- Page 1 ® UHD-WPE230-K 18Gbps HDMI Over HDBaseT with Wall Follow us on Youtube and Facebook Plate Transmitter up to 230Ft U S E R M A N U A L www.orei.com...
-
Page 2: Table Of Contents
Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions Application Example Thank you for purchasing this product Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be dam- aged by electrical spikes, surges, electric shock, lightning strikes, etc. - Page 3 OREI Live Technical Support Hours US team (US/Canada/Mexico): Monday-Friday, 9 a.m. - 6 p.m. Central Time Support Email - info@orei.com | Support Number - 877-290-5530 Chat Live on www.orei.com Send us an instant message now. Our Technical Support Team will respond momentarily.
-
Page 4: Introduction
Introduction The UHD-WPE230-K HDBaseT Wall Plate Extender can transmit up to 4K@60Hz (4:4:4) video over a single CAT 6/6a/7 cable up to 130ft/40m or 1080p@60Hz up to 230ft/70m. It supports Power over Cable (PoC) functionality that allows for greater flexibility in installations. It also supports two-way IR and RS-232. -
Page 5: Features
Features 1. HDMI 2.0b 18Gbps, HDCP 2.2 compliant 2. Up to 4K@60Hz(4:4:4), 4K@30Hz, 1080p@120Hz 3. Up to 7.1 channels HD audio 4. HDBaseT™ over a single CAT 6/6a/7 cable up to 230ft/70m distance 5. One HDMI input, 1 Gang US Decora Wall Plate 6. -
Page 6: Package Contents
Package Contents 1 × 18Gbps HDMI Wall Plate 2 × Wideband IR Transmitter Transmitter 1 × 18Gbps HDMI Receiver 2 × Wideband IR Receiver 2 × Phoenix connectors (3 pins) 1 × 24V/1A Power Adapter 2 × Phoenix connectors (2 pins) 1 ×... - Page 7 Specifications Connection Inputs: 1 × HDMI Type A [19-pin female] 1 × IR INPUT [Phoenix jack] Transmitter 1 × RS-232 [Phoenix jack] Outputs: 1 × HDBaseT OUT [RJ45] 1 × IR OUTPUT [Phoenix jack] Inputs: 1 × HDBaseT IN [RJ45] 1 ×...
-
Page 8: Operation Controls And Functions
Operation Controls and Functions Transmitter Panel Name Function Description HDMI IN Connect to HDMI source devices such as Blu-ray or PS4. ACTIVE Green LED input signal indicator. HDBaseT HDBaseT output port. Connect to HDBaseT receiver with a UTP cable. 5V OUT Supply 5V power for external IR receiver. - Page 9 Operation Controls and Functions Receiver Panel Name Function Description POWER LED System power indicator. DC 24V Connect 24V/1A adapter to AC wall outlet for power supply. Standard HDBaseT signal input port. Connect to HDBaseT HDBaseT IN Transmitter with a UTP cable following the standard of direct interconnection method.
- Page 10 Operation Controls and Functions Name Function Description • Illuminated: The Transmitter and Receiver are in good Connection connection status. • Signal Flashing: The Transmitter and Receiver are in poor Indicator connection status. • Dark: The Transmitter and Receiver are not connected. •...
- Page 11 Operation Controls and Functions Description 2 ※ Bidirectional Infrared control Application Example HDMI Cable HDMI Cable UTP Cable TX 2 DVD Remote Description 3 ※ Bidirectional RS-232 control Application Example page 11...
-
Page 12: Application Example
Application Example IR Receiver Receiver Receiver Transmitter page 12... - Page 13 ® 18Gbps HDMI Over HDBaseT with Wall Plate Transmitter up to 230Ft UHD-WPE230-K www.orei.com © 2023...
