Specifications - SUNTEC SP500C Pro Operating Manual

Installing your dehumidifier
How to install the dehumidifier on the wheels?
How to install the dehumidifier on the ground?
Step 1: Lift up the dehumidifier and let it sit on
the wooden box as show on figure below.
Step 2: Take out the wheels from the accessory
bag and screw those wheels into the screw
thread on the base.
Step 3: Put the dehumidifier on the flat ground.
Step 4: Adjust the wheels height according to the
ground condition.
Step 1: Lift up the dehumidifier and let it sit on
the wooden box as show on figure below.
Step 2: Take out the floor mounted brackets from
the accessory bag and screw those brackets into
the screw thread on the base.
Step 3: Put the dehumidifier on the flat ground.
Step 4: Adjust the brackets height according to
the ground condition.

Specifications

Model SP500C Pro
Water Removal
50L per day
(30°C/80%RH)
Operating Temp.
1° - 40° C
Range
Operating
10% to 90% RH
Humidity Range
Compressor /
Rotary / R410A
Refringent
Power
720Watt
Consumption
Voltage / Cycle 220~240V/50Hz
Ampere 3.1A
3
Rated Air Flow 500 m /h
Noise Level 42dB(A)
Installation/ Mobile/ Floor Mount
mobility / Wall Mount
Touch-pad
Yes
control panel
Remote Control Yes
Defrost Type Hot-gas bypass
Air Filter Washable
Housing Hard Plastic
Drain Hose
2m
Length
Cable Length 3m
W x D x H 65 x 27 x 55cm
Use Weight 35kg
Specifications are subject to change without notice. Some values are approximate.
SP1000C Pro SP1500C Pro
100L per day 150L per day
1° - 40° C 1° - 40° C
10% to 90% RH 10% to 90% RH
Rotary / R410A Rotary / R410A
1500Watt 2050Watt
220~240V/50Hz 220~240V/50Hz
6.5 Amps 8.9 Amps
3 3
800 m /h 900 m /h
48dB(A) 48dB(A)
Mobile/ Floor Mount Mobile/ Floor Mount
/ Wall Mount / Wall Mount
Yes Yes
Yes Yes
Hot-gas bypass Hot-gas bypass
Washable Washable
Hard Plastic Hard Plastic
2m 2m
3m 3m
89 x 29 x 76cm 100 x 33 x 80cm
56kg 71kg
