 8: General Precautions
The medical device may only be used with the original parts provided and the combination products provided by Papenmeier. If a combination with products from other manufacturers is required, these must comply with the applicable statutory provisions. WARNING • Only operate this device in a dry environment. The device must never get wet, otherwise there is a health risk from electric shocks. -
Page 9: Cleaning
To avoid overstressing your hands and wrists through prolonged use of the controls and reading the Braille display, longer breaks and relaxation exercises are recommended. In specialist shops you will find literature on the ergonomic design of a workplace and posture, which can be used to reduce overexertion. -
Page 10: Introduction
Introduction Papenmeier has added three more devices to the BRAILLEX EL family BRAILLEX EL 40c, BRAILLEX EL 60c and BRAILLEX EL80c BRAILLEX EL 80c BRAILLEX EL 60c BRAILLEX EL 40c All three new EL devices have the patented Easy Access Bar which guarantees ergonomic work and comfortable one-hand-operation. -
Page 11: System Requirements
operate the Braille display. Often used PC keyboard functions are accessible from every hand position on the horizontal Braille display. In this way, your reading hand/s stay at their proper place. No longer will the user search or count out keys which is quite annoying. Additional hand movements or a constant re-orientation in the reading window will no more be necessary. -
Page 12: Installation And Connection
Installation and Connection Place the Braille display in the working position in front of the keyboard or in front of the notebook. Place your hands on the Braille cells to read, and your thumbs on the Easy Access Bar. Correct the position of the Braille display until it is optimal for your working position. -
Page 13: Commissioning
Braille display with buttons right and left Commissioning The device may only be commissioned by trained personnel. The operator must provide proof of this instruction. The device may only be put into operation if no damage to the device or the supply lines is visible and no malfunctions are to be expected (see Safety instructions, from page 6). -
Page 14: Display And Installation
Display and installation Without a screen reader, e.g. "JAWS for Windows", no display with the Braille display is possible. For the Braille display, the screen reader needs a driver. The driver must be installed separately for some screen readers, or more precisely, their versions. Possibly, the Braille display can also be selected during the installation of the screen reader. - Page 15 Device Manager dialog box Click with the right mouse button on the entry and click in the selection menu on "Update driver". Alternatively, you can also open the entry by double-clicking on it, then click on the "Update driver" button in the dialog. Now select "Search for drivers on my computer".
-
Page 16: Installation
Driver installation completion dialog box Installation If the installation from the disk does not start automatically, run the program "brxel-setup- 544b.exe". The following photo series shows the installation under Windows. Driver setup window 1 The driver installation starts. Activate the "Next" button. - Page 17 Driver setup window 2 After the system check, the next dialog box appears. Activate the "Install" button. Window driver setup finishing After a short time, the installation is complete. Activate the "Finish" button.
-
Page 18: The Easy Access Bar
The Easy Access Bar The Easy Access Bar of the BRAILLEX EL c series can be moved in one step each to the left, up, right and down. Thus, four functions are available. By default, the reading window of the Braille display moves in one of these four directions by pressing the Easy Access Bar and displays the corresponding content. -
Page 19: Configuring The Braille Display For Jaws
Configuring the Braille Display for JAWS Depending on the installation type, BRAILLEX EL was selected as Braille display during the installation of JAWS or is already set in the installation routine. The interface is also set with "USB" in the default. To check, open the Braille settings of the screen reader software. •... -
Page 20: Braille Options
Braille Options Here you can find commands for changing the braille mode, braille presentation for grade 2 translation and compression. Working Mode This list defines the current working mode of the Easy Access Bar. Buttons on BRAILLEX EL c On the left and on the right of the Braille cells, there are two push buttons each, with which you can perform individual functions for setting up the Braille display. -
Page 21: The Command Lists
The command lists When you have pressed one of the three buttons, a JAWS dialog box appears. The speech output reads out the title of the current settings dialog. The Braille display shows the first entry in the list. The list entry is always divided into two columns: On the left is the function, or •... -
Page 22: Comfort While Moving - The Working Modes
1 step to the right [R] shows the next text section, 1 step to the left [L] shows the previous text section. Note that the text is scrolled to the right or left by the number of cells in each case. A possibly desired word wrap can be activated in the Braille settings of the screen reader. -
Page 23: Other Functions For Navigating With The Braille Display
Other functions for navigating with the Braille display To quickly get to the beginning of the window (window title) or to the end of the window, use the second level of the Easy Access Bar in navigation mode. You activate the second level with the Easy Access Bar in combination with a lower routing key. - Page 24 Press button 3 [B3]. From the list that appears, use the Easy Access Bar on the right or left to select the "Working mode - combined mode" command and confirm with (Enter). • up [U] moves the cursor up one line, as in PC mode. down [D] moves the cursor down one line, as in PC mode.
-
Page 25: Functions With Braillex El C
Functions with BRAILLEX EL c Mouse actions with BRAILLEX EL c You execute mouse functions on BRAILLEX EL c using the routing keys. To perform a mouse action, move the reading window to the line where you wish to perform a click. -
Page 26: Attributes On The Braille Display
an attribute exists and for which characters it applies. If you want to know exactly which attribute is presented, use the function on the BRAILLEX EL c to determine the attribute. On the BRAILLEX EL c, press button 1 [B1] to show the command list for Braille marking. The list first shows the attribute at the current cursor. -
Page 27: Braille Mode
Define Braille presentation • Marking with dots 7 and 8 • If you want to change the Braille options for BRAILLEX EL c, press button 2 [B2]. Select one of the presented options and change the setting using the Easy Access Bar. Braille mode With the first entry of the list you switch the Braille display between th line mode and the structured mode. - Page 28 Find the entry "Braille presentation" with the Easy Access Bar. • • The current setting is displayed, e.g. "as on screen". This means that all spaces are also presented on the Braille display. • Use the space bar to select the other option, e.g. "Collect text". In this case, all spaces are compressed down to one space.
-
Page 29: Hide Points
Hide points If points 7 and 8, which are necessary for the presentation of computer braille, interfere with reading, they can be hidden. Press button 2 [B2]. • • The "Braille Settings" dialog appears. The list entry "Display in" indicates the current setting. •... -
Page 30: Appendix
Appendix Scope of delivery for BRAILLEX EL 40c • Braille display RS#1868.002.00 USB cable, USB-A, Mini-B,90°, approx. 0.5m R#3490.000070 • • USB cable, USB-A, Mini-B,90°, approx. 2m R#3490.000077 User manual in print ink, english R#0090.459.00 • Carrying case R#8522.000003 • Driver (Software) •... -
Page 31: Technical Data
Phone +49 2304 205 250 hotline@papenmeier.de If possible, please give a short description of the malfunction that has occurred. Repair and maintenance Repairs and maintenance may only be carried out by F.H. Papenmeier GmbH & Co. KG or by authorized companies. - Page 32 In the event of improper use or improper handling, any warranty shall expire. Warranty (only valid within Germany) Papenmeier warrants for a period of 36 months from the date of receipt that all components will operate substantially as described in the enclosed user manual.
- Page 33 WEEE disposal center or your local waste management company. Under the registration number DE60886380, the company F.H. Papenmeier GmbH & Co. KG is registered as a producer of electrical and/or electronic equipment at the Stiftung Elektro-...
