Main Controller Harness Connection Description
3.1 Main Harness (8-Pin) – Connect the following wires
GREY(2 Wires): (+) Turn Signal Lights
• Connect to positive side of the Front/Rear indicator lights. Could
optionally connect to hazard light wiring for same effect.
RED: (+) 12V Battery
• Connect to the 12V supply wire at the IGNITION switch. Ensure that
the OEM power wire is fused for more than 30A. Note: When no
suitable 12-Volt source at the IGNITION switch (where the 12-Volt
wire is a small ignition signal wire or current capacity is less than 15A).
In this case, vehicle's interior fuse junction box or the B+ connection
on the battery is recommended.
GREEN: (-) Lock
• If you have a negative-trigger central locking system, directly connect
this wire to the door lock signal wire.
• Please refer to section 4 for more information on central locking
system trigger type.
BLUE: (-) Unlock
• If you have a negative-trigger central locking system, directly connect
this wire to the door unlock signal wire.
• Please refer to section 4 for more information on central locking
system trigger type.
BLACK: (-) Ground
• This wire must be connected to bare, unpainted metal (to Chassis or
true body-ground). It is preferable to use a factory ground bolt rather
than a self-tapping screw. Screws tend to get loose or rusted over
time and lead to erratic electrical problems.
PURPLE: (-) OEM Horn Control Wire
• Connect to negative side of vehicle's OEM horn for sound warning. If
desire to use siren, change the jumper and alarm setting according to
the main controller wiring diagram. If siren control is positive input
type, add additional relay according to the wiring diagram to convert
output to a positive type.
