- Page 1 PMLN8502_ IMPRES Retainer Quick Reference Guide FEBRUARY 2023 *MN009520A01* MN009520A01-AA © 2023 Motorola Solutions, Inc. All rights reserved...
-
Page 2: Safety And Legal
License Rights The purchase of Motorola Solutions products shall not be deemed to grant either directly or by implication, estoppel or otherwise, any license under the copyrights, patents or patent applications of Motorola Solutions, except for the normal non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product. -
Page 3: Warranty
Motorola Solutions will not honor any warranty claim where the Product is used in such a combination and it is determined by Motorola Solutions that there is no fault with the Product. Upon open or dismantle the Product, the warranty is immediately voided. Motorola Solutions specifically disclaim any responsibility for any damage in any way caused by improper installation by unauthorized personnel. - Page 4 Your organization received support phone numbers and other contact information appropriate for your geographic region and service agreement. Use that contact information for the most efficient response. However, if needed, you can also find general support contact information on the Motorola Solutions website, by following these steps: 1 Enter motorolasolutions.com...
-
Page 5: Icon Conventions
MN009520A01-AA Icon Conventions Icon Conventions The documentation set is designed to give the reader more visual clues. The following graphic icons are used throughout the documentation set. DANGER: The signal word DANGER with the associated safety icon implies information that, if disregarded, will result in death or serious injury. - Page 6 MN009520A01-AA Chapter 1 : Assembling Retainer to a Plug Connector Chapter 1 Assembling Retainer to a Plug Connector Follow the numbering in the image to perform the required actions. Scan here to view the assembly video. https://youtu.be/VB9BpnTq0NQ Procedure: 1 Push up the latch on the retainer. 2 Hook the lower part of the retainer into the plug connector cable.
- Page 7 MN009520A01-AA Assembling Plug Connector to Your Radio Chapter 2 Assembling Plug Connector to Your Radio Follow the numbering in the image to perform the required actions. Scan here to view the assembly video. https://youtu.be/o3roBaDYE40 Procedure: 1 Open the dust cover. 2 Rotate the dust cover down.
- Page 8 MN009520A01-AA Chapter 3 : Disassembling Plug Connector from Your Radio Chapter 3 Disassembling Plug Connector from Your Radio Follow the numbering in the image to perform the required actions. Scan here to view the disassembly video. https://youtu.be/XNWFrVC4rU4 Procedure: 1 Unlock the sub-assembly by pulling up the retainer latch. 2 Slide down the retainer until you hear a click.
- Page 9 MN009520A01-AA Disassembling Retainer from a Plug Connector Chapter 4 Disassembling Retainer from a Plug Connector Follow the numbering in the image to perform the required actions. Scan here to view the disassembly video. https://youtu.be/9Q9gPnI_icM Procedure: 1 Pull back the top part of the retainer from the plug connector. 2 Slide down then remove the retainer from the plug connector.
