- Page 1 Compact DAB+/FM Radio Art. No. 50740 User Manual...
-
Page 2: Table Of Contents
Contents Location of controls ........3 Precautions ..........Getting started ..........6 Declaration of Conformity ........ Charging battery .........8 Change mode ........9 DAB radio operation ........10 FM radio operation ........15 Statio n Preset ........... Bluetooth Playback ........Q & A ............ - Page 3 Location of controls DAB+ SOUND - 3 -...
- Page 4 Location of controls 1. Display Press and hold to power on, press and hold it again to power off.. 3. ▲ [DAB] Enter the station list after scan Scroll up on the menu list [FM] Every press of the button will scan the frequency upward by 0.05MHz.
- Page 5 Location of controls 7. + Press + to increase the volume level ]-Info Press the button repeatedly to view various info broadcasted by the radio station [ M ] - Menu Press and hold the button to enter the main menu 9.
-
Page 6: Precautions
Precautions • The radio should not be used in a high temperature or high humidity environment over prolonged periods of time as this may damage the unit. • Keep the radio away from liquids as it may get damaged. Please switch off the radio immediately if water or liquids is spilled into the radio. -
Page 7: Declaration Of Conformity
• Directive 2011/65/EU (RoHS 2.0) and its amend ment directive (EU)2015/863 Declaration of Conformity Hereby, EUROtops Versand GmbH declares that article 50740 Compact DAB+/FM radio complies with the essential requirements of the European Union Directive 2014/53/EU. The full text of the EU declaration of conformity is... -
Page 8: Charging Battery
Charging battery You can check the level of battery power remains on the radio. When the radio is playing, press the [ /M] button repeatedly until you see the percentage of remaining battery power display as follow: ABC dig percentage of remaining Battery battery power When battery power is low, it will prompt with... -
Page 9: Change Mode
Change the Mode When the radio is powered on, press the [ MODE ] button to switch modes of DAB / FM / Bluetooth. - 9 -... -
Page 10: Dab Radio Operation
DAB radio operation DAB scan The first time you power on the radio, it will scan the DAB radio stations automatically. It will display and play the first station after the scan is done. In case it displays "No DAB Station", it will enter into main menu automatically and display the "Full Scan"... - Page 11 DAB radio operation • Manual tune This function allows you to check whether a specific frequency can be received in your area and it's signal strength. When this option is selected, it will show a list of DAB frequencies. Choose the desired frequency and it will display the signal strength.
- Page 12 DAB radio operation - Select Alarm 1 or Alarm 2 by the up/down button. Press OK to confirm. - Choose "On" or "Off" by the up/down button to activate the Alarm or disable it, then press OK. - Set the time by the up/down button. Set the "Hour"...
- Page 13 DAB radio operation Duration of Snooze When the Snooze is activated, the "Snooze 5 minutes" will appear and blink for a few seconds. The 5 minutes is set by default. Snooze: 5 Minutes While it is blinking, press the up/down button to choose other duration time of 10/15/30 minutes.
- Page 14 DAB radio operation choose "YES" and press [OK] to confirm, the radio will reboot and all settings will be resumed factory's default (all previous settings/presets will be erased). SW Version This is to show software version of the radio. DAB radio information When the radio station is playing, press the [ /M ]...
-
Page 15: Fm Radio Operation
FM radio operation FM scan Press the [ MODE] button to switch to FM. To enable Auto Scan, press and hold the [OK] button, it will scan the available stations according to the scan setting selected in the menu, and store to the preset list automatically (see below section for scan setting). - Page 16 FM radio operation it will scan out both the strong and weak channels. <Scan setting > Scan setting* Scan setting* <Strong stations > <All stations > • Audio setting You can choose to have "Forced Mono" or "Stereo allowed". If the signal is weak and stable stereo reception is not possible, select "Forced Mono"...
- Page 17 FM radio operation button repeatedly to cycle through the information broadcasted by the radio as follow: • Name of the radio station • RT (Radio text): Text broadcasted from the FM station(if any). • Program type (PTY) • Radio Frequency – the FM frequency for the radio station in playing.
-
Page 18: Station Preset
Station Preset To preset a station, press and hold the [FAV] button, it will enter the list of "Preset Store". If the preset is available, it will show "Empty". Use the [ ▲/▼ ] button to choose the preset number and press [OK] to confirm. -
Page 19: Bluetooth Playback
Bluetooth Playback Before transmission between your BT device and the radio is possible, both devices must be coupled. This process is called "pairing". The radio is served as a receiver, to receive music stream to play on the radio. Press the <Mode> button to cycle through the different operating modes, ultimately selecting BT mode. -
Page 20: Q & A
Q & A If you are experiencing problems with your DAB radio there are some quick and easy checks that you can do, which may help to solve the problem. No DAB reception - If it displays "No DAB Station", please carry out "Factory Reset"... - Page 21 Q & A Problems with Bluetooth no sound Make sure the Bluetooth device is paired and connect- Check that your smart phone is set up to stream audio via Bluetooth. Check the volume of the Bluetooth device and radio volume control buttons. Switch to source Bluetooth with MODE button.
-
Page 22: Technical Data
Technical Data Subject to technical changes and errors. The dimensions are approximate. Compact DAB+/FM Radio Unit Dimension 125 x 27 x 76 mm (L x D x H) Unit weight About 162g Ambient temperature +5 °C to +35 °C Relative humidity 5% to 90% (non-condensing) Power supply... -
Page 23: Package Disposal
Package Disposal ATTENTION!!! The returns will be impossible if products were damaged because of incorrect use. DISPOSAL： The packaging material is reusable. Dispose of the packaging in an environmentally friendly way by putting it in the appropriate recyclable waste collection contain- ers. - Page 24 Eurotops Versand GmbH Elisabeth-Selbert-Straße 3 40764 Langenfeld, Germany If technical support is needed, please call ... in Germany 0180 . 530 63 63* or info@eurotops.de in Austria 0800 321768**** or info@eurotops.at in Switzerland 071/27 4 68 06 or info@eurotops.ch in the Netherlands 020262 1958 or info@eurotops.nl...
