Creative Sound Blaster for iTunes User Manual

Sound Blaster for iTunes®
and
Sound Blaster Wireless Receiver
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
Sound Blaster for iTunes ®
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
and
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
Sound Blaster Wireless Receiver
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to
channels 1 through 11.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF
exposure compliance. To maintain compliance with FCC RF exposure compliance
requirements, please follow operation instruction as documented in this manual.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
SAR compliance has been established in typical laptop computer(s) with USB slot, and
product could be used in typical laptop computer with USB slot. Other application like
handheld PC or similar device has not been verified and may not compliance with related RF
exposure rule and such use shall be prohibited.
WARNING: Handling this product may expose you to chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm. Wash hands after handling.
Explanatory Note
California Safe Drinking Water and Toxic Enforcement Act of 1986 (Proposition 65) requires special product
labeling for products containing certain chemicals known to the State of California to cause cancer, birth defects
or other reproductive harm. Creative has chosen to provide a warning based on its knowledge about the presence
of one or more listed chemicals without attempting to evaluate the level of exposure. With Creative's products, the
exposure may be below the Proposition 65 level of concern, or could even be zero. However, out of an abundance
of caution, Creative has elected to place the Proposition 65 warning on its products.
Copyright © 2009 Creative Technology Ltd. All rights reserved. The Creative logo, Sound Blaster, X-Fi, CMSS, and
Crystalizer are trademarks or registered trademarks of Creative Technology Ltd. in the United States and/or other
countries. iPod and iTunes are registered trademarks of Apple Inc., registered in the U.S. and other countries.
PN 03SB117000001 Rev.A
Product Registration
Registering your product ensures you receive the most appropriate service and product support
available. You can register your product at www.creative.com/register.
Please note that your warranty rights are not dependent on registration.
Technical & Customer Support Services
Go to www.creative.com/support to resolve and troubleshoot technical queries at Creative's
24-hour self-help Knowledge Base. You can also find Customer Support Services and other
helpful information here.
Other Information
Warranty Warranty information is supplied with your product.
Please keep your Proof of Purchase for the duration of the Warranty period.
User's Guide Download the user's guides at
www.soundblaster.com/SBWirelessReceiver
www.soundblaster.com/SBforiTunes
Keep this document for future reference.
1 1
1
Setting Up Your Audio Device
This
(a) USB port
(b) Desktop computer
(c) Notebook computer
3
3
Connecting Your Receiver
Stereo to RCA cable
1b
OR
Stereo cable
1c
Powered stereo or
1a
2.1 speakers LINE
OUT
4
4
Pairing Your Audio Device (Transmitter) and Receiver
Turn on Transmitter and Receiver
1
The transmitter's
wireless features are
enabled by default and
the Link LED should light
up. If not, enable it in the
Entertainment Console.
Sound Blaster Wireless Receiver
Auto pairing
2
The Link LED on the receiver flashes and then remains on when pairing is
successful.
NOTE
If your transmitter and receiver do not pair, simply
reset them. On one unit at a time, press and hold the
Connect button for five seconds.
2
2
Installing Software
Your transmitter is operational without any software installation.
However, to enjoy all the features, install the drivers and applications
provided on the installation CD.
For Windows Vista ® and Windows ® XP
1. If prompted for the audio drivers, click the Cancel button.
2. Insert the Installation CD into your CD or DVD drive. Your CD should
start automatically. If it does not, follow the steps below:
i. Click Start -> My Computer.
ii. Right-click the CD or DVD drive icon, and then click Open
Autoplay or Autoplay.
3. To complete the installation, follow the instructions on the screen.
4. When prompted, restart your computer.
For Mac OS
1. Insert the Installation CD into your CD or DVD drive.
2. Double-click the <CREATIVE> icon.
3. Double-click the <Install> icon.
4. To complete the installation, follow the instructions on the screen.
1
3
LINK/ 5v DC
CONNECT
Power
2a
adapter
Power
2b
outlet
Play and stream music from Transmitter
3
BASS TREBLE VOLUME
OFF MAX
AUX IN
NOTE Place your receiver up to 30 meters (approximately 100 feet) away from
your transmitter.
Place your transmitter or receivers away from large metal surfaces.
See the receiver's User's Guide:
- to pair two or more receivers to your transmitter
- if you are having difficulties pairing your transmitter and receiver
2
