USER MANUAL
SIRIO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIRIO and is the answer not in the manual?

Questions and answers

Related Manuals for Montana SIRIO

Summary of Contents for Montana SIRIO

  • Page 1 USER MANUAL SIRIO...

  • Page 3: Table Of Contents

    U S E R M A N U A L I N D E X 1.0 General warning 1.1 Important safety information 2.0 OLI Sport system main features 2.1 How to switch on/off the OLI Sport system 3.0 Battery 3.1 Battery charge percentage 3.2 Battery installation and removal 3.3 Battery key 3.4 Battery cleaning...

  • Page 4: General Warning

    • This product must be used in compliance with the local laws and regulations. !! WARNING – The use of batteries, battery chargers or other aftermarket accessories not approved by MONTANA S.R.L may compromise the normal functioning of the system and may cause damage. Moreover, it voids the warranty. 1.1 IMPORTANT SAFETY INFORMATION !! DANGER –...
  • Page 5 U S E R M A N U A L • Kids must not play too close to the e-bike. • Contact the retailer for the installation and adjustment of the e-bike. • Do not put the e-bike upside down. This may cause damage to the display or to the shift lever. •...

  • Page 6: Oli Sport System Main Features

    U S E R M A N U A L 2.0 OLI SPORT SYSTEM MAIN FEATURES To use the OLI Sport propulsion system, make sure that the following requirements are met: • The battery must be sufficiently charged. • The speed sensor must be correctly connected and the magnet correctly positioned. The motor automatically deactivates when the e-bike reaches the speed of 25 km/h.

  • Page 7: Battery Charge Percentage

    U S E R M A N U A L 3.1 BATTERY CHARGE PERCENTAGE The battery charge percentage is displayed in every Home screen. battery charge indicator 3.2 BATTERY INSTALLATION AND REMOVAL WARNING: Always remember to switch off the battery before the battery installation or removal. BATTERY REMOVAL BATTERY INSTALLATION 1.

  • Page 8: Battery Key

    U S E R M A N U A L 3.3 BATTERY KEY In case of key loss, contact your retailer. He will replace the whole padlock. 3.4 BATTERY CLEANING • Do not use diluents or solvents to clean the e-bike parts. Such products may damage the components. •...

  • Page 9: High Vision Display

    U S E R M A N U A L FraMe charging socKei charging plug WARNING: • If the battery (17.5 Ah) is completely discharged, it will take 10 hours to complete the charge. • If the battery (14.5 Ah) is completely discharged, it will take 7/8 hours to complete the charge. •...

  • Page 10: Main Screens

    U S E R M A N U A L BUTTON SHORT PRESSING (<1 SEC) LONG PRESSING (>2 SEC) Allows you to scroll through the menu items, From any main screen allows you to activate DOWN going down Walk mode From the main screens, pressing the two DOWN + UP keys simultaneously allows access to the...
  • Page 11 U S E R M A N U A L SCREEN 1 – TRIP Indicates the distance travelled in kilometers (km) since the last reset. SCREEN 2 – TIME Indicates the time elapsed in motion since the last reset. The value is expressed in hours:minutes:seconds.

  • Page 12: Assistance Levels

    U S E R M A N U A L SCREEN 6 – SUMMARY It is the sixth screen of the Home section. This screen summarizes the variable parameters of the previous screens. Indicates the distance travelled in kilometers (km) since the last reset.

  • Page 13: Settings

    U S E R M A N U A L 4.5 MENU From the Home section, hold down the UP + DOWN buttons at the same time for 2” to enter the Menu section. From the Menu page: • Use the UP and DOWN buttons to scroll through the items present, the selected item is highlighted in the center in the white line;...
  • Page 14 U S E R M A N U A L LANGUAGE From this screen you can choose the language of the unit’s text. Use the UP and DOWN buttons to scroll through the available items. The selected value is highlighted in the center in the white line. Press the POWER button to confirm and return to the Advanced page.

  • Page 15: Error Codes

    U S E R M A N U A L NIGHT MODE: From this screen you can choose the configuration for night mode: • Automatic, the night mode is set automatically by means of the twilight sensor inside the display, which detects the ambient brightness. •...

  • Page 16: Technical Assistance

    U S E R M A N U A L Locked rotor. The motor failed to start due 0808 to a mechanical lock or a problem with the Request assistance internal wiring of the power unit The battery voltage is higher than the 0809 Request assistance maximum allowed...

  • Page 17: Disposal

    U S E R M A N U A L 4.9 DISPOSAL HMI unit, display, keypad, various accessories and packaging must be disposed of in compliance with the environmental regulations in force. When the unit is put out of service and dismantled, it is necessary to separate the plastic parts and the electrical components, which must be sent to the separate collection centres in compliance with the regulations in force.
  • Page 20 MONTANA S.R.L. Via Domenico Rossi 70, 12060 Magliano Alpi (CN) - Italy Tel. +39 017466828 - Fax +39 017466651 montana@montanabike.com - www.montanabike.com...
