PCB Piezotronics IMI SENSORS R687A02 Installation And Operating Manual page 14

Model Number
687A02
Performance
Frequency Response(+10 to -20 %)
Frequency Response(+/-3 dB)
Acceleration Range
Resolution
Velocity Range
Accuracy
Environmental
Temperature Range
Electrical
Excitation Voltage(+/-1 VDC)
Constant Current Excitation(+/-0.6 mA)
Bias Voltage
Battery Life(Alkaline)
Battery Life(Rechargeable Ni Cad)
Physical
Size (Length x Width x Height)
Weight(with battery)
Connector(Input)
Connector(Headphones)
ROHS Compliant
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
HANDHELD VIBRATION METER
ENGLISH SI
600 to 60,000 cpm 600 to 60,000 cpm
3 to 3000 kcpm 99 to 3,000,000 cpm
0.01-199.99 g rms 0.01-19.99 g rms
± 2 counts ± 2 counts
0.001-1.999 in/sec rms NA
± 3 % ± 3 %
+32 to +122 °F 0 to +50 °C
24 VDC 24 VDC
2 mA 2 mA
0.00 to 19.99 VDC 0.00 to 19.99 VDC
10 hours 10 hours
3 hours 3 hours
5.9 in x 3.15 in x 1.2 in 150 mm x 80 mm x 30 mm
0569 lb 0569 lb
BNC Jack BNC Jack
1/8" Stereo Jack 1/8" Stereo Jack
No No
[5]
Optional versions have identical specifications and accessories as listed for the standard model
[5] except where noted below. More than one option may be used.
R
[1] - Rechargeable option, includes rechargable batteries and charger.
Supplied Accessory : Model 017A01 Power Cord (1)
Supplied Accessory : Model 073A09 Rechargeable NiCad battery (9V) (1)
[1]
Supplied Accessory : Model 073M12 External Charger (1)
[4]
NOTES:
[1] Typical value.
[2] Typical.
[3] Varta TR7/8 or Eveready N88 for rechargeable version.
[1] [4] Non-condensing.
[5] 1Hz = 60 cpm (cycles per minute).
[2][3]
Entered: LK Engineer: RB
Date: 5/15/2018 Date: 5/15/2018
3425 Walden Avenue, Depew, NY 14043
Revision: C
ECN #: 47534
OPTIONAL VERSIONS
Sales: MC Approved: BAM
Date: 5/15/2018 Date: 5/15/2018
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
Spec Number:
11285
