- Page 1 7R Moving Head Beam Sharpy Light User Manual 230W Moving Head Beam Sharpy CE RoHS User Manual Please read this user manual before using this product！ Keep it for further reference! http://www.newfeellight.com...
-
Page 2: Table Of Contents
7R Moving Head Beam Sharpy Light User Manual Thank you for using our product! Please read this manual carefully and completely. For technical reference in future, please keep this user manual well. This user manual contains INDEX all installation and operation information of this Moving Head Sharpy Light, it’s very useful for user to install and operate the light. -
Page 3: Ⅲ Safety Information
higher than this. and unification; The Maximum surface temperature is 50°C ·It will ensure the light can putouts more colorful, more beautiful and more brightness; When suspending the fixture above ground level, verify that the structure can hold at ... - Page 4 Picture 2: The locking and releasing mechanism of Tilt, every 45 degree will LOCK or Picture 3: This light can be installed on the floor of the rubber feet, truss, the ceiling or UNLOCKED wall WARNING: The light must be connected with the safety rope, unless it is installed and posited on the floor...
-
Page 5: Ⅴ Menu Operation
Picture 6: Connect to the Control Single Cable (DMX-512 Single) Note: Please use the standard twisted signal cable which can shield the double electrodes. The characteristic impedance is 120 ohm. Don’t use the microphone cable or other different using single cable. You have to use the XLR type 3 pins male and female cannon connector to connect the terminal. - Page 6 reset calibration. Right Button Enter the menu, or confirm the setting Take the "modify DMX address code" as an example, show the use of button as below: If the current interface is not the main one, press the "Left" button (one or multiple) can get back to the main interface.
- Page 7 OK "button again, enter reset interface, all motor reset CH17~20 no function CH Mode Color wheel 0~255 Press the "OK" button to enter edit state. And it chosen the CH17~20 control the speed（See the channel table） hundred position, press the "Up" and "Down" button to ……...
-
Page 8: Ⅵ Dmx Protocol
Enter into the son interface from this, shows Yellow DMX channel value the numerical and percentage channel value Yellow + magenta for check Magenta Magenta + cyan If the red ERR light shine, it means the light has operation error, the details can be view Cyan Cyan +CTO260 in son interface. - Page 9 General dimmer .... 000←→255 Dimmer, 0-100% Gobo2 shake, fast speed ....(Gobo 3 to gobo 15) Static gobo change Gobo16 shake, slow speed White ..Gobo1 ..Gobo2 Gobo16 shake, fast speed Gobo17 shake, slow speed Gobo3 .... Gobo4 Gobo5 Gobo17 shake, fast speed...
- Page 10 Tilt Pink CH12 020←→255 Tilt movement, 0-250 degree Pink + yellow Yellow Tilt fine CH13 000←→255 Yellow + magenta Tilt fine adjust(16Bit) Function setting(reserved) Magenta CH14 000←→255 Magenta + cyan Reset Cyan 000←→025 Unused range Cyan +CTO260 CH15 026←→076 Effects reset CTO260 077←→127 Pan/tilt reset...
- Page 11 239←→251 Random fast strobe Gobo1 shake, fast speed 252←→255 Open, controlled by dimmer channel Gobo2 shake, slow speed General dimmer .... 000←→255 Gobo2 shake, fast speed Dimmer, 0-100% Static gobo change ....(Gobo 3 to gobo 15) Gobo16 shake, slow speed White ..
- Page 12 Pan fine CH11 000←→255 Pan fine adjust(16Bit) Tilt CH12 020←→255 Tilt movement, 0-250 degree Tilt fine CH13 000←→255 Tilt fine adjust(16Bit) CH14 000←→255 Function setting(reserved) Reset 000←→025 Unused range 026←→076 CH15 Effects reset 077←→127 Pan/tilt reset 128←→255 Complete reset Lamp control 000←→009 Unused range CH16...
-
Page 13: Ⅷ Technical Specification
Ⅷ TECHNICAL SPECIFICATION Input power AC100V~240V±10%/50~60Hz Light sources YODN MSD230 7R Lamp (Philips 7R 230W optional) Ballast Electronic ballast Color temperature 8000K Luminous flux 8250lm (6 meters) Intensity of illumination 65760lx (20 meters) Average life 2000 hours Color wheel 14 colors + white, forward and backward rotation Gobo wheel 17 fixed gobos + white, forward and backward rotation Prism...
