Summary of Contents for Lenovo R27i-30
- Page 1 Lenovo R27i-30 User Guide...
- Page 2 First Edition (May , 2023) © Copyright Lenovo 2023. LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.
-
Page 3: Table Of Contents
Contents Safety information ..................iv General Safety guidelines ....................iv Chapter 1.Getting started ................1-1 Shipping contents ......................1-1 Notice for use ........................1-2 Product overview ......................1-2 Setting up your monitor ....................1-5 Chapter 2.Adjusting and using your monitor ..........2-2 Comfort and accessibility ....................2-2 Arranging your work area ....................2-2 Positioning and viewing your monitor ...............2-2 Quick tips for healthy work habits ................2-3 Adjusting your monitor image ..................2-4... - Page 4 Appendix A. Service and Support .............. B-1 Registering your option ....................B-1 Online technical support ..................... B-1 Telephone technical support ..................B-1 Appendix B.Notices ..................B-2 Recycling information ....................B-3 Trademarks ........................B-4 Power cords and power adapters ................B-4...
-
Page 5: Safety Information
Safety information General Safety guidelines For tips to help you use your computer safely, go to: http://www.lenovo.com/safety Before installing this product, read the Safety Information. DANGER To avoid shock hazard: • Do not remove the covers. • Do not operate this product unless the stand is attached. -
Page 6: Chapter 1.Getting Started
This User’s Guide provides detailed operation instructions for the user. For quick instruction overview, please see the Setup Poster for brief information. Lenovo R27i-30 supports Lenovo Display Control Center -Artery. Shipping contents The product package should include the following items: ■... -
Page 7: Notice For Use
Notice for use To set up your monitor, please see the illustrations below. Note: Do not touch the monitor within the screen area. The screen area is glass and can be damaged by rough handling or excessive pressure. 1. Take out the Top cushion and accessories. 2. - Page 8 - Adjust the screen position before rotating the monitor screen. (Make sure that the monitor screen ascent to its highest point, and it inclines backward at 22°.) - Then rotate until the monitor stops at 90°. 90° 90° 135mm 1-3 R27i-30 Flat Panel Monitor User’s Guide...
- Page 9 Monitor controls The keypad controls on the panel frame are accesses to various functions. For information on how to utilize these keypad controls, please see “Adjusting your monitor image” on page 2-4. Kensington anti-theft lock Your monitor is equipped with a Kensington anti-theft lock located on the rear of your monitor.
-
Page 10: Setting Up Your Monitor
Note: Be sure to read the Safety information on page iv before carrying out this procedure. 1. Power off your computer and all attached devices, and unplug the computer power cord. 2. Connect the cables according to below icon indication. HDMI 1 HDMI 2 1-5 R27i-30 Flat Panel Monitor User’s Guide... - Page 11 3. For computer in DP connecting. 4. For computer in HDMI connecting. Note: For other regions Lenovo recommends that customers who require to use the HDMI input on their monitor purchase the "Lenovo HDMI to HDMI cable OB47070" http://www.lenovo.com/support/monitoraccessories HDMI HDMI Chapter 1.Getting started 1-6...
- Page 12 IEC 60227 (designation H05VV-F 3G 0.75mm2 or H05VVH2-F2 3G 0.75mm2 ) shall be used. Alternative a flexible cord be of synthetic rubber according to IEC 60245 (designation H05RR-F 3G 0.75mm2 ) shall be used. 1-7 R27i-30 Flat Panel Monitor User’s Guide...
- Page 13 8. Power on the monitor and the computer. 9. When you install the monitor driver, download the driver that corresponds to your monitor model from the Lenovo website https://pcsupport.lenovo.com/solutions/ r27i_30. Refer to the ““Manually installing the monitor driver” on page 3-6” section to install the driver.
-
Page 14: Chapter 2.Adjusting And Using Your Monitor
• Tilt: Adjust the tilt of your monitor to optimize the appearance of the screen content and to accommodate your preferred head and neck posture. • General location: Position your monitor to avoid glare or reflections on the screen from overhead lighting or nearby windows. 2-2 R27i-30 Flat Panel Monitor User’s Guide... -
Page 15: Quick Tips For Healthy Work Habits
The following are some other tips for comfortable viewing of your monitor: • Use adequate lighting for the type of work you are performing. • Use the monitor brightness, contrast, and image adjustment controls, if equipped, to optimize the image on your screen to meet your visual preferences. •... -
Page 16: Adjusting Your Monitor Image
(1)It is a shortcut for changing input signal while there Source- is no OSD on the screen or on power-saving mode. selecting (2)Press and hold for 5 seconds to Enable/Disable the "DDC/CI" . Power Press to turn On/Off the monitor. 2-4 R27i-30 Flat Panel Monitor User’s Guide... - Page 17 Using the On-Screen Display(OSD) controls To adjust the settings, the user controls can be viewed through the OSD. R27i-30 Game Mode Standard Game Settings Screen Settings Over Drive Level 2 Color Settings MPRT Port Settings FreeSync Premium Auto Refresh Rate Num...
- Page 18 Over clock depending on the user's environment. 2)The overclocking function will automatically be disabled after 30 minutes. Prolonged use of the overclocking function may result in abnormal screen display or other adverse effects. 2-6 R27i-30 Flat Panel Monitor User’s Guide...
- Page 19 OSD Icon on Controls and Sub menu Description Main Menu Adjustments Adjusts overall screen brightness. All input ports Note: If the brightness is continuously Brightness increasing, it will exceed the preset maximum brightness value and increase power consumption. Adjusts difference between light and dark Contrast areas.
- Page 20 *Low Blue Light: The display uses the low blue light panel. It complies with TÜV Rheinland Low Blue Light Hardware Solution certification under factory reset/default setting (Low Blue Light=Standard, Brightness:75%, Contrast: 75%, CCT: Warm). *Enable the display HDR function requires that the connected PC system supports the HDR function . 2-8 R27i-30 Flat Panel Monitor User’s Guide...
-
Page 21: Selecting A Supported Display Mode
Selecting a supported display mode The display mode the monitor uses is controlled by the computer. Therefore, refer to your computer documentation for details on how to change display modes. The image size, position and shape might change when the display mode changes.This is normal and the image can be re-adjusted using automatic image setup and the image controls. -
Page 22: Understanding Power Management
Accordingly, the customer should not rely upon this information in making decisions about electrical tolerances or otherwise. No warranty as to accuracy or completeness is expressed or implied. 2-10 R27i-30 Flat Panel Monitor User’s Guide... -
Page 23: Caring For Your Monitor
Caring for your monitor Be sure to turn off the power before you perform any maintenance on the monitor. Do not: • Apply water or liquid directly to your monitor. • Use solvents or abrasives. • Use flammable cleaning materials to clean your monitor or any other electrical equipment. •... - Page 24 For use only with UL Listed Wall Mount Bracket with minimum weight/load: Note: When you use a flexible arm, do not tilt the monitor downward by more than 5 degrees. The machine does not support 180° screen rotation. 3-1 R27i-30 Flat Panel Monitor User’s Guide...
-
Page 25: Chapter 3.Reference Information
Chapter 3.Reference information This section contains monitor specifications, instructions to manually install the monitor driver, troubleshooting information. Monitor specifications Table 3-1. Monitor specifications for type-model R27i-30 Dimensions Depth 258.75 mm (10.19 in.) Height 527.36 mm (20.76 in.) Width 613.58 mm (24.16 in.) - Page 26 Storage -20° to 60°C (-4°F to 140° F) Shipping -20° to 60°C (-4° F to 140° F) Humidity Operating 10% to 80% non-condensing Storage 5% to 95% non-condensing Shipping 5% to 95% non-condensing 3-3 R27i-30 Flat Panel Monitor User’s Guide...
-
Page 27: Troubleshooting
Troubleshooting If you have a problem setting up or using your monitor, you might be able to solve it yourself. Before calling your dealer or Lenovo, try the suggested actions that are appropriate to your problem. Table 3-2. Troubleshooting Problem... - Page 28 2-9 setup. When working in the native See the Advanced resolution, you may find section of your additional improvements by system’s display adjusting the Dots Per Inch properties. (DPI) setting on your system. 3-5 R27i-30 Flat Panel Monitor User’s Guide...
-
Page 29: Manually Installing The Monitor Driver
(such as a desktop)). 14. Select the “lenR27i-30.inf” file and click the Open button. Click the OK button. 15. In the new window, select LEN R27i-30 and click Next. 16. After the installation is complete, delete all downloaded files and close all windows. - Page 30 480 at a refresh rate of 60 Hz. Getting further help If you still can’t solve your problem, please contact the Lenovo Support Center. For more information on contacting the Support Center, please see Appendix A.“Service and Support”on page B-1.
-
Page 31: Appendix A. Service And Support
In addition, if your option is installed in a Lenovo computer, you might be entitled to service at your location. Your technical support representative can help you determine the best alternative. -
Page 32: Appendix B.notices
Web sites. The materials at those Web sites are not part of the materials for this Lenovo product, and use of those Web sites is at your own risk. -
Page 33: Recycling Information
Collecting and recycling a disused Lenovo computer or monitor If you are a company employee and need to dispose of a Lenovo computer or monitor that is the property of the company, you must do so in accordance with the Law for Promotion of Effective Utilization of Resources. -
Page 34: Trademarks
Trademarks The following terms are trademarks of Lenovo in the United States, other countries, or both: Lenovo The Lenovo logo ThinkCentre ThinkPad ThinkVision Microsoft, Windows, and Windows NT are trademarks of the Microsoft group of companies. Other company, product, or service names may be trademarks or service marks of others.
Need help?
Do you have a question about the R27i-30 and is the answer not in the manual?
Questions and answers
Why can I not enable vrr and allm with this monitor. Even though this monitor claims to have hdmi 2.1 ports and i **** using a hdmi 2.1 cable for my ps5. Whenever i try to turn on these things it says 'your tv does not support this feature'
The Lenovo R27i-30 monitor does not support Variable Refresh Rate (VRR) or Auto Low Latency Mode (ALLM) because its specifications do not mention HDMI 2.1 features. Even though you are using an HDMI 2.1 cable, the monitor itself must support these technologies. The R27i-30 primarily supports AMD FreeSync™ Premium, which works with AMD Radeon™ graphics cards, and enabling MPRT disables FreeSync. Since the PS5 relies on HDMI 2.1 VRR and ALLM for enhanced gaming performance, these features will not function on this monitor.
