SPECIFICATIONS
CT-W620R/CT-W602R/CT-W502R
SYSTEM ivitanlienda iain Aeeiweekeeses 4-track, 2-channel stereo
"Hard Permalloy" recording/playback head xX 1
"Hard Permalloy" playback head X 1
"Ferrite" erasing head X 1
CT-W602R......... "Hard Permalloy" recording/playback head X 2
"Ferrite" erasing head X 2
WOtO eee ate ooesss cats sence fai ecaeow avant eget DC servo motor X 2
Wow and Flutter
CT -W620R ei ssctaesecthatedd arte: ness Gavdectente tht deere 0.09% (WRMS)
+0.19% (DIN)
CT-W602R/CT-W5O2QR.......cccccccccceeeeeeteeeerseeetenenneee -0.1% (WRMS)
Fast Winding Time............ Approximately 120 seconds (C-60 tape)
Frequency Response
—20 dB recording:
TYPE IV (Metal) tape ........... cc eesesseeeeeceenneseeneees 25 to 16,500 Hz
TYPE Il (High/CrO,) tape .......cccecescecssecesteeeeenerees 25 to 16,000 Hz
TYPE | (Normal) tape........ e s icecautes ctnsendovesieieeahane ete 25 to 16,000 Hz
Signal-to-Noise Ratio
Dolby NR OFF...........ccc0cccccccsssssstecceeceeeeeeeseeneeenees More than 57 dB
Noise Reduction Effect
Dolby B-type NR ON............cceeeeeeneees More than 10 dB (at 5 kHz)
Dolby C-type NR ON... cceeeeeeceeeee More than 19 dB (at 5 kHz)
Harmonic Distortion .........cccccccecccccesseeeesscessserseeess No more than 0.8%
(at —4 dB: 160 nwb/m)
Input (Sensitivity)
:
LINE (INPUT) ...... cc cececceeceees 100 mV (Input impedance 68 kQ)
MG save eiec Risteesteasivaueiionsvesstscostavtiveeened 0.63 mV (CT-W602R only)
Output (Reference level)
LINE (OUTPUT) .................0000 0.5 V (Output impedance 3.2 kQ)
Headphone .........cccccssssseeeeevees 0.63 mW (Load impedance 8 Q)
Subfunctions
@ AUTO BLE tuning system (CT-W620R/CT-W602R)
@ Automatic reverse
® Double recording/playback reverse (CT-W602R only)
@ DOLBY HX PRO recording function
@ DOLBY B/C type NR
@ Relay recording (CT-W602R only)
@ Music search over +15 selections
@ Synchronized copy start
@ High-speed and normal-speed copy (Deck | > Deck II)
@ Relay playback/biank skip
@ CD- DECK SYNCHRO recording capability
@ Peak level meter with peak-hold function
@ Automatic space recording mute
@ Automatic tape selector
@ | System remote control available
@ TIMER Recording
@ TIMER relay recording (CT-W602R only)
@ TIMER Playback (Automatic relay on)
@ 2-mode electronic 4-digit twin tape counter
@ Microphone jack with mixing recording from line input source
(CT-W602R only)
@ Headphone jack
@ FLEX system
Miscellaneous
Power Requirements
U.S., Canadian Models ............ccccccssssssseceeeeeesenees AC 120 V, 60 Hz
U.K. model... ccc cccccccccessseeeeseeevens AC 230—240 Volts~, 50/60 Hz
Power Consumption
CT-W620R xvvccievssthhesitscstedtevieccvestindeednaeisteees oem SENN 19W
GTS W602 ilccccdeicseiias vei vaveascesscvvsmeantinavasseasetevesuns Geastiee ees 18 W
CT WO 2R eisccecscecccedclectevcdvasieccavevas dastvacivsageets teavuevalguscessieseuente 16 W
Dimensions
CT-W620R/CT-W602R U.S. and
Canadian model.........cccccccccee 420 (W)X125 (H)X250 (D) mm
16-1/2 (W) X 4-15/16 (H) X 9-13/16 (D) in
CT-W502R U.S. and
Canadian model.............0. 420 (W) X 120 (H) X 250 (D) mm
16-1/2 (W) X 4-3/4 (H) X 9-13/16 (D) in
Weight (without package)
CT-WG620R/CT-WE02R..........:scscccccsssseeertseeeeerssees 4.3 kg (9 Ib 7 02.)
CT W502 aasvsccoveiiscehieabeaicenvuevnnetva ddnss covetsereceriaeee 4.2 kg (9 lb 4 oz.)
Accessories
Operating INStrUCtiONS ..........ccccccccccsssesssnceescsessstaasetsecessesssaaaeeanaeaenens 1
Connection Cord With Pin PIUGS .........ccccccccccssssececceeseresseenenssseeneeeenes 2
GA] Remote control COG ....ccccscscscescsessssesescssscsssesseeeseseseseaesssseeenees 1
CD - DECK SYNCHRO Control COrd ......ccccccesesssnneeeeeeesssseseensneeaeeees 1
NOTE:
Specifications and design subject to possible modifications with-
out notice, due to improvements.
