- Page 1 COT190E-AWF02 Spec1.0 COT190E-AWF02 19" Open-Frame Monitor with 4mm/6mm SAW Touchscreens DongGuan CJTOUCH Electronic Co., Ltd. PUBLISHED DATE:2013-03-28 - 1 - www.cjtouch.com...
-
Page 2: Revision History
COT190E-AWF02 Spec1.0 REVISION HISTORY VERSION DATE MODEL PAGE DESCRIPTION AUTHOR 李丽群 2013/3/28 COT190E-AWF02 First Issued - 2 - www.cjtouch.com... -
Page 3: Safety Instructions
COT190E-AWF02 Spec1.0 Safety Instructions 1. Read these safety instructions carefully. 2. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 3. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible. -
Page 4: Product Features
COT190E-AWF02 Spec1.0 1.1 Introduction Long lasting product cycle-enclosure controlled by CJtouch specifications Future generation panels phased-in without external changes High quality panel with high brightness,high contrast ratio and broad viewing angle Multiple mounting options including VESA mount, horizontal or vertical bracket-mount ... -
Page 5: System Setup
COT190E-AWF02 Spec1.0 1.2.3 Touchscreen Specification Cjtouch Surface Acoustic Wave(SAW) Type Resolution 4096*4096 Light Transmission 50 millions Touch Life Cycle Touch Response time 16ms Touch System Interface RS-232 and USB interface Power consumption +5V@80mA 1.2.4 External AC Power Adapter DC 12V /4A... - Page 6 COT190E-AWF02 Spec1.0 RS232 1.3.3 OSD Control OSD buttons Adjusting with OSD control Five different keys are well-defined for operation . They are labeled on the keypad. A) [Power] Key is designated for Power On/Off B) [Menu] Key is designated for Menu/Enter function depending on the selected item. Pressing [Menu] can invoke OSD menu.
-
Page 7: Mechanical Dimension
COT190E-AWF02 Spec1.0 1.3.4 Setup the driver 1. Make sure the Touchscreen Cable is properly connected. The Setup program cannot configure the touchscreen without it. 2. Insert the CD Kit into your PC system’s CD drive. 3. Click the SETUP.EXE installation program. The Setup program begins to execute and load the CJTOUCH’S driver. -
Page 8: Exploded Diagram
COT190E-AWF02 Spec1.0 1. Build 8 screw studs along the four sides of the cut out opening based on the dimension given on the drawing above. 2.Thghten the screw stud with hex nut and make sure it is stable. 1.4.3 Exploded Diagram 1.5 Electrical Block Diagram... -
Page 9: Solutions To Common Problems
COT190E-AWF02 Spec1.0 2.0 Solutions to Common Problems Problem Suggestion(s) 1)Check that the monitor’s Power Switch is on. The monitor does not respond 2)Turn off the power and check the monitor’s power cord after you turn on the system and signal cable for proper connection.
