Summary of Contents for Oakcastle HIFI100
- Page 1 Instruction Guide Oakcastle HIFI100 Slim Micro Hifi Stereo System...
-
Page 2: Table Of Contents
Bluetooth Operation ................. Auxiliary Input Operation ................. Preset EQ .................. Mute ................X-bass Button ............... Sleep Operations ....................Snooze Operations .................. Specifications .................. Warranty + Support .................. Safety Information Year Register your product for a FREE Warranty 3-Year Warranty at www.oakcastle.co.uk... -
Page 3: Box Contents
Box Contents What is in the Box? Oakcastle HIFI100 Power Adapter Instructions Guide Remote Control... -
Page 4: Controls & Functions
Controls & Functions Top View/Control Buttons CLOCK 12 13 9 10 CD STOP BUTTON/ VOLUME DOWN (-) BUTTON BLUETOOTH PAIR BUTTON VOLUME UP (+) BUTTON CD/BLUETOOTH PLAY/PAUSE BUTTON POWER /STANDBY BUTTON CD OPEN/CLOSE BUTTON MODE BUTTON CD/BLUETOOTH SKIP PREVIOUS / FM CLOCK BUTTON TUNE- BUTTON SLEEP BUTTON... - Page 5 Controls & Functions Front View RIGHT/LEFT SPEAKER REMOTE SENSOR LED DISPLAY...
- Page 6 Controls & Functions Controls & Functions Controls & Functions Controls & Functions Remote Control 1. CD OPEN/CLOSE BUTTON POWER /STANDBYBUTTON 15. CD/BLUETOOTH SKIP NEXT 2. CD/BLUETOOTH SKIP PREVIOUS BUTTON BUTTON 3. PLAY/PAUSE BUTTON 16. CD STOP BUTTON 4. CD REPEAT BUTTON 17.
-
Page 7: Getting Started
Instruction Guide Instruction Guide GETTING STARTED POWER SOURCE This unit operates on AC 230V ~ 50Hz AC-DC adaptor household current and requires two "AAA" (UM-4) battery (included) for the remote control. Do not attempt to operate the unit from any other power source. You could cause damage to the unit and void your warranty. -
Page 8: Turning The Unit On/Off
Instruction Guide STANDBY MODE Standby Mode is when the unit is first plugged into an AC power source (display flashes and shows 00:00) or after all the settings have been made and the time is showing on the display. Standby mode is also enabled when the button is pressed and all functions (Bluetooth/Radio/CD/AUX) are off, no buttons are pressed and no alarms are sounding. - Page 9 Instruction Guide Instruction Guide Button on either the main unit or remote control to change Tap the between 24 Hour mode “24-H” and 12 Hour mode “12-H” if needed. 3. When “24H” is showing on the LED Display, press the CLOCK button on top of the main unit or remote control to select 24 Hour clock format.
-
Page 10: Alarm Operation
Instruction Guide ALARM OPERATION (REMOTE CONTROL ONLY) SETTING THE ALARM CLOCK This feature allows the system to turn on automatically and wake you using a beeping alarm, the CD or the RADIO. 1. In standby mode, press and hold the ALARM Button on remote control, hour digits of alarm clock start flashing. -
Page 11: Radio Operation
Instruction Guide Instruction Guide Wake to Radio, CD or Beeping Alarm • When the alarm time is reached, the CD, radio or beeping alarm will sound for the time you set then shut off and reset itself for the following day. •... - Page 12 Instruction Guide FM & FM-Stereo Reception - When listening to the FM radio, press the FM ST. button on remote control or main unit to switch between stereo mode and mono mode. The FM stereo icon “ST” will appear on the display if unit is in stereo mode. It is preferable to receive the program in mono when you are receiving a weak station.
-
Page 13: Cd/Mp3 Cd Operation
Instruction Guide RECALLING PRESET MEMORY CHANNELS In radio mode, to recall the pre-set channels by 1, Pressing the PRESET/MEMORY BUTTON on main unit, then tape the Button repeatedly to select the preset radio station you want. 2, Pressing P+ or P- Button on remote control repeatedly to select directly. CD/MP3 CD OPERATION PLAYING A CD 1. - Page 14 Instruction Guide 9. You can choose to play your favorite track directly by pressing either the SKIP NEXT Button or SKIP PREVIOUS Button. The LED Display will indicate the correct track number selected. 10. To locate a particular section within a track, press and hold the Button until the section is found.
- Page 15 Instruction Guide For example, to choose track 13 in the disc, a.) Press the “1” button once. b.) Press the “3” button within 2 seconds. To choose track 130 in the disc, a.) Press the “1” button once. b.) And then press the “3” button. c.) Finally press the “0”...
-
Page 16: Different Cd Play
Instruction Guide DIFFERENT CD PLAY MODES (REMOTE CONTROL ONLY) Press the REPEAT Button on remote control repeatedly to select different play modes when CD or MP3 CD is playing. Repeat Playing During playback press the REPEAT button once the display shows flashing “... -
Page 17: Bluetooth Operation
2. Tap the MODE Button to select Bluetooth mode, “PAIRING” message running in LED display is in search mode 3. If the HIFI100 has never been paired with a Bluetooth device before or cannot find the last paired device, the running message “PAIRING” on LED will indicate the search mode. -
Page 18: Auxiliary Input Operation
• Turn on the Bluetooth function of your Bluetooth device and enable the search or scan function to find the Oakcastle HIFI100. • Select " Oakcastle HIFI100 " from the device list when it appears on your device screen. If required, enter the pass code “0000” to pair (link) the your device. -
Page 19: Preset Eq
Instruction Guide 3. Turn on the unit and external audio device. 4. Tap the MODE Button to select AUX mode, “AUDIO IN” icon turns on, display shows the current time. 5. The volume level can now be controlled through the main unit. Operate all other functions on the auxiliary device as usual. -
Page 20: Sleep Operations
Instruction Guide SLEEP OPERATIONS (REMOTE CONTROL ONLY) The sleep timer allows you to turn the unit off after a designated time is reached. 1. To activate the sleep timer, turn the unit on and tap the MODE button to select FM Radio, CD, Bluetooth or listening to music via AUDIO IN 2. -
Page 21: Specifications
Warranty + Support All products come with a standard 12 month warranty. All items must be registered on www.oakcastle.co.uk for the warranty to be valid. Once on the web page, use the menu to find “Register Your Product”. You will also be given the chance to extend your warranty for an additional 24 months, free of charge. -
Page 22: Safety Information
ADDITIONAL WARNINGS 2. Keep these instructions. Instructions are also The apparatus shall not be exposed to dripping or available for download at www.oakcastle.co.uk splashing and no objects filled with liquid, such as 3. Heed all Warnings. vases, shall be places on the apparatus. - Page 23 www.oakcastle.co.uk...
