- Page 1 RDT-756U DIGITAL TV RECEIVER WITH PVR FUNCTION AND TIME SHIFT N Instruction manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions Front Panel
DESCRIPTION The RDT-756U is a digital TV receiver with PVR function with time-shift. It records digital TV programmes and reproduces video, audio and image files. Amongst other characteristics it has highly sensitive reception, it allows the choice of language in multi-audio channels and has and electronic programme guide EPG, list of favourites, etc. -
Page 5: Remote Control
REMOTE CONTROL 1.- STANDBY: on/standby mode. 2.- 0-9: number buttons. 3.- INFO: shows information on the current channel. 4.- MENU: shows the main menu on the screen. 5.- RECORD: to start recording the chosen programme. 6.- VOL+,VOL-: volume adjustment. 7.- TTX: shows teletext on the screen. 8.- MEDIA: shows the files recorded in the USB through the system. - Page 6 CONNECTION Before making any connections, switch off all the equipment and disconnect it from the mains. It is recommendable to read the whole manual before connecting anything. Respect the connector colour coding when you make the audio and video connections. Connect the digital TV receiver to a television with just one type of connector.
-
Page 7: Installation
INSTRUCTIONS FOR USE START UP When you switch the digital TV receiver on for the first time, a quick start menu will appear on the screen which will make the receiver set up and channel tuning easier. Once the initial configuration (region, language, etc.) has been chosen, select OK and the automatic channel search will start. - Page 8 AUTO SCAN This lets you perform an automatic channel search. Select AUTO SCAN and press the OK button to access the menu. Press the movement buttons and select FTA ONLY, place the cursor over the SEARCH option and press OK to start the search. Manual scan This lets you perform a manual channel search.
-
Page 9: Channel Changing
When LCN (Logical Channel Number) is activated, the numbers of each TV channel assigned during tuning cannot be modified. You can activate or deactivate the LCN function. It is important to deactivate this option if you want to order the channels according to your preferences in the Channel editing >TV channel list menu option. -
Page 10: Channel Edit Menu
EDIT CHANNEL CHANNEL EDIT MENU Press the MENU button to access the main menu. Press the up/down buttons to choose the EDIT CHANNEL option and press the right button to enter the EDIT CHANNEL menu. Press the up/down buttons to choose the desired option and press OK to enter the submenu. Press the EXIT button to exit. -
Page 11: Sorting The Channel List
SORTING THE CHANNEL LIST To order the channel list, access the CHANNEL EDITING list and use the option MOVE to change the position of a channel within the list. The LCN option must be deactivated in order to move a channel. Check the LCN option in the INSTALLATION>Aerial adjustment menu. -
Page 12: System Setup Menu
SYSTEM SET UP This lets you set the language, TV system, date and time, timer, parental lock, OSD options, favourites and auto standby. SYSTEM SET UP MENU Press the MENU button to access the main menu. Press the up/down buttons to choose the SYSTEM SET UP option and then press the right button to enter the SYSTEM SET UP menu. -
Page 13: Time Setting
TV SYSTEM This lets you set the display mode, the aspect mode and the video output. Display mode: 480i/576i. Aspect mode: Auto/4:3PS/4:3LB/16:9. Video output: CVBS/RGB. TIME SETTING This lets you set the region, time and date. Region: to change the region setting. GMT Usage: to activate or deactivate GMT time zone. -
Page 14: Timer Setting
TIMER SETTING This lets you set the timer/programmer. Up to 8 timers can be set. Timer mode: Off/once/daily/weekly/monthly. Timer service: Channel/record. Wakeup channel: Select the desired channel to switch on as an alarm. Wakeup date: Insert the alarm date with the number buttons. Wakeup time: Insert the alarm time with the number buttons. -
Page 15: Osd Setting
OSD SETTING This lets you set the duration of the OSD, transparency and the original OSD load. OSD timeout: The time that it takes for the menu to disappear if nothing is touched. Transparency: This lets you set the transparency level of the menu to the values: Off/10%/20%/30%/40%. OSD Load default setting: This lets you re-establish the OSD default values. -
Page 16: Auto Standby
AUTO STANDBY On: If the device does not receive any signal on its front panel or in the remote control and no timers have been programmed, it will switch itself off in 3 hours. Off: It will not switch itself off automatically. TOOLS This menu lets you upgrade the receiver software and load default values amongst other options. -
Page 17: Load Factory Setting
LOAD FACTORY SETTING This menu lets you reset the system with the default values, deleting all channels. In the TOOLS menu, select LOAD FACTORY SETTING and press the OK button. You will be asked for a password (the password by default is 0000). A window will appear asking for confirmation. - Page 18 TO SAFELY REMOVE THE USB In the TOOLS menu, select DISK REMOVE. Press the OK button to confirm and a message will appear. Press the OK button again for the message to disappear. - 18 -...
- Page 19 GAMES This menu lets you access GAME. Press the MENU button to access the main menu. Press the up/down buttons to choose GAME and press the right button to enter the games menu. Use the up/down buttons to choose the desired option and press the OK button to enter the game. Press the EXIT button to exit.
-
Page 20: Usb Device
USB DEVICE This lets you reproduce files from the USB device. In the REC menu, select USB DEVICE and press the OK button to enter the MEDIA PLAYER menu. You can also access it through the USB button on the remote control. Press the up/down buttons to choose the desired option and press the OK button to reproduce the desired files. -
Page 21: Disk Information
DISK INFORMATION This lets you show some parameters from the removable device. In the REC menu, select DISK INFORMATION and press the OK button to open the disk information window. Press the EXIT button to exit. DVR SET Press the green button on the remote control to open the DVR SET menu. Use the left/right buttons to change the DVR type (REC&TMS/record/time shift). - Page 22 DVR CONFIGURATION (DIGITAL VIDEO RECORDER) This menu lets you set the DVR. Press the up/down buttons to choose the desired option and press the left or right buttons to change the configuration. Time shift: On/Off. Standby after record: On/Off. JUMP Press the left/right buttons to change the jump time.
-
Page 23: Special Functions
SPECIAL FUNCTIONS SORTING THE LIST OF CHANNELS To sort the list of channels, access the CHANNEL EDITING menu and use the option MOVE to move the position of a channel within the list. The LCN option must be deactivated in order to move a channel. Check the LCN option in the installation>aerial adjustment menu. -
Page 24: Troubleshooting
TROUBLE SHOOTING In some places the digital TV signal can be weak. To see the channels with the weakest signal, you must provide the receiver with a suitable level signal. Re-position the aerial and check the state of the amplifier. PROBLEMS POSSIBLE CAUSE WHAT TO DO... -
Page 25: Specifications
SPECIFICATIONS RDT-756U CHARACTERISTICS Digital TV receiver. Video recorder (PVR with time shift): records and plays digital TV programmes. USB controller host port, FAT and NTFS file format. Multimedia video, audio and image file player. Output formats: 576i and 480i. SD standard definition output through Scart. -
Page 26: Declaration Of Conformity
This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los...
