Summary of Contents for Spring USA SM-351WCR
- Page 1 Fire Suppression MAX Induction Cooking Stations Owner’s Manual 127 Ambassador Drive, Suite 147 | Naperville, Illinois 60540 | Phone 630.527.8600 | Fax 630.527.8677...
-
Page 2: Safety Instructions And Warnings
Introduction • Do not place any objects inside the duct work that could get lodged Thank you for purchasing Spring USA’s Fire Suppression MAX Induction in the blower intake or wheel. Cooking Station. The Fire Suppresion MAX Induction Cooking Stations •... -
Page 3: Limited Warranty
Each induction unit can be removed from the cart for hassle-free • Installation and labor are not considered warranty and are not replacement. Spring USA offers a 1 year, overnight exchange warranty on covered by this warranty. all induction ranges for customers in the U.S. View the “Induction Range •... -
Page 4: Included Components
Included Components Check the pressure gauge on the fire suppression tank on a daily basis. Refer to the Buckeye Fire Suppression Manual for additional safety, PART NUMBER ITEM DESCRIPTION QUANTITY operating and maintenance instructions. MCS59-400 Baffle Filters This Appliance is equipped with a MANUAL PULL STATION that allows MCS59-401 Pre-Filter for a manual activation of the fire suppression system. -
Page 5: Power Off Procedure
Included Components As you turn the control knob the digital display will show the tem- perature, stop turning the knob when the desired temperature is MODEL VOLTAGE POWER PLUG displayed Power Off Procedure CONFIGURATION Turn the Control knobs on the appliance to the OFF-Position. NOTE: The filtration system will continue to operate for a period 5000W MCS-59-FPS-SP251G... - Page 6 Spring USA filters will void the warranty. To avoid service disruptions aluminum foil, cutlery, watches etc. on the heating surface of the it is recommended to keep a spare set of filters on hand. Spring USA induction appliance. Metallic objects heat up very quickly when assumes no liability for loss of business due to filter related shutdown.
- Page 7 Pre-Filter Replacement Procedure Pre-Filter The Pre-Filter (Part No. ) is a low cost disposable hi-temp MCS59-401 filter. Do not operate the appliance without the pre-filter, doing so will shorten the life of the HEPA filter. Do not attempt to clean the Pre-Filter, replace in 30 days or sooner.
- Page 8 Figure 5 Figure 4 Carbon Odor Filter Carbon Odor Filter (Part No. ) is a disposable odor filter that MCS59-403 should be replaced every 6 months or sooner. Remove the back panel by lifting up on it Open the rear access panel shown below Remove the carbon Odor Filter Replace the Carbon Odor Filter in the correct orientation (air-flow arrow pointing down)
-
Page 9: Cleaning Instructions
Cleaning Instructions WEEKLY CLEANING INSTRUCTIONS Open the front doors and remove the appliance AIR INTAKE CAUTION FILTERS shown below by pressing up on its corners. Allow Unit to cool and shutoff before cleaning. Clean the AIR INTAKE FILTERS in a dishwasher. Wipe the Filters DRY before inserting them back into the filter holders. - Page 10 Appliance Front View Appliance Rear View DESCRIPTION DETAILS Heavy-duty, Locking Casters 5" casters are more durable & easier to push than industry- standard 4" casters Door with Integrated Handle & Vents that release air after it has run through the 4-stage Airflow Grate filtration system Induction Control Box...
-
Page 11: Troubleshooting Guide
Inspect and replace dirt filters. power is reduced blockage • Confirm that ambient temperature is below 100°F CPU Battery Low Bad Battery Contact Spring USA for replacement. Required Maintenance Fire Suppression Fire suppression not Contact Spring USA or Buckeye Not Ready... - Page 12 Activate the Systems Releasing Module by releasing tension from Verify that the extinguishing system is in its proper location the end of the fusible link line by cutting or melting the last link. Verify that the manual actuators are unobstructed Make certain that the Systems Releasing Module fires, the gas 10.
- Page 13 Replace all fusible link detectors Replace motor input shaft seal. After testing the fusible link line, repair the terminal link and re-set Contact an Authorized Spring USA Distributor the control head immediately If any deficiencies are found. Once the Systems Releasing Module is reset, the mechanical pull Note: A record of monthly inspections is to be kept by the station must be checked.
- Page 14 Required Maintenance OWNER’S MONTHLY INSPECTION LOG DESCRIPTION FREQUENCY PERFORMED BY Fire Suppression System Inspection per Monthly Owner/User manufacturer’s recommendations Change Filter As Needed Owner/User Clean Mobile Cooking Unit following As Needed Owner/User Daily/Weekly and Monthly Instructions Perform semi-annual maintenance Semi-Annual Authorized Buckeye of the fire suppression system as Dealer...
- Page 15 Range works with induction-ready serving vessels. cabinet must not exceed 90°F / 32° C. Regularly inspect air intake grill Visit the Spring USA Website for a full line of induction-ready, on underside of ranges. Clean by vacuuming, as needed. Ventilation professional serve ware.
-
Page 16: Mounting Control Panel
PEAK POWER PLUG TYPE • The LED panel will display a three-digit number indicating the 208-220 Volts SM-351WCR 3500 Watts 50-60 Hz NEMA 6-20 6" Cord temperature setting. To increase the temperature setting, turn the 14.6 Amps dial clockwise To decrease the setting, turn the dial to the counter-... - Page 17 127 Ambassador Drive, Suite 147 Naperville, IL 60540-4079 P: 630-527-8600 F: 630-527-8677 springusa@springusa.com www.springusa.com...
