- Page 1 COT150-AWF01 Spec1.0 COT150-AWF01 15" Open-Frame Monitor with 4mm SAW/ Vandal proof /Water Proof SAW Touchscreens DongGuan CJTOUCH Electronic Co., Ltd. PUBLISHED DATE:2013-03-28 - 1 - www.cjtouch.com...
-
Page 2: Revision History
COT150-AWF01 Spec1.0 REVISION HISTORY VERSION DATE MODEL PAGE DESCRIPTION AUTHOR 李丽群 2013/3/28 COT150-AWF01 First Issued - 2 - www.cjtouch.com... -
Page 3: Safety Instructions
COT150-AWF01 Spec1.0 Safety Instructions 1. Read these safety instructions carefully. 2. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 3. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible. -
Page 4: Product Features
COT150-AWF01 Spec1.0 1.1 Introduction Your LCD openframe touchmonitor is a 15” SXGA TFT color display with the following features: Bezel seal standard：NEMA3 and IEC IP64 Long lasting product cycle-enclosure controlled by CJtouch specifications Future generation panels phased-in without external changes ... -
Page 5: System Setup
COT150-AWF01 Spec1.0 Luminance(cd/m2) Response 2s/6s Time(Rising/Falling) Support Color 16.2M Backlight MTBF(hr) 50000 1.2.3 Touchscreen Specification Type Cjtouch Surface Acoustic Wave(SAW) Resolution 4096*4096 Light Transmission Touch Life Cycle 50 millions Touch Response time 16ms Touch System Interface RS-232 and USB interface... - Page 6 COT150-AWF01 Spec1.0 The diagram shows the DVI port, VGA port, RS-232 port, USB port and DC Power inlet RS232 1.3.3 OSD Control OSD buttons Adjusting with OSD control Five different keys are well-defined for operation . They are labeled on the keypad.
-
Page 7: Mechanical Dimension
COT150-AWF01 Spec1.0 C) [+] key is designated for selection function in up direction in OSD menu and also to increase the value on selected function. D) [-] key is designated for selection function in down direction in OSD menu and also to decrease the value on selected function. -
Page 8: Exploded Diagram
COT150-AWF01 Spec1.0 1.4.1 Touch Monitor Mounting guide 1. Build 4 screw studs along the two sides of the cut out opening based on the dimension given on the drawing above. 2.Thghten the screw stud with hex nut and make sure it is stable. -
Page 9: Solutions To Common Problems
COT150-AWF01 Spec1.0 touchscreen used as a pointing device. A metal chassis supports the whole module. Block Diagram 2.0 Solutions to Common Problems Problem Suggestion(s) 1)Check that the monitor’s Power Switch is on. The monitor does not respond 2)Turn off the power and check the monitor’s power after you turn on the system cord and signal cable for proper connection. -
Page 10: How To Contact Us
COT150-AWF01 Spec1.0 Entertainment Transport and Ticketing Hospitality Banking Customizsed Solutions How to contact us www.cjtouch.com ： Block B, 5th floor,Building 6, Anjia industrial park, WuLian, FengGang, DongGuan,P.R.China ： +86-769-82522511 ： +86-769-82522517 ： Sales & Marketing cjtouch@cjtouch.com - 10 - www.cjtouch.com...
