  • Page 1 The CINK User Manual...

  • Page 2: Table Of Contents

    Warranty ..............................13 INTRODUCTION The CINK is a complete, self-contained system for cleanup of clay, clay water, pottery tools and accessories. The system is designed to prevent clay from going down drains in plumbing or septic systems. The CINK Classic The CINK Deluxe diamondcoretools.com | info@diamondcoretools.com...

  • Page 3: Safety Precautions

    Do not plug the drain of The CINK to fill the sink basin to wash parts. • CAUTION: Use The CINK only in areas where if water spills it will not damage floors or carpeting, etc. Be aware that water may drip from hoses or spill when bucket lids or filters are removed.

  • Page 4: Quick Start

    QUICK START QUICK START Valve (Up is CLOSED, Down is OPEN) Spray Nozzle GFCI Pump Cover Pump 6.5 gal. Quick Disconnect Sink Basin String Filter Housing (Big Blue) (O-Ring & String Filter inside) Drain Union 5 gal. Quick Disconnect Bucket - 6.5 gal. Bucket - 5 gal.
  • Page 5 QUICK START Remove CINK from pallet. Position Separate the quick disconnects and Add fresh water to buckets. CINK near electrical outlet. the drain union to remove buckets. Stop at fill lines. Check string filter and ensure O-ring Screw on bucket lids. Be sure Remove blue filter housing by is in place.

  • Page 6: Operation

    WARNING! NEVER plug the sink basin drain and fill the basin with water to wash parts. This may cause the buckets to collapse if the pump keeps pumping. The CINK system is designed to function with continuous recirculation of water.

  • Page 7: Maintenance

    Emptying the 5-Gallon Clay Collection Bucket The 5-gallon bucket is intended to capture most of the clay and slip that will be put into The CINK. You will need to empty this bucket more frequently than cleaning or replacing the other two filters.
  • Page 8 MAINTENANCE Emptying the 6.5-Gallon Filtered Sediment Bucket and Cleaning the Filter Bag The filter bag in the 6.5-gallon filtered sediment bucket is designed to stop particles and debris that are not settled out in the 5-gallon clay collection bucket smaller bucket .
  • Page 9 MAINTENANCE Changing the Filter Cartridge in the Big Blue Filter The big blue filter collects ultra-fine clay particles and should be cleaned at least every 3 months. Eventually, the pores of the filter cartridge will fill up and the water flow from the spray nozzle will decrease. At that time, please visit www.DiamondCoreTools.com, call 619-905-9400 or email info diamondcoretools.com to purchase replacement filters.
  • Page 10 Water Cleanliness You can eliminate odors in The CINK the same way you would with a slip bucket or clay trap. Because clay is an organic material, it can sometimes create mold and a sulfuric stink. A capful of bleach, done in moderation, will kill mold spores but won’t affect reclaim.

  • Page 11: Troubleshooting

    Clean all buckets and filters. Basin Not Draining Bucket Lid Leaking Stop The CINK and allow Ensure lid is screwed on water to drain. Check that level and tight. Be care- all 3 O-rings (on lids ful not to crossthread.

  • Page 12: Frequently Asked Questions

    FREQUENTLY ASKED QUESTIONS FREQUENTLY ASKED QUESTIONS Why is the basin not draining? Loose 6.5 gallon bucket lid Damaged O-ring in either lid or blue filter housing Clogged check valve (small tube on the 6.5 gallon lid) How do I fix a leak in a bucket lid? Ensure lid is tight and seated properly Check O-ring for damage Why is water pooling on the top of the bucket lid?

  • Page 13: Parts & Accessories

    PARTS & ACCESSORIES The CINK Replacement String Filter: $29 The CINK Replacement Bag Filter: $19 The CINK Replacement Blue String Filter Canister: $95 The CINK Replacement Bucket O-Ring (2-pack): $11.50 The CINK Replacement Pump Kit: $319 The CINK Accessory Set 1: $10 For Replacement Parts DiamondCore®...
  • Page 14 Changing the World of Ceramic Arts Glass Arts Lapidary Arts Wax Arts And More 680 W. Bradley Ave., El Cajon, CA 92020 619-905-9400 | diamondcoretools.com | info@diamondcoretools.com...
