2. Setting up the monitor
228C3LH
Kensington anti-theft lock
DC power input
HDMI audio out
HDMI input
VGA input
Connect to PC
1. Connect the power adapter cable to the
back of the montior firmly.
2. Turn off your computer and unplug its
power cable.
3. Connect the monitor signal cable to the
video connector on the back of your
computer.
4. Plug the power cable into the power
adaptor and into a nearby outlet.
5. Turn on your computer and monitor. If
the monitor displays an image, installation
is complete.

2.2 Operating the monitor

Front view product description
5
7 6
: To access OSD menu.
: Return to previous OSD level.
: To use the Turbo function.
: To switch monitor's power on and off.
: To adjust the OSD menu.
: To change the signal input.
: SmartImage. There are 7 modes to
be selected: Text, Office, Photo, Movie,
Game, Economy and Off.
5
4
3 2 1
