Aiwa FX-W440 Service Manual

AIWA' eee moma
SERVICH MANUAL
MODEL NO.
Basic mechanism 2ME-1 (II)
2ME-4 (1)
TYPE.YB,YUB
tt
SPECIFICATIONS
Type Stereo cassette tape deck Dimensions 330 (W) x 106.5 (H) x345 (D) mm
Track format 4 tracks, 2 channels Weight 3.9 kg
Frequency
response METAL tape: 20—17,000 Hz
CrO, tape: 20—16,000 Hz
NORMAL tape: 20—15,000 Hz
Signal-to-noise
ratio 73 dB (METAL tape DOLBY C NR
ON)
Wow and flutter According toDIN45500 0.18%
0.065% (WRMS)
Tape speed 4.8 cm/sec. (1-7/8 ips), 9.5 cm/sec
(Double speed)
Rewind time 90 sec. (C-60)
Fast forward time 90 sec. (C-60)
Recording system AC bias (frequency 100 kHz)
Erase system AC erase
Motor DC Servomotor x 2
Heads Playback head x 1 (Deck })
Record/playback head x 1 (Deck I!)
Erase head x 1 (Deck Il)
over 47k). ratories Licensing Corporation.
