Delta 3582LF Series Manual

Delta 3582LF Series Manual

Two handle widespread lavatory faucet
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
ASME A112.18.1 / CSA B125.1
ASME A112.18.2 / CSA B125.2
ICC/ANSI A117.1
Model/Modelo/Modèle
3582LF
Series/Series/Seria
®
Rhythm
For easy installation of your Delta
faucet you will need:
• To READ ALL the instructions completely before
beginning.
• To READ ALL warnings, care and maintenance
information.
• To purchase the correct water supply hook-up.
Para instalación fácil de su llave Delta
usted necesitará:
• LEER TODAS las instrucciones completamente
antes de empezar.
• LEER TODAS los avisos, cuidados, e información
información de mantenimiento.
• Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet Delta
facilement, vous devez:
• LIRE TOUTES les instructions avant de débuter;
• LIRE TOUTES les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
• Acheter le bon nécessaire de raccordement.
65715
You may need/Usted puede necesitar/
Articles dont vous pouvez avoir besoin:
65715
1
TWO HANDLE WIDESPREAD
LAVATORY FAUCET
LLAVE DE LAVAMANOS
EXTENDIDAS DE DOS MANIJAS
ROBINET À ENTRAXE LONG À
DEUX POIGNÉES POUR LAVABO
?
7/18/12 Rev. B

Advertisement

loading

Related Manuals for Delta 3582LF Series

Summary of Contents for Delta 3582LF Series

  • Page 1 • To READ ALL warnings, care and maintenance information. • To purchase the correct water supply hook-up. Para instalación fácil de su llave Delta usted necesitará: • LEER TODAS las instrucciones completamente antes de empezar. • LEER TODAS los avisos, cuidados, e información información de mantenimiento.
  • Page 2 Install handles (1) on end valves using hex wrench (2). Slide Install spout (1) and gasket (2). Secure with washer and nut (3). Option: If sink is uneven, use silicone under hot (3) and cold (4) end v alves with gaskets (5) through sink. Note: hot side end valve is labeled (6).
  • Page 3 Metal Pop-up Apply silicone to underside of flange (1). Insert body Remove pivot nut (1). Install horizontal rod (2) and Remove stopper (1) and flange (2). (2) into sink. Screw flange (1) into body (2). stopper (3) as removable (4) or non-removable (5). Screw nut (1) all the way down.

  • Page 4: Maintenance

    1/2" (13 mm) IPS Maintenance Make Connections to water lines: Remove aerator (1) and turn faucet handles (2) all the way on. Turn on hot and cold water supplies (3) and flush water lines for Choose hook-ups for 1/2" I.P.S. connections: If faucet leaks from spout outlet–Shut off water supplies–...
  • Page 5 ▲ Specify Finish ▲ Especifique el Acabado ▲ Précisez le Fini RP6060 Bonnet Nuts RP61989▲ Bonetes/Capuchones Lift rod Chapeaux Filetés Varilla tirador Tirette de vidage RP24097 1/4 Turn Stop Tope a un 1/4 de Giración RP19754▲ Butée 1/4 de Tour Aerator - 1.5 GPM (5.7 L/M) Aireador - 1.5 GPM (5.7 L/M) RP24096...

  • Page 6: Cleaning And Care

    Any damage to this faucet Delta Faucet Company Masco Canada as a result of misuse, abuse or neglect, or any use of other than genuine Delta® replacement Product Service Technical Service Centre parts WILL VOID THE WARRANTY.
