QUICK REFERENCE GUIDE - SKULL CANYON AND HADES CANYON CEC ADAPTER
V 2.1
AND HADES CANYON
INTRODUCTION
HDMI-CEC allows devices connected to the TV through HDMI ports to communicate back and forth with the TV.
The TV can have some control over the devices, and the devices can have some control over the TV.
With the Pulse-Eight Intel NUC HDMI CEC Adaptor, the Skull and Hades Canyon NUC can be controlled with one
remote. Just directly attaches the Pulse-Eight Intel NUC HDMI CEC Adaptor to the top access port and requires
no cable loom.
FEATURES
• Works in both Skull Canyon and Hades Canyon systems.
• Directly attached
• No cable needed
SPECIFICATIONS
SKU:
Operating Temp Range:
Operating Humidity Range:
Certification:
SKULL CANYON
CEC ADAPTER
P8-SKULLHADESCEC
0 to +35°C (32 to +95°F)
5 to 90% RH (no condensation)
CE, FCC, RoHS
1
Advertisement
Table of Contents
Related Manuals for PULSEEIGHT P8-SKULLHADESCEC
Summary of Contents for PULSEEIGHT P8-SKULLHADESCEC
- Page 1 FEATURES • Works in both Skull Canyon and Hades Canyon systems. • Directly attached • No cable needed SPECIFICATIONS SKU: P8-SKULLHADESCEC Operating Temp Range: 0 to +35°C (32 to +95°F) Operating Humidity Range: 5 to 90% RH (no condensation) Certification:...
- Page 2 QUICK REFERENCE GUIDE - SKULL CANYON AND HADES CANYON CEC ADAPTER INSTALLATION Skull Canyon NUC 1. Remove the 6 screws from the Skull Canyon. 2. Remove the cover from the system. 3. Connect the CEC adapter into the expansion slot and close up the main cover. Hades Canyon NUC 1.
- Page 3 QUICK REFERENCE GUIDE - SKULL CANYON AND HADES CANYON CEC ADAPTER TROUBLESHOOTING Should you encounter installation difficulties or issues with device communication, the following checklist of common issues and causes should help resolve your issues. If you still continue to experience issues, please contact your local representative for further assistance.
