Product overview
2 This kit consists of main components required to
install an Easee Equalizer on a charging site with
3
one or multiple circuits. All of the components
are tested and guaranteed to work with the
3
Easee Equalizer (E02-EQP). Not for use with the
4
Easee Equalizer HAN version.
6
Energy Meter:
Eastron SDM630MCT-RJ12
Cable:
RJ12 6P6C 1.5m Cable x2
Current Sensor:
CT Clamp - ESCT-TU24 (3m length)
Rogowski Coil - ESCT-RC60
Connector:
CRJ-31 RJ12 Connector
Technical specifications
Eastron SDM630MCT-RJ12
Measurements (mm): H: 94,5 x W: 72 x D: 65
Voltage: 3 x 400V ac / 230V ac
Network frequency: 50/60Hz (± 2%)
Type: 3-phase 400 imp/kWh
IP-classification: IP51
Running temperature: -25°C - 55°C
Primary connection: 2,5mm2
100A Current Input: RJ12 100mA CT Clamp
500A Current Input: RJ12 85-100mV | 1KA
Output connection: RJ12 6P6C
Mounting: DIN-rail or alternative wall mount
with screw
Material: Self-extinguishing UI94 V-0
RJ12 cable
Length: 1.5m
Connector plug: RJ12
Lead cable: 6 pin
100A KIT CT Clamps
Input: Max 100A
Output: 100mA
Measurements (mm): H: 46 W: 29
Diameter: 15.7 mm
Running temperature: -15°C - +60°C
500A KIT Rogowski Coils
Input: 500A
Output: 85-100 mV | 1KA
Measurements (mm): L: 200
Diameter: 45-60 mm
Running temperature: -30°C - +80°C
Before you start
WARNING!
This product shall only be installed,
repaired or serviced by an suitable competent
and qualified electrician. All applicable local,
regional and national regulations for electrical
installations must be adhered to.
— Please check the safety instructions on
the manufacturer's user guides for all the
components of the kit.
— Make sure you have enough space on the DIN
rail for all the components. Minimum required
space is 126mm or 7 Modules
— The cable to the modbus can be extended
up to 200 meters. Please use appropriate
specification of cable for installation method.
— Ensure the Equalizer and the master
charger(s) will be connected to the same WiFi
network. The Equalizer requires connection to
a suitable and secure wifi network to ensure
correct operation.
— Main distribution unit or secondary
distribution unit / facade meter reader unit.
— Rogowski Coils must be fitted in the correct
orientation to read incoming power line.
— 10A triple pole fuse
— Install the Easee Installer App on your phone
by using the QR code below.
TIPS! Prepare installation in a new encapsulation
(not included):
— 4 Modules for Eastron 3-phase meter reader.
— 3 Modules for fuse 10A triple pole fuse
(Eastron 3-phase meter reader).
— 3 Modules for fuse of Easee Charging Robot
(not included)
