- Page 1 Urban Collection Fireplace Door Overlap & Inside Fit Installation & User Guide Installer please leave this with homeowner...
- Page 2 Thank You! Thank you for purchasing a Stoll Fireplace Enclosure! We are confident this quality product will last you for years to come. If you need further help or additional information regarding installation, please reach out to your local dealer for assistance.
- Page 3 Installation Methods Your installation kit contains hardware for multiple types of fireplaces and applications. See the descriptions below to see which type works best for your application. Lintel Clamp Pressure Mount Screws/Fasteners Mount/Fireplace Types Please see the list of mount types below and their location in this guide. Screw/Fastener Installation: ZC Inside Fit, (Page 4) Pressure Mount Installation: Masonry &...
- Page 4 Screw/Fastener Installation 1. Center the Fireplace Enclosure frame in the fireplace opening. 2. Using the 2” Self-Tapping Screws (H) or the appropriate fasteners for your fireplace material, fasten the frame to the firebox through the pre-drilled holes on the inside of the frame.
- Page 5 Pressure Mount Installation 1. Using the 1/2” Mounting Bolts (F), fasten two Multipurpose Brackets (A) to the threaded holes in the bottom flange of the frame. Choose the appropriate hole in the multipurpose bracket that allows the edge of the bracket to be as close as possible to firebox wall. Insert one Set Screw (G) into the threaded hole on each of the Brackets.
- Page 6 Lintel Clamp Installation 1. Assemble two Lintel Clamps by threading an adjustment nut (E), a flat washer (D), and a Multipurpose Bracket (A) onto a Lintel Bolt (B) in the order shown. 2. Attach the assembled Lintel Clamps to the threaded holes in the top flange of the frame.
- Page 7 Lintel Clamp continued.. 4. Center the Fireplace Enclosure frame in the fireplace opening. 5. Insulation (L) is provided to help close rough openings and gaps if desired. Cut pieces of insulation to length and fit them into the top and both sides of the enclosure frame. If frame is also overlapping on bottom, add insulation as needed.
- Page 8 • Your Stoll door and door frame finish can be cleaned using a damp cloth, or mild household cleaner. To avoid damage to the finish, cleaners containing ammonia or other harsh chemicals should be avoided.
