  • Page 1 All manuals and user guides at all-guides.com rs- ba1 remote control software quick reference guide...

  • Page 2: Table Of Contents

      Setting up Port Forwarding   ........................  5   Setting up the RS-BA1 Remote Utility Software for the Base Station   ..........  8   Connection Errors   ..............................   1 6   Setting up the RS-BA1 Remote Control Software  ............  1 7  ...

  • Page 3: Requirements

    This  router  should  be  connected  directly  to  the  Internet   Desktop  or   L aptop  computer  at   t he  Remote  Station   t hat  is  On   t he  Internet   ( different  Network  than   t he  Icom  ...
  • Page 4 All manuals and user guides at all-guides.com The  Windows   o perating  system  includes  a  Firewall  setting  as  standard;  this  is  the   s ecurity  function  that   c an  prevent   improper  access   t hrough  the  Internet.  To  let  the  Remote  Utility   w ork  properly,   a dd  it  as  an   e xception  in   t he  Firewall   In  the  “Allowed  programs  and  features”...

  • Page 5: Connecting To The Rs-Ba1 Locally

    All manuals and user guides at all-guides.com Finding the IP of your Base Station Computer 1. Click  Start.   2. Click  Run.     3. Type   “ cmd”.   4. Click  OK.       5. In  the  Command   w indow,  type   “ ipconfig”.   6.

  • Page 6: Setting Up Port Forwarding

    All manuals and user guides at all-guides.com 7. Record  your  computer’s  IP   a ddress.  You  will  need  this   i nformation  later  while  setting  up  the  RS-­‐ B A1  software.  In   the  following  example,  the   B ase  Station   c omputer’s  IP   i s  192.168.3.106      ...
  • Page 7 All manuals and user guides at all-guides.com 5. Enter  RS-­‐ B A1  in  the  Service  Name  field.   6. Select  UDP  in   t he  Protocol   f ield.   7. Enter  the  Port  Range  from   5 0001  to   5 0003.   8.
  • Page 8 All manuals and user guides at all-guides.com 10. Select   t he   R SBA1  UDP  port  in  the  Service  field.     11. Enter   y our   B ase  Station’s  Computer  IP  in  the  IP  Address  field.   12.

  • Page 9: Setting Up The Rs-Ba1 Remote Utility Software For The Base Station

    14. After  your  see   t he  RSBA1  ports  forwarding  box,  Click  Save  Settings.     Setting up the RS-BA1 Remote Utility Software for the Base Station 1. Open  the   R S-­‐ B A1   R emote   U tility  Software.  ...
  • Page 10 All manuals and user guides at all-guides.com 3. Enter   y our  Computer’s  Name  in  the  PC   N ame  field.   4. Choose  FTTH  in  the  Internet  Access  Line  field.     5. Click  Apply.   6. Close  (exit)  the  RS-­‐ B A1  Remote   U tility  software  and  open  it  again.    ...
  • Page 11 All manuals and user guides at all-guides.com 7. Select  Server  Setting.     8. Click  the  User  List   t ab.   9. Enter   y our   U ser  ID  and  password     10. Click  the  Administrator  Checkbox     11.
  • Page 12 All manuals and user guides at all-guides.com   13. Click  the  Radio  List  Tab.   14. Click    Add.       15. Enter   y our  radio  name  in  the  Radio   N ame  field.   16. Click  the  CI-­‐ V  checkbox  and  enter   y our  CI-­‐ V  address  in   t he  Address  field.  This  information  is  available  in  the   Instruction  ...
  • Page 13 All manuals and user guides at all-guides.com   19. Select  your  Username  from  the  Radio   U ser  Permission  box  and   c lick   P ermit.       20. When  you  see   y our  Username  in  the   P ermitted  Users   f ield,  click  OK.    ...
  • Page 14 All manuals and user guides at all-guides.com 21. When  using  a  USB  connection  between  your  computer  and  Icom  radio,  Click  Auto   f or  COM  Port/Audio  Setting.       22. When  setting  a  COM  port   m anually,   c lick   t he  Manual  Checkbox  and  select  your   C OM   P ort  in   t he   C OM  Port  ...
  • Page 15 All manuals and user guides at all-guides.com 24. When  using  a  USB  headset/mic,  select  your  headset  under  AF  Input  /  MOD  Output  Device.  Your  computer   should  auto  detect   y our  speakers.       25. Click  OK.      ...
  • Page 16 All manuals and user guides at all-guides.com 28. Select   y our  radio  and  click   C onnect.       29. Click  OK   o n  the  Remote  Utility  Box   ( Com  port  number   c an  be  looked  up  in  the  Device   m anager).    ...

  • Page 17: Connection Errors

    Check  that  all  devices  are  powered.   The  firmware   o n  your  Icom  radio  should  be  current  and  that  supports  the  RS-­‐ B A1.   Reboot   y our  computer,  sometimes  the  COM   P ort  (regular  and  virtual)  requires  a  PC  reboot  for  complete  ...
  • Page 18 All manuals and user guides at all-guides.com     1. Verify  that  the  Remote  Control  software  is  turned   O ff.    CLICK       2. Click  Option  and  select  Connect  Setting  …    CLICK          ...
  • Page 19 All manuals and user guides at all-guides.com 3. At  the   C onnect  Setting   w indow,   c lick  Model  and   s elect  your  radio  (verify  the  revision  number).       4. Click  Remote  Utility  and  select   y our   r adio.    ...
  • Page 20 All manuals and user guides at all-guides.com   8. Turn  the  Remote  Control  Software   o n.  Wait  for  the  software  to  change  its  frequency.     19  ...

  • Page 21: Accessing The Rs-Ba1 Remotely Over The Internet

    All manuals and user guides at all-guides.com The  following  steps  are  for  the  Remote  Base  Station  computer   o nly.   1. Click  Server  List.   2. Click  Add.       3. Enter  following  information:   Enter  your  Computer  Name   Enter  your  Base  Station  Network  global  IP*  ...
  • Page 22 All manuals and user guides at all-guides.com 4. You  have  now  created  a  Server   o n   y our   R emote   c omputer  to  talk  to   y our  Base  Station  network.       5. Select  Server  List.   6.
  • Page 23 All manuals and user guides at all-guides.com   If  connection  is  successful,   y ou   w ill  see  the  following   w indow.  CONNECTING   m eans  you  are  connected.       7. Click  Radio   L ist  and  you   w ill  see   y our  radio  come  up.    ...
  • Page 24 All manuals and user guides at all-guides.com 8. Click  your  radio.   9. Click  Settings.       10. Click  Virtual   C om  Port  Number  and  select   y our  virtual  COM  Port  (  You  can  look   u p  your  Virtual  Comport  in  the   Device  ...
  • Page 25 All manuals and user guides at all-guides.com 11. Click  Save.   12. Click  Connect.                   13. Click    OK   o n  the  Remote  Utility  window.           24  ...
  • Page 26 All manuals and user guides at all-guides.com If  you   s ee  <<CONNECT>>   o n  the  window   y our  connection  is  successful.       14. Open  the   R S-­‐ B A1   R emote  Control  software   o n  the  Remote  Station  computer  and  set  it  up  as  described  in  Setting  ...

  • Page 27: Errors Explained

    All manuals and user guides at all-guides.com Errors Explained You   w ill  get  the  OFFLINE   e rror   o n  the  remote   c omputer  Utility  Software  if  the  Remote   U tility  software   o n  the  Base   Station  ...
  • Page 28 All manuals and user guides at all-guides.com 2380 116th Ave NE, Bellevue WA, 98004...
