- Page 1 3D Foot Scanner Model iQube VAS-41 Installation and User Guide 002-UG-0001-R03 Page 1...
- Page 2 © 2023 UAB Elinvision Information in this guide is subject to change without notice. No part of this document may be reproduced or transmitted in any way without the express written permission of UAB Elinvision. Registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
6. Start the software ..........................14 7. Your first measurement ........................14 8. Software user guide ........................15 9. System specifications model iQube VAS-41 ................16 10. Appendices ............................ 18 10.1. Troubleshooting ......................... 18 10.2. REACH compliance statement ....................18... -
Page 4: Introduction
Congratulations on your new purchase. The 3D Foot Scanner is intended to obtain foot dimensions for shoe size measurement and selection. This guide will assist you with the installation and usage of the 3D Foot Scanner model iQube VAS-41. The installation consists of: ✓... -
Page 5: Product Description
1.3. Product description The 3D Foot Scanner uses laser triangulation technology combined with color images precise representation of the feet. Cameras plus line lasers are used to capture the 3D image and texture. This allows precise and fast scans of feet in normal ambient light conditions. -
Page 6: Product Overview
1.4. Product overview 1.4.1. Model iQube VAS-41 The 3D Foot Scanner model iQube VAS-41 package includes: • iQube 3D Foot Scanner. • Scanner cover / side support step. • USB cable A-B 1.8m (71 Inches). Do not use any other USB cable! •... - Page 7 • Vacuum suction cup to lift the glass plate to remove the transportation lock. • Unpacking instructions. • Optional foot switch / pedal. 002-UG-0001-R03 Page 7...
-
Page 8: General Information
2. General information 2.1. Symbols The following symbols may appear on the product, packaging or documentation: Caution, read these instructions carefully. If used on the product label: Caution, consult accompanying documentation. Regulatory Mark for the European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). -
Page 9: System Requirements
2.2. System requirements Refer to the Installation Guide and User Manual for the software. 2.3. General safety information This section contains instructions regarding safety. Please read carefully. • Prior to a measurement session, instruct the client how to stand on the 3D Foot Scanner. The client should only step or stand on the designated scan area or center of the support step. -
Page 10: Care Of The 3D Foot Scanner
Period") when used in accordance with the Installation and User Guide. • If the Product is determined to be defective during the Warranty Period, UAB Elinvision will at its option (1) repair the Product, (2) exchange the Product with a new Product or refurbished Product that is equivalent to new in performance and reliability. -
Page 11: European Union (Eu) Customer Information
• The cost of all parts and labor in the repair or replacement of the Product, following mechanical or electrical breakdown, which are shown to the satisfaction of UAB Elinvision to be defective due to faulty materials or workmanship. The warranty excludes: •... -
Page 12: Unpacking And Installation
3. Unpacking and installation The scanner is shipped with a transportation lock, follow the instructions on the lock to remove it. Place the scanner at the point of use. Place the scanner level on a solid flat surface. Do not place under direct lighting or sunlight. Unlock the clips from the scanner cover. -
Page 13: Software Installation
4. Software installation Caution: Do not connect the 3D Foot Scanner to the USB port of the PC until the software is installed. Refer to the Installation Guide and User Manual for the installation of the software. 5. Connecting the scanner Once the software has been successfully installed, you are ready to connect the 3D Foot Scanner. -
Page 14: Start The Software
Connect the USB-A plug side of the cable (flat rectangular plug) to a free USB port on your PC. Match the orientation of plug and connector. When the hardware setup is completed, switch on the 3D Foot Scanner by switching the power switch to the ON position (Marked I). -
Page 15: Software User Guide
Roughly position the center of the foot in the center of the transparent part of the glass to obtain the best scan result. Refer to the Installation Guide and User Manual for the software for further instructions on how to take a measurement. -
Page 16: System Specifications Model Iqube Vas-41
9. System specifications model iQube VAS-41 Dimensions (with cover) (L x W x H): 700 x 380 x 199 mm (27.55 x 14.96 x 7.83 Inches) Weight: 17 Kg (37.48 lbs.) 330 x 180 x 150 mm ±5 mm Scanning area (L x W x H): (13 x 7 x 6 Inches ±0.2 Inches) - Page 17 I/O: 1x USB 2.0 (1.8m USB cable A-B) Supply voltage: Power consumption: 100 V - 240 V AC 50-60 Hz 9 W non scanning 19 W scanning Mains connection: connect to the AC mains mains fuse, replace with same rating (1.25A) Fuse: to switch the 3D Foot Scanner on or off, lights red when power is on and mains Power switch:...
-
Page 18: Appendices
All information in this statement is based on our current knowledge. We take neither liability nor warranty for factors beyond our knowledge and control. The majority of products supplied by UAB Elinvision do not contain any of the Substances of Very High Concern (SVHC) of the published candidate list in a concentration above 0.1% w/w.
