Front
Panel
Headphones Volume Control
Adjust the headphones volume
by turning this dial left or right.
Side
Panel
Figure 1-3:
Power LED
Lights up blue when Sound
Blaster is connected to your
computer.
Microphone jack
Connects to an external
microphone.
Headphones jack
Connects to a pair of
headphones. Your speaker
output is muted when you
connect the headphones to
Sound Blaster.
USB port
Connects to the
computer's USB port
using a USB cable.
Jacks, connectors and ports on Sound Blaster
Digital/Analog switch
Switches between Digital Only
and Digital/Analog modes.
About Sound Blaster
1-3
