Page 11
VAXIS · ATOM 600 HDMI Wireless Video System To Vaxis Customers: Thank you for your recent purchase of the Vaxis Atom 600 HDMI. We created this product with you in mind and hope you will find the Atom 600 HDMI useful.
Page 12
Features ·500 feet transmission range ·Automatically switch channels ·<0.1s latency ·Firmware Upgrades via USB ·HDMI input and SDI input ·OLED display screen ·Support USB-C voltage input ·Stable & Reliable industrial metal ·iOS & Android App support housing Packing List Scan QR code to download product instructions User Card*1...
Page 13
Transmitter Interface NPF-970 Power Switch HDMI Output HDMI Input USB interface Menu/OK Down...
Page 14
Receiver Interface NPF-970 Power Switch HDMI Output HDMI Output USB interface Menu/OK Down...
Page 15
OLED Display QUALITY QUALITY 1080P60 1080P60 7.6v 7.6v Signal Strength Quality Linked RX Quality Battery Voltage Channel Battery Voltage Channel Video Format Video Format Channel Change Press either the up or down button on the transmitter to change the channel, then press the OK button to confirm the selected channel.
Page 16
PAIRING:ON PAIRING:ON PAIRING:ON PAIRING... PAIRING... PAIRING... SUCCESS FAILURE TIMEOUT BACK BACK BACK App Installation & Use Download Vaxis Vision on App Store or scan the QR code below to download Android APK file. Search: Vaxis Vision...
Page 18
Specification HDMI input/HDMI output HDMI output*2 Interface voltage 5V DC 5V DC Power <5w <3w 720P@50/60Hz HDMI Input 1080I@50/60Hz Video Format 1080P@24/25/30/50/60Hz 720P@50/60Hz HDMI Output 1080I@50/60Hz Video Format 1080P@24/25/30/50/60Hz Weight 150g 150g Dimensions 91*63.5*26mm 91*63.5*26mm Frequency 5GHz Transmission 17dbm Power Delay 80ms Rx sensitivity...
Page 19
Common Faults & Maintenance Connection issue 1.Check and make sure the power supply functions well on both the transmitter and the receiver. 2.Check if the battery level is enough, If the battery level is too low, Please change another battery. 3.Change to another channel to troubleshoot 4.Re-paring the device Display issue...
