- Page 1 Quick Installation Guide Grid-Tied PV Inverter (CSI3600 CSI5000 CSI6000 ) V1.0-2023-06-30...
-
Page 2: Safety Disclaimer
Safety Precautions General Disclaimer • The information in this quick installation guide is subject to change due to product updates or other reasons. This guide cannot replace the product labels or the safety precautions in the user manual unless otherwise specified. All descriptions here are for guidance only. •... -
Page 3: Check Before Power-On
Product: 1. Do not apply mechanical load to the terminals, otherwise the terminals can be damaged. 2. All labels and warning marks should be visible after the installation. Do not scrawl, damage, or cover any label on the device. 3. Unauthorized dismantling or modification may damage the equipment, the damage is not covered under the warranty. -
Page 4: Eu Declaration Of Conformity
EU Declaration of Conformity Viridian Solar Ltd. hereby declares that the inverter with wireless communication modules sold in the European market meets the requirements of the following directives: • Radio Equipment Directive 2014/53/EU (RED) • Restrictions of Hazardous Substances Directive 2011/65/EU and (EU) 2015/863 (RoHS) •... - Page 5 Inverters Designed without LCD Indicator Status Description ON = EQUIPMENT POWER ON OFF = EQUIPMENT POWER OFF ON = THE INVERTER IS FEEDING POWER OFF = THE INVERTER IS NOT FEEDING POWER SINGLE SLOW FLASH = SELF CHECK BEFORE CONNECTING TO THE GRID SINGLE FLASH = CONNECTING TO THE GRID ON = WIRELESS IS CONNECTED/ACTIVE...
- Page 6 Product Introduction Parts DC Switch DC switch Locking Hole PV Input Terminal Communication RS485/Remote Shutdown/ Module/RS485-USB CT/Meter Communication AC Output Terminal Cable Port Cable Port DRED/Dry Contact Communication Cable PE Terminal Indicator Port LCD(optional) Button(optional) Mounting Plate Heat Sink [1] For Australia only.
-
Page 7: Inverter Installation
Dimensions Inverter Installation N = Quantity depends on the inverter model. - Page 8 Space Requirements Children No Touch ≥300mm ≥200mm ≥200mm ≥300mm ≥500mm ALT: 4000m (*3000m for IP66 Australia) 0%~100%RH...
- Page 9 Angle Requirements Installing the Inverter For Australia only.
- Page 10 Electrical Connection PE Cable Copper,...
- Page 11 AC Cable Click AC-1 AC-2 AC-1 Copper, 2.5mm ≤S≤6mm Click...
- Page 12 AC-2 Copper, DC Cable Click...
- Page 13 Vaconn Click Click...
- Page 14 Staubli MC4 ≤S≤6mm Click Click...
- Page 15 Communication Connection Function Definition Function Definition RS485+ Meter+ RS485 Meter RS485- Meter- Remote Shutdown RSD+ (For Europe only) or Rapid ShutDown (For North America only) or Emergency RSD- Power Off(For India only) I/O1+ DRM1/5 I/O1- DRM2/6 I/O2+ DRM3/7 DRED ( For Australia Dry Contact only.
- Page 16 RS485 Meter Remote Shutdown or Rapid Shutdown or Emergency Power Off Dry Contact DRED RS485 1: RS485+ 2: RS485- Meter Remote Shutdown or 11: Meter+ Rapid Shutdown 12: Meter- or Emergency Power Off 3: RSD+ 13: CT+ 4: RSD- 14: CT- Contact DRED 5: I/O1+...
- Page 17 Communication Module WiFi kit, LAN kit, 4G kit, GPRS, Bluetooth Kit, Wi-Fi/LAN Kit module: optional. RS485-USB Cable: Brazil.
- Page 18 Power On and Off Inverter AC Breaker Grid DC Isolator (Optional) Power ON Turn on Power OFF Turn off For Australia only.
- Page 19 Commissioning Commissioning via LCD Set country code Select Country code 1 Country/Region Setting is completed Country code 2 successfully Commissioning via WE Mate APP play WE Mate App Store <10m <5m WE Mate APP Monitoring via Solar Portal App play Solar Portal App Store Solar Portal APP...
